CyberPower P600WSURC1 User Manual

CyberPower P600WSURC1 User Manual

6-outlet & 2 usb surge protector wall tap

Advertisement

Quick Links

6-Outlet & 2 USB
6-Outlet & 2 USB
Surge Protector Wall Tap
Surge Protector Wall Tap
P600WSURC1
P600WSURC1
3
USER MANUAL
Copyright © 2018 Cyber Power Systems (USA), Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the CyberPower P600WSURC1
Surge Protector Wall Tap. This manual explains the
features and operation of the P600WSURC1. Please
take a few moments to read this manual.
FEATURES
1. Surge Protected Indicator
Illuminated when the surge protection feature is
working properly.
2. Ground Indicator LED
Illuminated when the Ground protection feature is
working properly.
3. Pivoting Standard Grounded Outlets (6)
Pivoting outlets for ease of use and convenience,
fits standard-sized plugs.
4. USB Charging Ports (2)*
Connect and charge up to two (2) USB devices
using the surge protected USB charging ports.
1
*USB outlets cannot be used as a USB hub. This
device does not transfer data.
2
SPECIFICATIONS
• Model Number: P600WSURC1
• Outlets: 6 Standard Grounded Outlets, 2 USB
Charging Ports
• Surge Protection: 1,200 Joules
3
• Electrical Rating: 125 V/15 A/1875 W
• USB Charging Rating: 5 V/2.4 A total
• UL Clamping Voltage: UL 1449 4th/400 V (H-N,
N-G), 500 V (H-G)
• Maximum Peak Current: 60,000 A
4
• 3 AC Lines Protected: H-N: 30,000 A, H-G: 15,000
A, N-G: 15,000 A; (The maximum surge possible on
household Wiring is 6,000 volts)
• Response Time: Less than 1 nanosecond
• Attenuation: Up to 32 dB
• EMI/RFI Filtration: 150 kHz to 100 MHz
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use
only in dry locations and only indoors. DO NOT plug
into another relocatable power tap. DO NOT "daisy
chain" surge protectors. DO NOT use with any
aquarium equipment. DO NOT use if properly
grounded outlets are not available. DO NOT install
this device if there is less than 10 meters (30 feet) or
more of wire between the electrical outlet and
electrical service panel. DO NOT use for medical or
life support equipment. This device features an
internal protection that will disconnect the surge
protective component at the end of its useful life, but it
will maintain unprotected power to the load.
TROUBLESHOOTING
▪ If the grounded indicator does not light when you
plug in the surge protector, move the surge
protector to a di erent grounded three-prong AC
outlet. If it still does not light, return the product to
the retailer for assistance. If the surge protector
appears to be working properly, your outlets may
not be properly grounded and need to be repaired
by a professional electrician. If the grounded
indicator turns o after a period of use, the surge
protection has been depleted. Replace your
surge protector.
▪ If the protected indicator does not light, the surge
protector's AC lines are no longer protected from
surge. The surge protector may have received a
power surge or spike beyond its specified limits
that overloaded the protection circuitry and
rendered it inactive. The surge protector has
protected your connected equipment as designed,
but it will not protect against future surges, and
spikes. It should be replaced.
TECHNICAL SUPPORT
Please contact our Tech Support Department
with installation, troubleshooting, or general
product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation:
1
Monday – Friday 7:00am – 6:00pm CST
2
