Page 2 EPSON® PROGRESSION™ User’s Guide l%is manual is printed on recycled paper and is 100% recyclable...
Page 3 This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio and television reception.
Page 4 Nor is any liability assumed for damages resulting from the use of the information contained herein. Further, this publication and features described herein are subject to change without notice. Epson is a registered trademark and Epson Progression is a trademark of Seiko Epson Corporation. VirtualCache is a trademark of Epson Portland, Inc.
Page 5: Important Safety Instructions
Important Safety Instructions 1. Read all of these instructions and save them for later reference. 2. Follow all warnings and instructions marked on the computer. 3. Unplug the computer from the wall outlet before cleaning. Use a damp cloth for cleaning; do not use liquid or aerosol cleaners. 4.
Page 6 11. If you use an extension cord with the computer, make sure the total of the ampere ratings of the devices plugged into the extension cord does not exceed the ampere rating for the extension cord. Also, make sure the total of all products plugged into the wall outlet does not exceed 15 amperes.
Page 7 Instructions Importantes de Sécurité Lire compMtement les instructions qui suivant et les conserver pour references futures. Bien suivre tous les avertissements et les instructions indiquks l’ordinateur. Wbrancher l’ordinateur de toute sortie murale avant le nettoyage. Utiliser un chiffon humide; ne jamais utiliser un nettoyeur liquide ou une bonbonne aerosol.
Page 8 10. S’assurer que le cordon d’alimentation de l’ordinateur n’est pas effrs. 11. Dans le cas ou on utilise un cordon de rallonge avec l’ordinateur, on doit s’assurer que la valeur totale d’amperes branches dans le cordon n’excede en aucun temps les amperes du cordon de rallonge.
Page 9: Table Of Contents
Optional Equipment ......2 Memory......2 Drives .
Page 10 Using a Password ......1-24 Changing a Password ....1-25 Deleting a Password .
Page 11 Installing an OverDrive Module ....Installing a Math Coprocessor ....Installing the Intel 487SX/25 Microprocessor .
Page 12 Formatting a Hard Disk Chapter 6 Starting the Program ......Formatting a New Disk Reformatting a Used Disk ....6-3 Selecting an Option .
Page 13 Appendix A Specifications CPU and Memory ..... . . A-1 Controllers ......A-4 Interfaces .
Page 14 4MB of internal memory, expandable to 128MB System and video BIOS shadow RAM 8KB of internal cache VirtualCache™ -the Epson proprietary memory architecture which allows the system to use all its system memory as a virtual cache pool Integrated VGA (video graphics array) controller with Wingine™...
Page 15: Optional Equipment
Your computer’s video and memory features work together to make it extremely fast. The advanced system architecture allows the CPU to communicate directly with the Wingine video controller, providing direct throughput from the system memory to the display. Combined with the speed and graphics capabilities of the Wingine VGA controller, this technology produces screen refresh rates that are ten tunes faster than standard super VGA systems and up to five tunes faster than...
Page 16: Cpu Card
Your system can support up to five mass storage devices, such as hard disk drives, diskette drives, a tape drive, or a CD-ROM drive. As your storage needs expand, you can install these drives to provide the necessary space for all your data. Because the CPU card is replaceable, you can easily upgrade your system without having to purchase a new computer.
Page 17: Video Daughterboard
16 or 256. Check with your authorized Epson dealer for information on optional equipment. For installation instructions, see Chapters 2,3, and 4 of this manual.
Page 18 This manual contains the information you need to get the best results from your computer. You don’t have to read everything in this book; check the following summary. Chapter 1 covers general operating procedures, such as turning the computer on and off, using disks and disk drives, entering a password, and changing the processor speed.
Page 19: Where To Get Help
Where to Get Help If you purchased your computer in the United States, Epson America provides local customer support and service through a nationwide network of authorized Epson dealers and Service Centers. Epson also provides the following support services through the Epson Customer Support Center at (800) 922-8911:...
Page 20: Using Your Computer
Chapter 1 Using Your Computer This chapter gives you a brief overview of some basic computer operations that you’ll use on a daily basis, such as how to turn your system on and off, use diskettes and disk drives, and reset the computer.
Page 21: Turning On The Computer
Turning On the Computer Before turning on your computer, check the following safety rules to avoid accidentally damaging your computer or injuring yourself: Cl Do not connect or disconnect any power cables or peripheral device cables (including the mouse or keyboard) when the computer’s power is on.
Page 22 3. To turn on the computer, press the power button located on the right side of the front panel, as shown below. The power indicator below the button lights up. After a few seconds, the computer displays a count of its system memory, and then performs its power-on diagnostics.
