Summary of Contents for TRENDnet TV-IP1313PI
-
Page 2: Table Of Contents
Download sections of video ..................... 22 Contents Download snapshots ........................ 22 ...................... 1 Log ........................ 23 Product Overview ................ 4 Search for logs ......................... 23 Features ........................4 System Information .................... 24 Specifications ......................4 System Configuration .............. 25 Front View .............. Error! Bookmark not defined. Device Settings ..................... 25 Mounting .............. Error! Bookmark not defined. User Accounts ....................... 26 Connectors ............... Error! Bookmark not defined. Time Settings ...................... 26 Warnings ........................6 Daylight Savings .................... 27 Cautions ........................7 Live View Settings .................... 27 Plan for installation location ............ 7 Maintenance ... - Page 3 Privacy Mask ...................... 41 Video Recording .................... 42 Events ..................... 4 3 Motion Detection .................... 43 Video Tampering .................... 45 Notification ...................... 46 Snapshot ....................... 47 Email ........................ 48 Network Storage ................ 4 9 Network Storage .................... 49 Storage Management ................... 50 FTP Server ...................... 51 Regulations .................. 5 2 Federal Communication Commission Interference Statement ........ 52 RoHS ........................ 52 Europe – EU Declaration of Conformity ............... 53 Limited Warranty ................ 5 4 ...
-
Page 4: Product Overview
Features Save installation costs with Power over Ethernet (PoE) Outdoor Ready TRENDnet’s Indoor/Outdoor 5MP H.265 WDR PoE EXIR Network Camera, model TV‐IP313PI, provides day and night surveillance with a night vision Outdoor IP67 weather rated housing range of up to 80 meters (262 ft.). EXIR uses powerful energy efficient infrared LEDs to produce a balanced night vision illumination field and ... - Page 5 Adjustable 120dB WDR setting improves image quality and focus when a camera is exposed to high contrast lighting environments by enhancing the Drilling Template Mounting Screws dark areas of the image to make them more visible. Recording Flexibility Define custom schedules using continuous (24/7) and event based recording modes. Network Cable ONVIF/PSIA Waterproof Accessories ONVIF Profile S, Profile G and PSIA compliant Complimentary Software If any package content is missing or damaged, please contact the retail store, online retailer, or reseller/distributor from which the product was purchased. Complimentary pro‐grade software to manage TRENDnet cameras Complimentary Apps ® ™ Live video to a mobile device with free iOS and Android apps ...
-
Page 6: Warnings
Interface Warnings Serious injury or death may be caused if any of these warnings are neglected. Follow these safety guards to prevent serious injury or death. • If using the power adapter, please choose the power adapter that meets the safety extra low voltage (SELV) standard or IEC60950‐1 and Limited Power Source standard. • If the product does not work properly, please contact your dealer or the nearest service center. Never attempt to disassemble the camera yourself. Disassembling the product will void the warranty and may cause harm or injury. • To reduce the risk of fire or electrical shock, do not expose this product to rain or water. • The installation should be done by a qualified service person and should conform to all construction and electric regulations and other ... -
Page 7: Cautions
Cautions Plan for installation location Injury or equipment damage may be caused if any of these cautions are Viewing Angle neglected. Follow these precautions to prevent potential injury or material damage. The TV‐IP313PI is a bullet camera with a focused viewing angle that provides non‐distorted and detailed images. Choose the location where has good • Make sure the power supply voltage is correct before using the Camera. angle to shoot the image you expect to see. The motion detection area should • Do not drop the camera or subject to physical shock. also be considered when installing the camera. • Do not touch sensor modules with fingers. If cleaning is necessary, use Weather Conditions a clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an extended period of time, put on the lens cap to The TV‐IP313PI is a small bullet camera, which fits most installations indoor ... -
Page 8: Hardware Installation
