EN User Manual | Dishwasher
EEG68600L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EEG68600L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Electrolux EEG68600L

Summary of Contents for Electrolux EEG68600L

  • Page 1 EN User Manual | Dishwasher EEG68600L...

  • Page 2: Table Of Contents

    WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    similar accommodation where such use does not exceed (average) domestic usage levels. • Do not change the specification of this appliance. • The operating water pressure (minimum and maximum) must be between 0.05 (0.5) / 1 (10) MPa (bar). • Follow the maximum number of 14 place settings. •...
  • Page 5 • Warning: this appliance is designed to be installed / connected to a grounding connection in the building. • Make sure that the parameters on the rating plate are compatible with the electrical ratings of the mains power supply. • Always use a correctly installed shockproof socket.

  • Page 6: Installation

    If the How to install your AEG/Electrolux plastic cover is damaged, contact the 60 cm Sliding Door Dishwasher Authorized Service Centre to replace it with the new one.
  • Page 7 5 mm ENGLISH...

  • Page 8: Product Description

    4. PRODUCT DESCRIPTION Ceiling spray arm Rinse aid dispenser Upper spray arm Detergent dispenser Lower spray arm Lower basket Filters Upper basket Rating plate Cutlery drawer Salt container Air vent 4.1 Beam-on-Floor • The red light flashes when the appliance has a malfunction.

  • Page 9: Control Panel

    5. CONTROL PANEL On/Off button / Reset button Option buttons (EXTRAS) Delay start button AUTO Sense program button Display MY TIME program selection bar 5.1 Display 5.2 ECOMETER The ECOMETER indicates how the programme selection impacts energy and water consumption. The more bars are on, the lower the consumption is.

  • Page 10: Programme Selection

    6. PROGRAMME SELECTION 6.1 MY TIME 6.2 AUTO Sense MY TIME selection bar allows to select a The AUTO Sense programme automatically suitable dishwashing cycle based on adjusts the dishwashing cycle to the type of programme duration. load. The appliance senses the degree of soil and the amount of dishes in the baskets.
  • Page 11 6.4 Programmes overview Programme Dishwasher Degree of Programme phases EXTRAS load soil Quick Crockery, cutlery Fresh • Dishwashing 50 °C • ExtraPower • Intermediate rinse • GlassCare • Final rinse 45 °C • ExtraHygiene • AirDry Not applicable • Prewash Pre-rinse Crockery, cutlery Fresh, lightly •...

  • Page 12: Basic Settings

    Consumption values Water (l) Energy (kWh) Duration (min) Programme 1)2) Quick 11.0 0.620 Pre-rinse 0.010 11.8 0.970 1h 30min 11.9 1.110 2h 40min 11.9 1.210 10.9 0.542 AUTO Sense 12.1 1.220 Machine Care 10.6 0.710 The pressure and the temperature of the water, the variations of the mains supply, the options, the quantity of dishes and the degree of soil can change the values.
  • Page 13 You can change the basic settings in setting The lights related to the Previous, OK and mode. Next are on. When the appliance is in setting mode, the How to change a setting bars of the ECOMETER represent available settings. For each setting, a dedicated bar of Make sure the appliance is in setting mode.
  • Page 14 1. Press and hold the on/off button until the negative effect on the washing results and on dishwasher is activated. the appliance. 2. Press and hold Previous and Next for 5 The higher the content of these minerals, the seconds. harder your water is.
  • Page 15 7.5 The rinse aid level Water softener level Amount of water (l) The rinse aid helps to dry the dishes without streaks and stains. It is automatically released during the hot rinse phase. It is possible to set the released quantity of rinse aid.

  • Page 16: Before First Use

    7.8 Key tones When AirDry opens the door, the display shows the remaining time of the running The buttons on the control panel make a click programme. sound when you press them. You can deactivate this sound. CAUTION! Do not try to close the appliance door 7.9 Latest programme selection within 2 minutes after automatic opening.

  • Page 17: Daily Use

    CAUTION! The compartment (B) is for rinse aid only. Do not fill it with detergent. CAUTION! Only use rinse aid designed specifically for dishwashers. 6. Turn the cap of the salt container clockwise to close the salt container. 1. Open the lid (C). 2.
  • Page 18 9.1 Using the detergent • The light related to the selected programme is on. • The ECOMETER indicates the level of energy and water consumption. • The display shows the programme duration. 2. Activate applicable EXTRAS if desired. 3. Close the appliance door to start the programme.
  • Page 19 Activating options often increases the Make sure that there is detergent in the water and energy consumption as well as detergent dispenser before you start a the programme duration. new programme. 9.5 How to start the AUTO Sense 9.9 Opening the door while the program appliance operates Opening the door while a programme is...

  • Page 20: Hints And Tips

    10. HINTS AND TIPS 10.1 General 10.2 Using salt, rinse aid and detergent Follow the hints below to ensure optimal cleaning and drying results in daily use and to • Only use salt, rinse aid and detergent protect the environment. designed for dishwasher.

  • Page 21: Care And Cleaning

    4. When the programme is completed, • Do not wash in the appliance items that adjust the water softener according to the can absorb water (sponges, household water hardness in your area. cloths). 5. Adjust the released quantity of rinse aid. •...
  • Page 22 11.5 Cleaning the filters 2. Press and hold simultaneously The filter system is made of 3 parts. for about 3 seconds. The indicators flash. The display shows the programme duration. 3. Close the appliance door to start the programme. When the programme is complete, the indicator is off.
  • Page 23 CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 11.6 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes. Clogged holes can cause unsatisfactory washing results.
  • Page 24 4. To install the spray arm back, press the spray arm upwards and simultaneously turn it counterclockwise until it locks into place. 11.7 Cleaning the upper spray arm We recommend to clean the upper spray arm regularly to prevent soil from clogging the holes.

  • Page 25: Troubleshooting

    2. Move the upper basket to the lowest level 5. To install the spray arm (C) back, insert to reach the spray arm more easily. the mounting element (B) in the spray 3. To detach the spray arm (C) from the arm and fix it in the delivery tube (A) by delivery tube (A), turn the mounting turning it clockwise.
  • Page 26 Problem and alarm code Possible cause and solution The appliance does not fill with wa‐ • Make sure that the water tap is open. ter. • Make sure that the pressure of the water supply is not too low. For this The display shows i10 or i11.
  • Page 27 Problem and alarm code Possible cause and solution Small leak from the appliance door. • The appliance is not levelled. Loosen or tighten the adjustable feet (if applicable). • The appliance door is not centred on the tub. Adjust the rear foot (if ap‐ plicable).
  • Page 28 12.2 The dishwashing and drying results are not satisfactory Problem Possible cause and solution Poor washing results. • Refer to "Daily use", "Hints and tips" and the basket loading leaf‐ let. • Use more intensive washing programme. • Activate the ExtraPower option to improve the washing results of a selected programme.

  • Page 29: Technical Information

    Problem Possible cause and solution Limescale deposits on the tableware, • The level of salt is low, check the refill indicator. on the tub and on the inside of the • The cap of the salt container is loose. door. •...

  • Page 30: Environmental Concerns

    rating plate of the appliance. Refer to the For more detailed information about the chapter "Product description". energy label, visit www.theenergylabel.eu. 14. ENVIRONMENTAL CONCERNS appliances marked with the symbol with Recycle materials with the symbol . Put the the household waste. Return the product to packaging in relevant containers to recycle it.
  • Page 32 117835870-A-172023...
