English

Overview

1
The PSU module is a power supply adapting board, which connects the AXPRO to 12 VDC power sources.
Installation
2
Before You Start
Make sure that the device is disconnected from the mains.
Follow the general safety rules when install the PSU.
1.Remove the mounting plate of the control panel.
2.Turn off the power button of the device. Disconnect the power and Ethernet cables.
3.Loosen the screws and remove the back lid.
4.Remove the screws that fix the boards on the device body.
3
5.Remove the boards, and keep them in the same plane without disconnecting them.
4
6.Remove the original power supply unit (the smaller one) from the mainboard.
7.Connect the PSU to the mainboard by connecting the pin terminal.
8.Fix the boards and the control panel body with the screws loosened before.
9.Connect the power and Ethernet cable, and turn on the power switch.
Specification
Compatibility
Input Voltage
Output Voltage
Input Current
Output Current
Operation temperature
Operation humidity
Dimension ( W× H×D)
Weight
Hangzhou Hikvision Digital Technology CO.,Ltd. No.555 Qianmo Road, Binjiang District, Hangzhou 310052, China
AX PRO Panel
4 to 16 VDC
5 VDC
Up to 4A (4 VDC) ~ Up to 1A (16 VDC)
Up to 2.5A
-10°C to 55°C (-4°F to 122°F)
10% to 90% (No condensing)
80 × 90 × 15 mm
35 g
DS-PM2-D
6V PSU Module
User Manual
UD27355B