• Sunlight: Avoid direct sun light exposure. Direct sun light will damage Hardware Installation the image sensor. If sunlight is necessary for your viewing purposes, provide protection for the image sensor. Cabling • Lighting: Consider installing your camera faces the same direction of It’s recommended that the wiring the cable in your home or office by a the light sources. Shooting images with top‐down position outdoor or professional. If you already have the cable deployed, make sure the cable and next to the existing light source are good choices. Avoid the light source the connectors meet the category 5 Ethernet cable standards. At least 2 pairs if it creates a shade that darkens the viewing area. of twisted lines are required for power and data. Poor cable quality may cause unexpected problems. Testing your cable or running a new cable is suggested for new camera installation. ... -
Page 9: Mount Your Camera
Loosen the lock ring and then adjust the camera position. Tighten the lock Mount your camera ring when you setup the camera position. Drill the screw holes and the cable hole if necessary with the drill template Loosen No.1 lock screw to adjust the tilt angle [0 ° to 100°]. comes with the package. Loosen No.2 lock screw to adjust the pan angle [0° to 360°]. Loosen No.3 lock screw to rotate the camera [0° to 360°]. Tighten the lock screws. Fix the mounting base on the ceiling or the wall with the screws that come with the package. Route the cables to the cable hole. ... - Page 10 Memory Card Installation 1. Unscrew the cover to expose the memory card slot. 2. Expose memory card slot and insert the memory card. ...
-
Page 11: Setup Your Camera With Camera Utility
TRENDnet User’s Guide TV‐IP313PI 4. This will also require you to Install WinPcap program if you don’t have Setup Your Camera with Camera Utility this installed before, please follow the on screen Instructions to Install It. 1. Please download the utility at http://www.trendnet.com/camerautility 2. Extract the downloaded file and double click on the camera utility file to install 5. Restart the computer after the Installation. 3. Last, click Next to finish the installation. © Copyright 2017 TRENDnet. All Rights Reserved. 11 ... -
Page 12: Access Your Camera With The Web Browser
TRENDnet User’s Guide TV‐IP313PI Access your Camera with the Web Browser 6. After the computer has restarted, double click on the Camera Utility icon to launch the program. Logging‐in to the Camera for the First Time (Windows) 1. Find the camera from the Utility and double click on the IP address to open the browser. 7. Find the camera you would like to access and configure then double click on the IP address. 2. Activate the admin User Account by entering your desired password, and then click OK. 8. Continue to the next section Access your Camera with the Web Browser for detail configurations of the camera. © Copyright 2017 TRENDnet. All Rights Reserved. 12 ... - Page 13 TRENDnet User’s Guide TV‐IP313PI 3. For Chrome and Firefox, the camera will go to Live stream directly but for 5. Permission request may show up depends on the Internet security IE and Safari, plugin install is required. settings on your computer. Click Yes to install the plug‐ in. 6. Click Next to install the plug‐in. 4. Download the plug‐in to your computer and then and close your browser. Launch the plug‐in installation to install the plug‐in. (For Internet Explorer) ...
- Page 14 TRENDnet User’s Guide TV‐IP313PI 7. Click Finish to finish the installation. 9. Refresh the browser and the Live View page will show up and begin streaming video. 8. Open the browser and login again, enter the user name admin and new password again to start secured session. © Copyright 2017 TRENDnet. All Rights Reserved. 14 ...
-
Page 15: Logging-In To The Camera For The First Time (Os X)
TRENDnet User’s Guide TV‐IP313PI Logging‐in to the Camera for the First Time (OS X) 3. The camera management page will detect if you installed the camera webcomponent plug‐in or not. Click the link to download the plug‐in from 1. Open the web browser on your computer. In the address bar, enter the the camera. default IP address of the camera 192.168.10.30. If the camera is Note: Internet connection is required to download the plug‐in. If you do not have connected to a router/network, please use the Windows Camera Utility Internet access, you can find the plug‐in on the CD comes with the package under to find the exact IP address. /Mac folder. ... - Page 16 TRENDnet User’s Guide TV‐IP313PI 5. Go to the Finder and navigate to the Download folder. Command‐Click 7. Click Continue to install the plug‐in. the WebComponents.pkg and then click Open. (If you are install the plug‐ in from the CD when you don’t have internet connection, just browse to /Mac folder and double click the WebComponents.pkg file.) 8. Select a destination to install the plug‐in. Then click Continue. 6. Click Open with Installer to start installation. © Copyright 2017 TRENDnet. All Rights Reserved. 16 ...
