- Page 1 Roger Access Control System ME-16 metal enclosure User Manual Product version: 1.1 Document version: Rev. B...
- Page 2 12.11.2019 ESIGN AND APPLICATION ME-16 metal enclosure is dedicated to installation of RACS 5 modules and devices which require DIN rail and 17Ah backup battery. The enclosure is equipped with DIN rail, tamper contact and mounting bracket for PS2D/PS4D/PS8D (Roger) power supply units. The enclosure front panel is attached with screws. ME-16 is made of anthracite grey powder coated stainless metal sheet.
- Page 3 ME-16 User Manual 12.11.2019 Fig. 1 Arrangement of ME-16 internal components PECIFICATION Parameter Value Tamper contact NO/NC; 50mA/50VDC DIN rail 1 x 300mm Metal sheet DC01; 0,7mm; anti-corrosion protection Colour Anthracite grey RAL7016 MAT Battery Space for 17Ah battery Mounting bracket for PS2D, PS4D, PS8D power supply unit Environmental conditions Indoor general conditions, relative humidity up to 90%;...
- Page 4 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
