- Page 1 Water Dispenser Setup Manual Model No.: CLCTPOU720UVF3...
-
Page 2: Table Of Contents
Table of Contents Safety Information � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � 3 Intended Use �... -
Page 3: Safety Information
Safety Information WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling, installing and operating the dispenser. WARNING: This product dispenses water at very high temperatures. Failure to use properly can cause personal injury. When operating this dispenser, always exercise basic safety precautions, including the following: •... -
Page 4: Intended Use
Intended Use This dispenser is intended to be used in household and similar applications such as: • Staff kitchen areas, offices and other working environments • Farm houses • Clients in hotels, motels and other residential type environments • Bed and breakfast type environments •... -
Page 5: Touch Panel Description
Touch Panel Description 1� Up arrow button – Press to set the time on the clock and increase temperature settings. 2� Clock/Temperature display – Displays the time and water temperature setting for hot and cold water and also indicates when filters must be replaced. 3�... -
Page 6: Package Contents
Package Contents Part Description Quantity Part Description Quantity Filter connecting tube Mounting bracket Shut off valve tube (7 ft.) Filter clip Elbow joint tube Grounding bracket Filter flushing tube (4 ft.) Plumber’s tape Pressure-reducing Feed water adapter (with extra nut) valve Filter housing Tubing cutter... -
Page 7: Installation
Installation 1� Determine Installation Location A� Place the dispenser upright. B� Locate the dispenser on a hard and level surface in a cool shaded location near a grounded wall outlet. NOTICE: Do NOT plug in the power cord until the entire installation section is completed. -
Page 8: Install The Filters And Tubing
3� Install the Filters and Tubing A� Click the three black mounting brackets (H) onto the top of the condenser. B� Attach one filter housing (F) to the top of a mounting bracket (H). C� Connect the filter connecting tube (A) to the filter housing (F). - Page 9 D� Slide the next filter housing (F) onto the middle mounting bracket (H) and connect the other end of the filter connecting tube (A). E� Repeat for the third filter housing. F� Connect the shut off valve with tube (B) to the left filter housing (F).
-
Page 10: Connect To The Cold Water Supply
4� Connect to the Cold Water Supply CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE. The water supply to the unit MUST be from the COLD WATER LINE. Using HOT WATER will severely damage your filters. A�... -
Page 11: Flush The Filters And Complete The Installation
5� Flush the Filters and Complete the Installation IMPORTANT: Follow this procedure every time you replace your filters. IMPORTANT: Ensure the water supply is off before you begin. A� Connect the red filter flushing tube (D) to the right filter housing (F). B�... -
Page 12: Operation
Operation IMPORTANT: This unit has been tested and sanitized prior to packing and shipping. During transit, dust and odors can accumulate in the tank and lines. Dispense and dispose at least one quart of water prior to drinking any water. Turn the Dispenser On/Off IMPORTANT: Before you activate the hot and cold switches, ensure water has filled the tanks inside the... -
Page 13: Dispense Cold And Room Temperature Water
Dispense Cold and Room Temperature Water NOTE: Water will take approximately 1 hour after plugging in and turning on to become completely chilled. 1� Place a drinking glass or container under the tap and press the cold water button to dispense cold water or the ambient water button to dispense room temperature water. -
Page 14: Troubleshooting
Troubleshooting Problem Solution • It takes up to one hour after setup to dispense cold water. • Make sure the power cord is properly connected to a working outlet. • Make sure the back of the dispenser is at least 20 cm from a wall and The cold water is not cold. -
Page 15: Filter Replacement Schedule
Filter Replacement Schedule Filter Type Replacement Schedule Function Pre-carbon 6 months or 950 gallons Reduces chlorine, taste and odor, lead and cysts. Performs a coarse filtration of original water. Removes mud, sand, Sediment 6 months or 950 gallons iron, rust, suspensions and impurities. Post carbon 6 months or 950 gallons Taste and impurity removal. -
Page 16: Care And Maintenance
Care and Maintenance • Keep this dispenser in a dry and cool place and avoid direct sunshine. • Ensure the back of the dispenser is at least 20 cm (8 in.) away from the wall. • Never put the dispenser on paper or foam, which may store water and then cause creepage. Never put anything flammable beside this machine. -
Page 17: Warranty
Warranty Brio (“Vendor”) warrants to the original purchaser of the Brio Water Coolers (the “Product”), and to no other person, that if the Product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in material and workmanship. - Page 18 Contact Us Call: +1 844-257-4103 ©2020 DTWUSA...