- Page 17 TRENDnet User’s Guide TV‐IP313PI 9. Use the default location and click Install. 11. Installation will process automatically. 12. Click Close to exit the installation. 10. Enter your password and click Install Software © Copyright 2017 TRENDnet. All Rights Reserved. 17 ...
- Page 18 TRENDnet User’s Guide TV‐IP313PI 13. Open the browser and login again with the default IP 192.168.10.30 or the IP that was dynamically assigned by your router. Enter the user name, admin, and the default password, admin, and then click OK. 14. The Live View page shows up and the video starts to stream. © Copyright 2017 TRENDnet. All Rights Reserved. 18 ...
-
Page 19: Live View
TRENDnet User’s Guide TV‐IP313PI Live View After you log‐in into the camera management page, you’ll see the Live View page. Snapshot Click this icon to take a video snapshot. Zoom Click once to enable zoom. When enabled, click and drag the area on the picture to zoom in. Right click to resume 100% zoom. Click the icon again to disable zoom. The zoom function works in full screen mode as ... -
Page 20: Playback
TRENDnet User’s Guide TV‐IP313PI Playback Time Line There is a play back head in the center of the time line represented in a yellow You can playback the video recording on the network storage and download vertical line. To look for a specific video recording, move the time line by the video clip and snapshots to your local computer. clicking and dragging it. If the recording is short, zoom in by clicking button. Click to zoom out the time scale. If you know the exact time of ... -
Page 21: Playback
TRENDnet User’s Guide TV‐IP313PI Playback Slice images from video playback Use playback controls to play back the video recording. You can take snapshots from playback video or make new video clips from the video you are playing back. Click this button to play the video. Click this button to enable zoom. Then click and drag on Click this button to pause video playback. the video to define the area you want to zoom in. Click Click this button to stop playback. again to get back to 100% zoom. Click this button increase playback speed*. Double click to show video in full screen and press ESC Click this button decrease playback speed*. on keyboard to exit full screen mode. Click to playback video frame by frame. Click again for Click this button to disable zoom. ... -
Page 22: Download Sections Of Video
TRENDnet User’s Guide TV‐IP313PI Download sections of video Download snapshots To save complete video sections or snapshots, you can download the files directly. Click button to list snapshots to download Click button to download video sections. Check the time of the recording, select the videos you want to download, and Select the type of event that triggered the snapshots. then click Download. Choose the Start Time and End Time. Then, click Search ... -
Page 23: Log
TRENDnet User’s Guide TV‐IP313PI Log Search for logs Click the type of log and then the Start Time and End Time. Click Search to The log of the TV‐IP313PI will be saved on the network storage. You can start searching. search the relevant records and save to your local computer. (See Network Storage on page 49 to setup the storage.) Click First Page, Prev Page, Next Page, and Last Page to show the logs. Click Save Log to save the logs to your computer. © Copyright 2017 TRENDnet. All Rights Reserved. 23 ... -
Page 24: System Information
TRENDnet User’s Guide TV‐IP313PI System Information Network Information System Information page shows the camera’s basic information. IP Address: IP address of the TV‐IP313PI Subnet Mask: Network range of IP address Default Gateway: The default route going from the TV‐IP313PI subnet. Primary DNS: Primary DNS server address Secondary DNS: Secondary DNS server address Basic Information Device Name: Human readable device name for easy identification. Firmware Version: Firmware version MAC Address: The MAC address of Ethernet Interface System Time: The system time setup in the camera. Keeping this time correct is important for recording, scheduled control and logging accurately. Device Name: Human readable device name for easy identification. © Copyright 2017 TRENDnet. All Rights Reserved. 24 ... -
Page 25: System Configuration
