  • Page 1 Vision Box User Manual UD04763B...

  • Page 2: Table Of Contents

    Vision Box User Manual TABLE OF CONTENTS Chapter 1 Overview ....................6 1.1 Introduction ....................6 1.2 Features ......................6 1.3 Specifications ....................6 Chapter 2 Panels and Connections ............... 8 2.1 Dimensions....................8 2.2 Installation ....................8 2.3 Panels ......................9 2.4 GPIO Connections ..................
  • Page 3 INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE WHOLLY AT YOUR OWN RISKS.
  • Page 4 Vision Box User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 5 Vision Box User Manual Applicable Models This manual is applicable to the MV-VB2100-032/120G Vision Box. Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results.
  • Page 6 Vision Box User Manual Safety Instructions  Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user.  In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation and region.

  • Page 7: Chapter 1 Overview

     Two Intel-chip Gigabit network interfaces, with the enhanced surge-protection design to ensure the stable access by machine vision cameras.  Two independent HDMI video outputs.  8 GPIO. 1.3 Specifications Model MV-VB2100-032G MV-VB2100-120G Processor Intel E3845 chip, 4-core 1.91GHz Memory 4GB DDR3L-1333...
  • Page 8 Vision Box User Manual 2 independent HDMI outputs at 2560×1600 Display resolution 2 Intel i210 Gigabit Ethernet chips Network 2 RJ45 Gigabit Ethernet interfaces Enhanced surge-protection Storage 32GB SSD 120GB SSD 1 × USB 3.0 host interface USB interface 1 × composite interface (USB3.0 client+ USB2.0 host) 2 ×...

  • Page 9: Chapter 2 Panels And Connections

    Vision Box User Manual Chapter 2 Panels and Connections 2.1 Dimensions Refer to the following figure for the outline and dimensions of the Vision Box: 4-M3 4 Figure 2-1 Outline and Dimensions 2.2 Installation Use four M3 set screws to install the Vision Box.

  • Page 10: Panels

    Vision Box User Manual Figure 2-2 Installation 2.3 Panels Refer to the following figure for the interfaces on the panel of Vision Box: HDMI接口 USB接口 电源指示灯 RS232接口 千兆网口 千兆网口 USB2.0 HDMI1 USB3.0 AUDIO USB2.0 HDMI2 1 2 3 4 G 1 2 3 4 C G DC 24V RS232 RS485...
  • Page 11 Vision Box User Manual LAN Interface RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface. USB 2.0 interface 2 USB 2.0 Universal Serial Bus (USB) interfaces for additional devices such as USB mouse and USB Hard Disk Drive (HDD). HDD indicator blinks red when data is being read from or written to HDD.

  • Page 12: Gpio Connections

    Vision Box User Manual 2.4 GPIO Connections 2.4.1 Pin Definitions Refer to the following table for the pin definitions of GPIO inputs and outputs: Table 2-2 Pin Definitions Pin No. Name Definition Optical isolation input 1 Optical isolation input 2 Optical isolation input 3 Optical isolation input 4 IN_GND...
  • Page 13 Vision Box User Manual Figure 2-4 Connection Mode A Connection Mode B When the output is used as the signal, you need to add a pull-up resistor (12V/1~ 4k, 24V/2 ~ 8k) between the Common and Output to form a level signal. Refer to the following figure: Figure 2-5 Connection Mode B...

  • Page 14: Chapter 3 Operation Of I/O And Demo

    Vision Box User Manual Chapter 3 Operation of I/O and Demo 3.1 Input/Output Pattern The input channel can be triggered by the upper level device control or the I/O control. And the PWM output and pulse output are provided. The following three configuration patterns are selectable: ...

  • Page 15: Selecting Pattern

    Vision Box User Manual 3.2.1 Selecting Pattern Three patterns are selectable: PATTERN_ALL (pattern 1), PATTERN_I_O (pattern 2) and PATTERN_SERIAL (pattern 3). Step 1 Check the checkbox of Show to enable the settings. Step 2 Select a pattern from the drop-down list. ...

  • Page 16: Triggering By Serial Port

    Vision Box User Manual Step 3 Repeat the sub steps 1) to 3) of Step 2, and select the ACTION_END and configure it to EDGE_RISING or EDGE_FALLING triggering mode. And repeat the sub steps 5) to 6) of Step 2 to complete the settings.

  • Page 17: Configuring Serial Port Property

    Vision Box User Manual You can enter Max in the duration to set continuous outputting. 5) Click the SendCommand to complete the settings. Step 2 Select the STROBE_STATUS mode and set the ENABLE_START to start enabling the serial port. Click the SendCommand to complete the settings Step 3 Select the STROBE_STATUS mode and set the ENABLE_END to end the serial port enabling.
  • Page 18 Vision Box User Manual Figure 3-7 Serial port “Resource” window Table 3-1 Information correspond to function and serial port hardware IRQ Original Serial Correspond IRQ Information Port No. Function COM1 RS232 0x00000004（04） COM2 GPIO 0x0000000A（10） COM3 RS485 0x00000003（03） COM4 NULL 0x0000000B（11）...
  • Page 19 Vision Box User Manual Figure 3-8 Hardware modification window correspond to serial port The Com1 of the Vision Box corresponds to the RS-232, the Com3 to RS-485, and the Com4 is null. Figure 3-9 Serial Port Property...

  • Page 20: Chapter 4 Video Output Configuration

    Vision Box User Manual Chapter 4 Video Output Configuration 4.1 HDMI Video Output The Vision Box provides two HDMI output interfaces for connection to the HDMI display unit (or to VGA display unit with HDMI-to-VGA adapter). Up to 2560 x 1600 resolution is supported. 4.2 Remote Access The Vision Box is installed with the MVWhere client software for device access to the LAN.

  • Page 21: Chapter 5 System And Driver Installation

    Vision Box User Manual Chapter 5 System and Driver Installation 5.1 Installing Operating System The operating system can be installed via USB storage device (e.g., USB DVD, USB mobile disk, etc.). Connect the USB storage device and operate the following instructions to install the system in the BIOS mode.
  • Page 22 Vision Box User Manual...
