Power Up the Device

Check power requirements in the table below:
Power Requirement for External Gateway
QuickServer Family
FS-QS-2X10-XXXX (Typical)
NOTE: These values are 'nominal' and a safety margin should be added to the power supply of
the host system. A safety margin of 25% is recommended.
Apply power to the QuickServer as shown below in
complies with the specifications provided in
•
The gateway accepts 12-24VDC or 24VAC on pins 4 and 5.
•
Frame GND should be connected.
Power to
Gateway
Power In (+)
Power In (-)
Frame Ground

Figure 6: Required Current Draw for the Gateway

Appendix
Gateway
Pin #
Pin 4
Pin 5
Pin 6

Figure 7: Power Connections

Page 11 of 34
QuickServer Start-Up Guide
Current Draw Type
12VDC
250mA
Figure 7. Ensure that the power supply used
C.5.
Pin
Assignment
V +
V -
FRAME GND
24V DC/AC
125mA