TRENDnet User’s Guide TV‐IP313PI System Configuration Authentication RTSP: TV‐IP313PI’s video stream can be accessed with RTSP, Real Time Streaming Protocol. Only the Device Settings administrator and users can view this video stream Un‐checking this box will allow everyone access to this video Setup your camera name and location for easy identification. This camera stream without authentication. Default: Checked. name will also be recognized by other network camera software as the name of this camera. OSD, On Screen Display, camera name is referring to this setting as well. Service ... -
Page 26: User Accounts
TRENDnet User’s Guide TV‐IP313PI User Accounts Time Settings You can setup up to 16 user accounts to access the camera’s video stream The accuracy of the system clock is important for scheduling and accurate with a web browser or real time video stream (RTSP). Only one administrator logging. You can synchronize the system time with your computer, or account can be setup to configure the TV‐IP313PI and cannot be deleted. automatically check the time accuracy with a network time server (NTP ... -
Page 27: Daylight Savings
TRENDnet User’s Guide TV‐IP313PI Daylight Savings Live View Settings Setup daylight savings. Setup the live view video quality, file size and file saving directories. Automatic Update Enable DST: Check this box if your time zone has daylight savings. Start Time: Enter the date that daylight savings starts End Time: Enter the date that daylight savings ends DST Bias Enter how much time the daylight saving adjusted by daylight savings. Live View Parameters Click Save to save the changes Live View Configure the buffer size for live view video stream. With Buffer: low buffer size setting, you can get real‐time video ... -
Page 28: Maintenance
TRENDnet User’s Guide TV‐IP313PI Maintenance Record File Settings Record file size: This size of live view video recording. You can choose 256MB, 512MB, or 1GB a file. Smaller file size is good You can restart, load camera settings and upgrade the camera firmware on for many short recordings. this page. Save record Click Browse and then choose a new destination if you files to: want to save the file somewhere else. Save Click Browse and then choose a new destination if you downloaded want to save the file somewhere else. files to: Picture and Clip Settings Save snapshots Click Browse and then choose a new destination if you in want to save the file somewhere else. live view to: Save snapshots Click Browse and then choose a new destination if you when playback want to save the file somewhere else. to: Save clips to: Click Browse and then choose a new destination if you want to save the file somewhere else. Click Save to save the changes ... -
Page 29: Network Settings
Upgrade. Status: Shows the status in firmware upgrade. TRENDnet may periodically release firmware upgrades that might add features or fix problems associated with your camera. To find out if there is a firmware upgrade available for your device, please check your TRENDnet model and version using the link. http://www.trendnet.com/downloads/ 1. If a firmware upgrade is available, download the firmware to your computer. 2. Unzip the file to a folder on your computer. ... -
Page 30: Port
TRENDnet User’s Guide TV‐IP313PI Port Network Interface MAC Address: Click this button to reboot this camera. You can change the service port numbers of TV‐IP313PI and enable/disable Duplex and Choose one of the Ethernet duplex and speed to RTSP or HTTPS services. Speed: match your network. Default: auto. MTU: Maximum transmission unit. The maximum field size in the Ethernet packet. Primary DNS: Enter your first IPv4 or IPv6 DNS server address Secondary DNS: Enter your second IPv4 or IPv6 DNS server address IPv4 DHCP: Check this box if the IP address is assigned by DHCP server. Port Numbers IPv4 Address: The IPv4 dynamic or static address HTTP Port: The default web access port. You can change the port Subnet Mask: Network range of the subnet ... -
Page 31: Ddns
TRENDnet User’s Guide TV‐IP313PI DDNS PPPoE Dynamic Domain Name Service, DDNS, allows you to find your camera from Setup PPPoE (ADSL) connection to connect your camera with your ISP, the Internet with an easy to remember domain name. Internet Service Provider. DDNS PPPoE (ADSL) Enable DDNS: Check this box to enable DDNS Service. Enable PPPoE: Check this box to enable PPPoE connection. DDNS Type: Select a DDNS service provider. Dynamic IP: The IP address assigned by ISP User Name: Enter the account name. Password: Enter the password. Confirm: Enter the password again. Server Address: Enter the DDNS server address. ... -
