Backyard Creations M22105HD 2722241 Assembly Instructions

Shorewood high bar sling swivel rocker chair

Shorewood High Bar Sling Swivel Rocker Chair

**TO AVOID POTENTIAL SCRATCHING TO PARTS BY ROUGH GROUND SURFACE, COVER GROUND WITH SOFT

SMOOTH PROTECTIVE MATERIAL ON WHICH TO PLACE PARTS DURING ASSEMBLY. **

Step 1: Remove protective wrapping and lay all parts on floor. Identify all parts packed in carton against

the parts list.

Step 2: Lay Seat Bucket (A) on its front side. Then align each pair of holes on the T-bracket (C) to the two

pair of holes on the Brace of the Seat Bucket(A), place Steel Plate(D) over Brace so all holes are aligned

correctly as shown in Diagram 1.

Step 3: Attach this assembly together with Bolts (E), Steel Plates(D), Washers(F),Spring Washers(G), Nuts

(H). Put all bolts, washers, and nuts in their proper positions first before tightening securely with Hex

Wrench(K).

Step 4: Make sure all bolts are aligned properly and tightened securely. Then place Bolt Covers (I) and

Nut Covers(J) over Bolts and Nuts. And then attach the complete seat bucket to Base ( B) as shown in

Diagram 2.

NOTE: IT IS USER'S RESPONSIBILITY TO MAKE SURE ALL PARTS ARE ASSEMBLED AND TIGHTENED

PROPERLY AND SECURELY.

T-Bracket

Brace

M22105HD/2722241

Assembly Instructions

Steel

Plate

Diagram 1

1 of 2
