1
Camera Mount Clamps for Proaim Alpha
Stand
(CT-CMCL-01)
A s s e m b l y M a n u a l
What's In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
2 x Allen Key
(3/16", & 4mm)
Camera Mount Clamps for Alpha Stand
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmitted by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permitted by the applicable copyright
statutes or in writing by the Publisher.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PROAIM CT-CMCL-01
Summary of Contents for PROAIM CT-CMCL-01
- Page 1 Camera Mount Clamps for Proaim Alpha Stand (CT-CMCL-01) A s s e m b l y M a n u a l What’s In The Box Please inspect the contents of your shipped package to ensure you have received everything that is listed below.
- Page 2 Camera Mount Clamps Setup • Open the Clamp by loosening its ratchet knob. as shown in the image. • Remove the bush from inside the Clamp. Feature: Two mounting Clamps vertically attach to your rod and provide a mount for a separately available mounting rod and horseshoe camera mount, allowing you to form a camera mounting system.
- Page 3 Effortless Movement Camera Mount Clamps Slides Up or Down Camera Mount Clamps 360° Rotation...
- Page 4 • After inserting the rod, properly secure it using the ratchet knob, as shown in the image. • Pull and loosen the ratchet knob of the Horseshoe mount (Not Included). • Slide the Horseshoe mount (Not Included) into the rod and tighten the ratchet knob to secure •...
- Page 5 • Properly tighten the Castle ring to completely secure the fluid head (Not Included). • Press the knob of the Fluid head and remove the top plate. • After removing the plate, attach it to the Camera (Not Included) by aligning their threads.
- Page 6 YOUR PROAIM CAMERA MOUNT CLAMPS FOR PROAIM ALPHA STAND ALL DRESSED UP AND READY TO GO! (SHOWN WITH OPTIONAL ACCESSORIES) Warranty: We offer one year warranty for our products from date of purchase. Within this period of time, we will repair it without charge for labor or parts. Warranty doesn’t cover transportation costs nor does it cover a product subjected to misuse or accidental damage.