Page 32: Snmp
TRENDnet User’s Guide TV‐IP313PI SNMP SNMP V1/V2 Enable SNMPv1: Check this box to enable SNMP v1 management. SNMP Settings allows you to assign the contact details, location, community Enable SNMPv2c: Check this box to enable SNMP v2c management. name and trap settings of SNMP. This is a networking management protocol Read SNMP Specify the password to access the SNMP Community: community for read only access. used to monitor network‐attached devices. SNMP allows messages (called Write SNMP Specify the password for access to the SNMP protocol data units) to be sent to various parts of a network. Upon receiving Community: community with read/write access. these messages, SNMP compatible devices (called agents) return data stored Trap Address: Specify the IP address for the SNMP trap in their Management Information Bases. community. Trap Port: Specify the port number for the SNMP trap community. Trap Community: Specify the name of SNMP trap community. ... - Page 33 TRENDnet User’s Guide TV‐IP313PI 802.1X Setup 802.1X for remote authentication service. Authentication Choose the authentication method to verify the Algorithm: source of information: MD5 or SHA. Authentication Specify the authentication password between 8 to 32 Password: letters. Private‐key Choose the privacy key to encrypt SNMP messages: Algorithm: DES or AES. Private‐key Specify the privacy key between 8 to 32 letters. Password: SNMP Other Settings SNMP Port: SNMP service port number. Click Save to save the changes 802.1X Authentication Enable IEEE Check this box to enable 802.1X authentication ...
-
Page 34: Ip Address Filter
TRENDnet User’s Guide TV‐IP313PI IP Address Filter Quality of Service (QoS) Set up a list of clients allow only the clients on the list to access this camera Setup traffic prioritization tags the video packets to go through network or to reject clients on the list from access this camera. switches and routers with assigned priority. You can set the Differentiated Services Code Point (DSCP) bits on outgoing data streams. The QoS capable network device will forward different data in different priorities. The meaning of the value is different in different DiffServ domains. Consult your network manager for the setup details. IP Address Filter Enable IP Check this box to enable IP address filtering service. Address Filter: IP Address Filter Choose Forbidden to ban the listed IP addresses or Type: Allowed to allow listed host to access this camera. Add: Click Add to add a user account Modify: To modify an entry on the list, highlight the entry by IP Address Filter clicking on it. Then, click the Modify button. ... -
Page 35: Upnp
TRENDnet User’s Guide TV‐IP313PI UPnP Video Settings Universal Plug‐and‐Play is a device discovery protocol set. It allows your Video Format camera to easily be found, for example, on a Windows operation system. UPnP Enable UPnP: Check this box to enable UPnP connection. Friendly Name: The name that will be appeared when searched. Port Mapping Enable Port Check this box to enable UPnP connection. Mapping: Port Mapping Choose Manual or Auto port mapping. Mode: External Port: Choose the port number for mapping. Click Save to save the changes ... -
Page 36: Display Settings
TRENDnet User’s Guide TV‐IP313PI Display Settings Resolution: H.264/H.265 MJPEG Adjust video image quality, lightness, and color settings here. Bitrate Type: Choose between variable bit rate or constant bit (Auto‐Switch Mode) rate for video compression. The default is variable rate. Video Quality: Choose the video quality. The default is medium quality. Frame Rate: Choose the capturing frame rate. The default value is 30 frames per second. Reduce the frame rate to reduce the capture file size. Max. Bitrate: Choose the maximum video sampling bit rate. Default: 2048 I Frame Interval An I Frame is a frame that records a complete picture. Frames between I frames, (P frame or B frame) only records the image differences between two frames. Choose the I Frame Interval here. The default is 60. Click Save to save the changes Sub stream can be used for lower resolution needed application, for example mobile app streaming or NVR streaming. Brightness: Use the slider or enter a number (0‐100) to adjust the image brightness. Default: 50 Third stream is used