- Page 1 Roger Access Control System ME-15 metal enclosure User Manual Product version: 1.2 Document version: Rev. B...
- Page 2 2019-05-30 ESIGN AND APPLICATION ME-15 metal enclosure is dedicated to installation of RACS 5 modules and devices which require DIN rail and 7Ah backup battery. The enclosure is equipped with DIN rail, tamper contact and mounting bracket for PS2D/PS4D/PS8D (Roger) power supply units. The enclosure front panel is attached with screws. ME-15 is made of white powder coated stainless metal sheet.
- Page 3 ME-15 User Manual.doc 2019-05-30 Fig. 1 Arrangement of ME-15 internal components PECIFICATION Parameter Value Tamper contact NO/NC; 50mA/50VDC DIN rail 1 x 250mm Metal sheet DC01; 0,7mm; anti-corrosion protection Colour RAL9003 Battery Space for 7Ah battery Mounting bracket for PS2D, PS4D, PS8D power supply unit Environmental conditions Indoor general conditions, relative humidity up to 90%;...
- Page 4 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
