Signal type setting

(Signal Type)

This function allows you to select the input signal
type Computer1, Computer2, DVI or HDMI.
Input Selectable
signal items
Computer Auto Input signals are automatically
1/2
recognized as RGB or
component.
RGB Set when RGB signals are
received.
Component Set when component signals
are received.

DVI

D. PC RGB Set when digital PC RGB
signals are received from a
computer.
D. PC Comp. Set when digital PC
component signals are
received from a computer.
D. VIDEO Set when digital video RGB
RGB signals are received from
video equipment.
D. VIDEO Set when digital video
Comp. component signals are
received from video equipment.

HDMI

Auto Input signals are automatically
recognized as RGB or
component.
RGB Set when digital video RGB
signals are received from
video equipment.
YCbCr4:4:4 Set when video signals
are received from video
equipment.
YCbCr4:2:2 Set when video signals
are received from video
equipment.

Color Space

This function allows you to select ITU (International
Telecommunication Union) standard color space.
Selectable
Description
Items
Auto Color Space is automatically selected.
ITU601 The ITU601 standard signal is
selected.
ITU709 The ITU709 standard signal is
selected.
This function allows you to select the black level
range (the range between the minimum and
maximum brightness) for the DVI or HDMI input
signals.
Description
signal
DVI
HDMI
The monitor can switch the on-screen display
language among 7 languages.
Menu operations

Dynamic Range

Input Selectable
items
Standard Reproduces black level range
normally.
Enhanced Reproduces black level range
more extensively.
Auto Looks at the AVI packet
information of the HDMI
signal and automatically
selects the dynamic range.
Standard Reproduces black level range
normally.
Enhanced Reproduces black level range
more extensively.
Selecting the on-screen display

language

(Language)
English
Deutsch
Español
Nederlands
Français
Italiano
Description
41