for Live view only, it has resolution limitation on Chrome, ... - Page 37 TRENDnet User’s Guide TV‐IP313PI Light sensitivities Iris Mode: This camera uses fixed lens, therefore the Iris function is not configurable. Exposure Time: Adjust this value for exposure time for each picture. You can choose a value between 1/3 second to 1/100,000 second. The default value is 1/30 second exposure time for each picture. Gain This value be manually configured from 0 to 100. The bigger the value is, the brighter would the image be, and the noise would also be amplified to a larger extent. Day/Night Choose whether you want the Switch: camera to be set to the day mode (color video) or night mode (IR enhanced black/white video). You can manually set it to day mode or night mode, adjust by lighting (Auto), or pre‐define schedule. Auto: Sensitivity: The light sensor sensitivity. Switch Time: The time delayed to switch between modes. Longer switch time can prevent unnecessary mode flipping if an object is blocking the light source temporarily. Range: 5‐120 seconds, default: 5 seconds. ...
- Page 38 TRENDnet User’s Guide TV‐IP313PI Schedule: White Balance: Use quick selection or enter the time down below. Click OK to confirm the time you want to set. Choose a color temperature as the white color and compensate the color on the whole image. Digital Noise Choose the mode of noise reduction. Start Time: The start time for day mode. Reduction: Stop Time: The start time for day mode. Normal Mode Smart Set the supplement light as ON, and Auto and Manual Noise Reduction Level: Adjust the effect of digital Supplement are selectable for light mode. noise reduction. Range: 0‐100%, default : 100% Light Select Auto, and the supplement light changes Expert Mode according to the actual luminance. Space DNR Level: Adjust the special digital noise ...
- Page 39 TRENDnet User’s Guide TV‐IP313PI (Scheduled‐Switch mode) Rotate To make a complete use of the 16:9 aspect ratio, you can enable the rotate function when you use the camera in a narrow view scene. When installing, turn the camera to the 90 degrees or rotate the 3‐axis lens to 90 degrees, and set the rotate mode as on, you will get a normal view of the scene with 9:16 aspect ratio to ignore the needless information such as the wall, and get more meaningful information of the scene. Scene Mode Choose the scene as indoor or outdoor according to ...
-
Page 40: On Screen Display Settings
TRENDnet User’s Guide TV‐IP313PI To configure this section On Screen Display Settings 1. Click the calendar icon to select the start time and the end time. Display the camera name and the time the video is shooting on the screen • The start time and end time refer to the valid time for day mode. • The time period can start and end on two days in a row. For example, if you set start time as 10:00 and end time as 1:00, the day mode will be activated at 10 o'clock in the morning and stopped at 1 o'clock early in the next morning. 2. Click Working mode to configure common parameters applicable to the day mode and night mode. 3. Click Day tab to configure the parameters applicable for day mode. 4. Click Night tab to configure the parameters applicable for night mode. Note: The settings are saved automatically when parameters are changed. Display Check this box to display the product name that was Name: setup in the device settings Display Date: Check this box to display system time. Display Week: Check this box to display time of the week. Time Format: Select 12 or 24‐hour time format. Date Format: Select the date format ... -
Page 41: Text Overlay
TRENDnet User’s Guide TV‐IP313PI Text Overlay Privacy Mask Display extra information on the screen over the image. Create a masking area to keep your privacy. You can create up to four independent masking areas by clicking and dragging on the screen. Check Box: Check this box to enable text overlay. Text Field: Enter the text you want to display. You can enter your Enable Privacy Mask: Check this box to enable privacy masking. local language if you want. The text field allows Stop Drawing: Click this button to stop drawing. ... -
Page 42: Video Recording
