- Page 1 Roger Access Control System ME-2 and ME-2-D v1.0 Metal Enclosures Document version: Rev. B...
- Page 2 12V/17Ah. ME-2-D set additionally includes 13.8VDC/3.5A buffer power supply unit and fuse block. Basically, ME-2 was designed for RACS system however, it can be also used with 3rd party devices. The enclosure can accommodate access controllers, network controller, communication interfaces and I/O expanders in various arrangements.
- Page 3 2. I NSTALLATION ME-2 should be installed on a vertical part of construction in location protected against moisture and dust, ensuring nominal operating conditions required for the enclosure and internal devices. The 230VAC power supply cable must enter the enclosure through the dedicated cable bushing.
- Page 4 ME-2 and ME-2-D Metal Enclosures v1.0 Rev. B.doc 2016-10-08 Fig. 2 Inside view of ME-2-D set with buffer PSU, fuse block and optional 12V/17Ah battery Page 4 of 8...
- Page 5 ME-2 and ME-2-D Metal Enclosures v1.0 Rev. B.doc 2016-10-08 Fig. 3 PR402DR-12VDC-BRD controllers installed inside ME-2-D (example) Page 5 of 8...
- Page 6 ME-2 and ME-2-D Metal Enclosures v1.0 Rev. B.doc 2016-10-08 Fig. 4 PR102DR-BRD controllers installed inside ME-2-D (example) Page 6 of 8...
- Page 7 ME-2 and ME-2-D Metal Enclosures v1.0 Rev. B.doc 2016-10-08 Fig. 5 ME-2 dimensions Page 7 of 8...
- Page 8 ME-2 and ME-2-D Metal Enclosures v1.0 Rev. B.doc 2016-10-08 4. O RDERING INFORMATION Product Description ME-2 Metal enclosure ME-2-D Metal enclosure with buffer PSU and fuse block ML-1 Mechanical lock 5. P RODUCT HISTORY Version Date Description ME-2 v1.0 10/2013 The first commercial version of the product ME-2-D v1.0...
