5. As shown in the figure:
- Align the seat with the holes on the
frame, then secure it with screws.
THE PUTTER INSTRUCTIONS:
Loosen the knob and press the
telescopic button on the push
rod. Whilst holding the button
down, you can move the putter
up and down three gears.
7. As shown in the figure:
- Insert the parent pushbar into the
connecting tube behind the seat
until the bead lock clicks into place.
- It has been attached successfully.
EN
2
1
2
1
IMPORTANT:
The seat cushion is
adjustable.
1 is the front file; 2 is the rear
stop.
The bolt holes indicated by 2
can expand the riding space.
6. As shown in the figure:
- Attach the basket to the rear axle of the
- Ensure it is in the correct position, then
IMPORTANT:
The awning can be
adjusted up and down;
8. As shown in the figure:
- Align the positioning column with the
guardrail support.
- Insert the support until it clicks into
place.
9
main frame.
tighten it with the basket lock.