TRENDnet User’s Guide TV‐IP313PI Video Recording Edit: Click Edit to edit the recording schedule. The Edit Schedule window will pop up. 1. Select day of the week you want to edit. 2. Select All Day or Customized schedule of the day. 3. Set the time period and the event you want to trigger the video recording Pre‐record: Recording time before trigger event. continuous (always recording) or motion Post‐record: Recording time after trigger event. detection. Overwrite: Select Yes to allow older recordings to be 4. Click Select All or the weekday you want overwritten. to have the same schedule on different Enable Record Check this box and then click Save to enable video day. Schedule: recording. 5. Click another day of the week by clicking on its tab to set the next schedule. Click Click Save to save the changes ... -
Page 43: Events
TRENDnet User’s Guide TV‐IP313PI Events Motion Detection Set up how the motion detection event will be triggered and what actions will be triggered. Enable Check this box to enable motion detection. Click Save Motion to save the choice. Detection: Enable Check this box to enable motion tracking. Motion Motion tracking is a dynamic display that shows the current Tracking: status of motion detection. The motion tracking is ... - Page 44 TRENDnet User’s Guide TV‐IP313PI Draw Area: Click Draw Area button to start drawing. Click and 3. Set the time period and the event you want drag on the area you want to set up the motion to trigger the video recording continuous detection. You can draw up to 8 different areas. Click (always recording) or motion detection. Stop Drawing to stop drawing motion detection 4. Click Select All or the weekday you want to areas. have the same schedule on different day. ...
-
Page 45: Video Tampering
TRENDnet User’s Guide TV‐IP313PI Video Tampering This is to detect if the camera has been tampered with and surveillance is compromised. You can set up tamper proof notifications to alert the system manager to check the camera. Enable Check this box to enable tamper detection. Click Save Tamper to save the settings. Detection: Draw Area: Click Draw Area button to start drawing. Click and drag on the area you want to set up the tamper detection. You can setup only one area for tamper detection. Click Stop Drawing to stop drawing motion detection areas. The gray block represents the detection area. Sensitivity: Move the slider to adjust detection sensitivity. Clear All: Click this button to clear all the set up areas. © Copyright 2017 TRENDnet. All Rights Reserved. 45 ... -
Page 46: Notification
TRENDnet User’s Guide TV‐IP313PI Notification Arming Schedule Edit: Click Edit to edit the recording schedule. The Edit Schedule window will pop up. Provide notifications for other system events, set up your notifications here. 1. Select day of the week you want to edit. 2. Select All Day or Customized schedule of the day. 3. Set the time period and the event you want to trigger the video recording continuous (always recording) or motion detection. Notification 4. Click Select All or the weekday you want to Notification First, choose the exception type, and then choose have the same schedule on different day. Type: the corresponding action. 5. Click another day of the week by clicking on Send Email: Check this box to send an e‐mail notification when ... -
Page 47: Snapshot
TRENDnet User’s Guide TV‐IP313PI Snapshot Event triggered Enable: Check this box to take snapshots when an event is occurred. You can set up your camera to continuously taking snapshots or taking Format: Save snapshots in JPEG format snapshots only when events happening. Resolution: Uses the same resolution set in Video Format for the snapshot resolution. Quality: Choose a compression quality for snapshot. Interval: State the time interval between this series of ... -
Page 48: Email
TRENDnet User’s Guide TV‐IP313PI Email Enable SSL: Check this box if your service provider requires a SSL secured connection. Attach Check Attach Image if you want to send a snapshot Set up email accounts for notifications. Image/Interval: image with the email notification and select the interval of snapshots in seconds. Authentication: Check this box if your server requires a password in order to send email. Most email servers require authentication when sending an email. User name: Enter the user name of outgoing email account Password: Enter the password Confirm: Enter the password again to confirm that the ... -
Page 49: Network Storage
