- Page 1 PSS u2 ES 16PT 0V Control system PSS u2 Remote I/O system PSS u2 Operating Manual-1003766-EN-03...
- Page 2 We do assure you that all persons are regarded without discrim- ination and on an equal basis. All rights to this documentation are reserved by Pilz GmbH & Co. KG. Copies may be made for the user's internal purposes. Suggestions and comments for improving this documenta- tion will be gratefully received.
-
Page 3: Table Of Contents
............................General wiring guidelines ......................6.1.1 Connection mechanism for terminal blocks ................Terminal configuration ......................Operation ..........................Display elements and messages ....................Technical details ........................Order reference ........................Product ............................. Accessories ..........................Operating Manual PSS u2 ES 16PT 0V 1003766-EN-03... -
Page 4: Introduction
This operating manual explains the function and operation, describes the installation and provides guidelines on how to connect the product. This documentation is valid for the product PSS u2 ES 16PT 0V hardware version 01 or higher. It is valid until new documentation is published. - Page 5 Introduction INFORMATION This gives advice on applications and provides information on special fea- tures. Operating Manual PSS u2 ES 16PT 0V 1003766-EN-03...
-
Page 6: Overview
Details of the terminal blocks that can be used are available under "Intended Use". Module features Application of the product PSS u2 ES 16PT 0V: Electronic module for tapping the periphery supply 0 V The product has the following features:... -
Page 7: Safety
Any use of the module that is not in accordance with the technical details. Please also refer to Installation manual PSS u2. The module PSS u2 ES 16PT 0V may be used in conjunction with the following terminal block: 16-pin terminal block System requirements... -
Page 8: Safety Regulations
Any type of modification has been made (e.g. exchanging components on the PCB boards, soldering work etc.). 3.3.3 Disposal When decommissioning, please comply with local regulations regarding the disposal of electronic devices (e.g. Electrical and Electronic Equipment Act). Operating Manual PSS u2 ES 16PT 0V 1003766-EN-03... -
Page 9: Function Description
Supply Supply Supply +24 V DC Fig.: Block diagram PSS u2 ES 16PT 0V Supply The module is supplied with voltage via the head module. Periphery supply The module provides 16 terminals with the 0V potential of the periphery supply. -
Page 10: Installation
5.1.1 Dimensions The dimensions include the backplane, electronic module and terminal block. 12,5 51,1 111,1 Fig.: Dimensions in mm, including backplane, electronic module and terminal block Operating Manual PSS u2 ES 16PT 0V | 10 1003766-EN-03... -
Page 11: Inserting And Removing An Electronic Module
Inserting an electronic module 1. Insert the electronic module into the suspen- sion lug on the back- plane. 2. Swivel the electronic module downwards until you hear it click into place. Operating Manual PSS u2 ES 16PT 0V | 11 1003766-EN-03... - Page 12 Installation 3. Insert the terminal block into the suspen- sion lug on the module. 4. Swivel the terminal block upwards until you hear it click into place. Operating Manual PSS u2 ES 16PT 0V | 12 1003766-EN-03...
-
Page 13: Removing An Electronic Module
2. Press the unlocking mechanism that is shown by the arrow and pull off the electronic module upwards. Operating Manual PSS u2 ES 16PT 0V | 13 1003766-EN-03... -
Page 14: Changing An Electronic Module During Operation
– Restart of the head module. After a restart, the system behaves as after a warm reset using a reset pushbutton (see operating manual of the head module, chapter “Reset pusbutton", section "Carrying out a warm reset (restart)"). Operating Manual PSS u2 ES 16PT 0V | 14 1003766-EN-03... -
Page 15: Wiring
The minimum cable cross section for field connection terminals on the terminal blocks is 0.15 mm (AWG26). The maximum cable cross section for field connection terminals on the terminal blocks is 1.5 mm with ferrules (AWG14) Use copper wiring. Operating Manual PSS u2 ES 16PT 0V | 15 1003766-EN-03... -
Page 16: Terminal Configuration
16: Output O15 10: Periphery supply 0 V 11: Periphery supply 0 V 12: Periphery supply 0 V 13: Periphery supply 0 V 14: Periphery supply 0 V 15: Periphery supply 0 V 16: Periphery supply 0 V Operating Manual PSS u2 ES 16PT 0V | 16 1003766-EN-03... -
Page 17: Operation
The status of the module is displayed via the "Module status" LED; this is signalled to the head module and any error is entered in the head module's diagnostic log. Display elements and messages Legend [1] Module status display Operating Manual PSS u2 ES 16PT 0V | 17 1003766-EN-03... - Page 18 – an error message is sent to the head module After the "too hot" message has been received, if the temperature drops back below the "too warm" threshold value, the module will switch to an error-free state. Operating Manual PSS u2 ES 16PT 0V | 18 1003766-EN-03...
-
Page 19: Technical Details
EN 60529 Housing IP20 Mounting area (e.g. control cabinet) IP54 Potential isolation Potential isolation between Periphery supply and module supply Type of potential isolation Functional insulation Rated surge voltage 2500 V Operating Manual PSS u2 ES 16PT 0V | 19 1003766-EN-03... - Page 20 Mechanical data Material Housing Mounting type plug-in Dimensions Height 110,8 mm Width 12,5 mm Depth 72,5 mm Weight 29 g Where standards are undated, the 2015-04 latest editions shall apply. Operating Manual PSS u2 ES 16PT 0V | 20 1003766-EN-03...
-
Page 21: Order Reference
Label holder for terminal block 328912 (10 pcs.) 61 x 11.5 mm, scope of supply: 10 pieces Codierelemente Produkttyp Merkmale Bestell-Nr. PSS u2 A CE E (10 pc.) Codierelemente für Elektronikmodule, 10 328860 Stück Operating Manual PSS u2 ES 16PT 0V | 21 1003766-EN-03... - Page 22 Order reference Backplanes Product type Features Order no. PSS u2 B 1 Backplane, 1 slot 328811 PSS u2 B 4 Backplane, 4 slots 328810 Operating Manual PSS u2 ES 16PT 0V | 22 1003766-EN-03...
- Page 23 We are represented internationally. Please refer to our homepage www.pilz.com for further details or contact our headquarters. Headquarters: Pilz GmbH & Co. KG, Felix-Wankel-Straße 2, 73760 Ostfildern, Germany Telephone: +49 711 3409-0, Telefax: +49 711 3409-133, E-Mail: info@pilz.com, Internet: www.pilz.com...
