- Page 1 Roger Access Control System ME-14-40VA metal enclosure User Manual Product version: 1.0 Document version: Rev. A...
- Page 2 2017-10-04 ESIGN AND APPLICATION ME-14-40VA metal enclosure is dedicated to installation of RACS 5 modules and devices which require DIN rail and 7Ah backup battery. The enclosure is equipped with DIN rail, 18VAC/40VA transformer and tamper contact. The enclosure front panel is attached with screws. ME-14 is made of white powder coated stainless metal sheet.
- Page 3 ME-14-40VA User manual.doc 2017-10-04 Fig. 1 Arrangement of ME-14-40VA internal components PECIFICATION Parameter Value TRP 40 transformer 16/18VAC; 40VA Transformer standard EN 61558-2-6 Tamper contact NO/NC; 50mA/50VDC DIN rail 1 x 250mm Metal sheet DC01; 0,7mm; anti-corrosion protection Colour RAL9003...
- Page 4 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