TRENDnet User’s Guide TV‐IP313PI Network Storage No: The sequential number of the network storage. Network Storage Type: The type of storage. Server Enter the IP address of your network storage. Address: Network Storage must be setup before it can be managed. For storage File Path: Enter the shared folder as file path for network storage. You management, please refer to the next section. can create a folder under the shared folder and make it a ... -
Page 50: Storage Management
TRENDnet User’s Guide TV‐IP313PI Storage Management Format: Select a network storage volume and then click Format to format your network storage. This action will format the network volume (shared folder) for video recording. Network Storage must be setup before it can be managed. To setup storage, Placeholder files (formatting files) will be created to make ... -
Page 51: Ftp Server
TRENDnet User’s Guide TV‐IP313PI FTP Server Enable Snapshot Check this box if you want to store snapshots on the to FTP: FTP. Server Address: Enter the FTP server IP address. Port: Enter the service port number of the FTP server. User Check Anonymous if the FTP server does not require Name/Anonymous authentication. Enter the User Name if the FTP server requires authentication. Password: Enter the password of the FTP account. Confirm: Enter the password again to make sure the password was entered correctly. Directory When saving snapshots on an FTP server, they can Structure: be saved in a single place or organized with meaningful directory names. Save in root directory: You can choose to store all files in the same folder of FTP login. Save in directory: Structure your folders with camera name or IP address. Directory: Use Camera Name: Use the camera name to organize the saved files. Use Camera IP: Use the camera IP address to ... -
Page 52: Regulations
TRENDnet User’s Guide TV‐IP313PI IMPORTANT NOTE: Regulations FCC Radiation Exposure Statement: Federal Communication Commission Interference Statement This equipment complies with FCC radiation exposure limits set forth for an This equipment has been tested and found to comply with the limits for a uncontrolled environment. This equipment should be installed and operated Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are with minimum distance 20cm between the radiator & your body. designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio This transmitter must not be co‐located or operating in conjunction with any frequency energy and, if not installed and used in accordance with the other antenna or transmitter. instructions, may cause harmful interference to radio communications. The availability of some specific channels and/or operational frequency ... -
Page 53: Europe - Eu Declaration Of Conformity
TRENDnet User’s Guide TV‐IP313PI Europe – EU Declaration of Conformity ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 2004/108/EK, 2006/95/ΕΚ και. Français [French] Par la présente TRENDnet déclare que l'appareil TV‐IP313PI est This device complies with the essential requirements of the Directive conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 2004/108/CE, 2006/95/CE et. 2004/108/EC and 2006/95/EC. The following test methods have been applied Italiano[Italian] Con la presente TRENDnet dichiara che questo TV‐IP313PI è in order to prove presumption of conformity with the essential requirements conforme ai requisiti essenziali ed alle altre disposizioni of the Directive 2004/108/EC and 2006/95/EC and other relevant provisions pertinenti stabilite dalla direttiva 2004/108/CE e 2006/95/CE. Latviski [Latvian] AršoTRENDnetdeklarē, ka TV‐IP313PI atbilstDirektīvas under our sole responsibility. 2004/108/EK un 2006/95/EK būtiskajāmprasībām un citiemar Safety /EMC to saistītajiemnoteikumiem. Lietuvių Šiuo TRENDnet deklaruoja, kad šis TV‐IP313PI atitinka esminius EN 60950‐1: 2006 + A11: 2010 + A12: 2011 + A2: 2013 [Lithuanian] reikalavimus ir kitas 2004/108/EB ir 2006/95/EB Direktyvos ... -
Page 54: Limited Warranty
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET ALSO products that are replaced become the property of TRENDnet. Replacement products EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN may be new or reconditioned. TRENDnet does not issue refunds or credit. Please CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, contact the point‐of purchase for their return policies. INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE TRENDnet shall not be responsible for any software, firmware, information, or ... - Page 55 ...
