GENERAL INSTALLATION INSTRUCTIONS

MOUNTING THE APPLIANCE

See Table 1, page 22 for appliance weight. The wall or structure on which the units are to be mounted
must be capable of supporting these weights and the associated pipe-work.
Ensure that suitable fixing screws or bolts are used to secure the units to the wall, in accordance with
AS/NZS 5601 section 5. Wooden plugs shall not be used.
The top bracket has a keyhole slot so that the appliance can be positioned by hanging it on one screw,
then the other screws can be secured.
The appliance can be mounted directly against the wall or structure. There is no need to use non
combustible sheeting or leave an air gap between the appliance back panel and the wall or structure
for the purposes of meeting the temperature hazard requirements of AS/NZS 5601.

SERVICE CONNECTION POINTS

See Table 1, page 22 for connection / fitting dimensions. Note that these dimensions are NOT an
indication of the pipe sizes required.
An Approved full flow isolation valve and disconnection union MUST be fitted to the cold water inlet.
Isolation Valves must not be fitted directly to the appliance.
It may be necessary to fit a temperature limiting device for delivery to areas used primarily for the
purposes of personal hygiene. Refer to the 'Water Heater and Controllers Installation Configurations'
section of this document.
Purge gas and cold water supply lines to remove air and swarf before final connection of the
appliance. Swarf in either the gas or water supplies may cause damage.