Page 23: Turning Off The Computer
Note If your computer’s configuration does not match the information stored in the computer’s CMOS RAM (defined through the SETUP pro am), you see an error message and a prompt to press the ?3 SETUP program to correct the information. (See Chapter 2 of the Setup Guide for instructions.) If you do not want to run SETUP, ignore the prompt.
Page 24: Using Disks And Disk Drives
3. Remove any diskette(s) from the diskette drive(s). 4. Press the power button to turn off the computer and then turn off any peripheral devices (monitor, printer, etc.). If you need to move your computer, always wait at least 20 seconds after turning it off before you move it. This allows your hard disk drive’s read/write heads to move away from the disk to a safe location.
Page 25: How Disks Store Data
How Disks Store Data Diskettes are made of flexible plastic coated with magnetic material. This plastic is enclosed in a square jacket that is either slightly flexible (5.25-inch diskette) or hard (3.5-inch diskette). Unlike a diskette, a hard disk is rigid and fixed in place. It is sealed in a protective case to keep it free of dust and dirt.
Page 26: Types Of Diskette Drives
Double-sided, double-density diskettes have either 40 or 80 tracks on each side, and double-sided, high-density diskettes have 80 tracks on each side. Diskettes can have 8,9,15, or 18 sectors per track. A hard disk consists of two or more platters stacked on top of one another and thus has four or more sides.
Page 27: Drive And Diskette Incompatibilities
1.2MB drive-Use 5.25-inch, double-sided, high-density, 96 TPI, 1.2MB diskettes. These diskettes contain 80 tracks per side, 15 sectors per track, and hold up to 1.2MB of information (approximately 500 pages of text). 720KB drive-Use 3.5-inch, double-sided, double-density, 135 TPI, 720KB diskettes. These diskettes contain 80 tracks per side, 9 sectors per track, and hold up to 720KB of information (approximately 300 pages of text).
Page 28 5.25-inch drive/diskette compatibility Drive type Diskette types it can read from and write to 360KB 360KB, 320KB, 180KB, 160KB 1.2MB 1.2MB, 36OKB,* 32OKB,* 18OKB,* 160KB* * If you write to this diskette in a 1.2MB drive, you may not be able to read it or write to it In a 360KB drive later.
Page 29: Caring For Diskettes And Diskette Drives
Caring for Diskettes and Diskette Drives Follow these basic precautions to protect your diskettes and avoid losing data: P Remove all diskettes before you turn off the computer. P Do not remove a diskette from the diskette drive or reset or turn off the computer while the drive light is on.
Page 30 Q Do not place diskettes on top of your monitor or near an external hard disk drive. Always hold a 5.25-inch diskette by its protective jacket and never touch the magnetic surface (exposed by the read/write slot). The oils on your fingertips can damage it. Q Never wipe, brush, or try to clean diskettes in any way.
Page 31: Write-Protecting Diskettes
Write-protecting Diskettes You can write-protect a diskette to prevent its data from being altered. When a diskette is write-protected, you can read it and copy data from it, but you cannot store new data on it or delete any files it contains. To write-protect a 5.25-inch diskette, cover the small, rectangular notch (shown below) with an adhesive write-protect tab.
Page 32 On a 3.5-inch diskette, the write-protect device is a small switch on the back of the diskette in the lower right comer, shown below. To write-protect a 3.5-inch diskette, slide the switch toward the edge of the diskette until it clicks into position, exposing a hole in the comer.
Page 33: Inserting And Removing Diskettes
Inserting and Removing Diskettes If you have a 5.25-inch diskette drive, insert a diskette as follows: hold the diskette with the label facing up and the read/write slot leading into the drive, as shown below. Slide the diskette all the way into the slot. Then turn the latch down to lock it in a vertical position.
Page 34 If you have a 3.5-inch diskette drive, insert the diskette with the label facing up and the metal shutter leading into the drive, as shown below. Slide the diskette into the drive until it clicks into place. metal shutter When you want to remove the diskette, make sure the drive light is off;...
Page 35: Using A Single Diskette Drive System
Using a Single Diskette Drive System Most operating systems expect the computer to have at least two diskette drives and display prompts and messages accordingly. MS-DOS, for example, recognizes the first diskette drive (the top drive) as drive A and a second diskette drive as drive B.
Page 36: Formatting Diskettes
Formatting Diskettes Before you can store data on a new diskette, you must format it. Formatting prepares the diskette so that the operating system can write data on it. You need to do this only once, before you use the diskette for the first time. You can also reformat previously used diskettes to store new data.
Page 37: Using A Hard Disk Drive
Using a Hard Disk Drive Using a hard disk is similar to using a diskette. However, the hard disk provides several advantages: P A 240MB hard disk can store as much data as approximately 198 1.2MB diskettes or 165 1.44MB diskettes. P Your computer can perform all disk-related operations faster.
