CyberPower P403URC1 User Manual

6-Outlet Surge Protector 6-Outlet Surge Protector
(4 AC & 2 USB ports) (4 AC & 2 USB ports)
P403URC1 P403URC1
2.1A USB
USER'S MANUAL
Copyright © 2017 Cyber Power Systems, Inc. All rights reserved.
CONGRATULATIONS ON YOUR PURCHASE
Thank you for selecting the CyberPower P403URC1
Surge Protector. The information contained on this
package explains the features and operation of the
P403URC1. Please take a few moments to read
this package.
FEATURES
1. ON/OFF Reset Control Switch and Circuit Breaker
Controls power to all outlets. The switch is also a 15A
breaker. When an overload occurs, it will
automatically switch o . To resume operation, ensure
the overload condition is removed and reset the
surge protector by switching the unit ON.
2. Four Standard Outlets
3. USB Charging Ports*
Connect and charge up to two (2) USB devices using
the surge protected USB charging ports.
*USB outlets cannot be used as a USB hub. This
device does not transfer data.
SPECIFICATIONS
• Model Number: P403URC1
• Outlets: 4 Standard Outlets, 2 USB Charger Ports
• Surge Protection: 500 Joules
• Electrical Rating: 125V/15A/1875W
• UL Clamping Voltage: UL 1449 3rd/800V (L-N)
• Maximum Peak Current: 15,000A
• 1 AC Lines Protected: L-N: 15,000A
(The maximum surge possible on household wiring is
6,000 volts)
• Response Time: Less than 1 nanosecond
• USB Charger Rating: 5V/2.1A total
• Circuit Breaker: Resettable 15 Amp
1
CAUTION
TO REDUCE THE RISK OF ELECTRIC SHOCK - Use only in
dry locations and only indoors. DO NOT plug into another
relocatable power tap. DO NOT "daisy chain" surge
protectors. DO NOT use with any aquarium equipment.
DO NOT use if properly grounded outlets are not
available. DO NOT install this device if there is not at least
10 meters (30 feet) or more of wire between the electrical
outlet and electrical service panel. This device features an
internal protection that will disconnect the surge
protective component at the end of its useful life, but will
maintain power to the load – now unprotected.
TROUBLESHOOTING
If the ON/OFF is switched o , the 15A circuit breaker may
have tripped. Examine your connected equipment and
remove the device that is overloading the circuit. Then,
turn the ON/OFF switch back to RESET.If the Protected
indicator does not light, the surge protector's AC line is no
longer protected from surge. Replace the surge protector.
The surge protector may have received a power surge or
spike beyond its specified limits that overloaded the
protection circuitry and rendered it inactive. The surge
protector has protected your connected equipment but it
will not protect against future surges and spikes.
TECHNICAL SUPPORT
Please contact our Tech Support department with
installation, troubleshooting, or general product questions.
• Phone: 1-877-297-6937
• Email: tech@cpsww.com
• Hours of Operation: Monday – Friday, 7:00AM – 6:00PM
CST
LIMITED WARRANTY AND CONNECTED EQUIPMENT
GUARANTEE
Read the following terms and conditions carefully before
using the CyberPower P403URC1 (the "CPS Product"). By
using the CPS Product, you consent to be bound by the
terms and conditions of this Limited Warranty and
Connected Equipment Guarantee (together referred to as
this "Warranty").
IF YOU DO NOT AGREE TO THE TERMS AND
CONDITIONS OF THIS WARRANTY, YOU SHOULD
RETURN THE PRODUCT FOR A FULL REFUND PRIOR TO
USING IT.
2