Page 38: Backing Up The Hard Disk
Backing up the hard disk While the hard disk is very reliable, it is essential to back up your hard disk files to diskettes or tapes in case you lose some data accidentally. Make copies of all your system and application program diskettes before copying the programs to the hard disk.
Page 39: Special Keys On The Keyboard
Special Keys on the Keyboard Certain keys on your keyboard serve special functions when your computer is running your operating system or application programs, as described in the table below. key functions Special Ishml 1-20 Using Your Computer Moves the cursor one tab to the right In normal mode and one tab to the left in Shift mode.
Page 40: Stopping A Command Or Program
Special key functions (continued) =-l-[F1zl lserdllpal Ipwrrl The [$GLiC), [lunlodr], and [*a] keys work as toggles; press the key once to turn on a function and again to turn it off. When the function is enabled, the corresponding light in the upper right comer of the keyboard is lit.
Page 41: Resetting The Computer
Resetting the Computer Occasionally, you may settings or its memory without turning it off. You can do this by resetting the computer. For example, if an error occurs and the computer does not respond to your keyboard entries, you can reset it to reload your operating system and try again.
Page 42: Locking The Computer's Cover
If resetting the computer does not correct the problem, you probably need to turn it off and on again to reboot it. Remove any diskette(s) from the diskette drive(s). Turn off the computer and wait 10 seconds. If you do not have a hard disk, insert a system diskette in drive A.
Page 43: Using A Password
Using a Password If you set a password when you ran the SETUP program, you must enter it every time you turn on or reset the computer. Follow these steps to use your password: If you do not have a hard disk, insert your system diskette in drive A.
Page 44: Changing A Password
Note If you turned on network server mode when you ran the SETUP program, you need to use a different procedure to enter your password. See “Using Your Computer as a Network Server” on page 1-27. Changing a Password To change your password, follow these steps: 1.
Page 45: Deleting A Password
Note You can also change your password using the SETUP program. See Chapter 2 of the Setup Guide for instructions. Deleting a Password To delete your password, follow these steps: 1. If you do not have a hard disk, insert your system diskette in drive A.
Page 46: Using Your Computer As A Network Server
Using Your Computer as a Network Server A network server is the master computer in a network and provides storage space for the other computers connected to it. It can also write files to and read files from the other computers, making it the most powerful computer in the network.
Page 47: Using A Password In Network Server Mode
You do not have to set a password in network server mode to use your computer as a network server, but it is helpful. See “Setting the Password Options” in Chapter 2 of the Setup Guide for instructions on setting the password and enabling network server mode.
Page 48: Changing The Processor Speed
Changing the Processor Speed Your computer’s processor can operate at two speeds: high or low. High speed is the highest speed at which your microprocessor is capable of running, such as 33 MHz. Low speed simulates an 8 MHz processor to provide compatibility with older application programs.
Page 49 Some copy-protected programs require the computer to run at low speed while accessing the program on a diskette. These programs also usually require you to leave a key disk-the diskette that contains the copy protection-in the diskette drive. If you use a copy-protected program often, you may want to set your processor speed to change automatically to low speed when accessing the diskette and return to high speed when it is finished.
Page 50: Entering Keyboard Commands
If you frequently use programs that require low or automatic speed, use SETUP to change the processor speed. Your new setting remains in effect until you change it again using SETUP. See Chapter 2 of the Setup Guide for instructions. If you use these programs only occasionally, you should use the keyboard commands or the ESPEED program (described below) to change the processor speed.
Page 51: Using The Espeed Program
Note You can use the commands listed above while you are running a program. However, if the program uses one of these commands for another function, you cannot use it to change the processor speed. For example, if you are running a program that uses the [cbll[m - the cursor, you cannot enter [mJIm1[-1 to change the processor speed to low.
Page 52 To run SPEED, prompt and ESPEED You see the following messages: Usage: ESPEED[/H] [/L] /High Set High speed (no Auto) Set Low speed (no Auto) /LOW /Auto set Auto speed These messages tell you the switches you should use to set the speed to high, low, or automatic.
Page 53: Changing The Speaker Volume
Entering the ESPEED command in a butch file You may want to run the ESPEED program by including the command in a batch file. For example, let’s say you have a program called SLOWDOWN which requires a slower processor speed. You could include the following commands in a batch file to start the SLOWDOWN program: ESPEED SLOwDO?IN...
Page 54 Follow these steps to run SETVOL: 1. If you copied SETVOL.EXE to your hard disk, log onto the directory where it is stored. If you did not copy the file, insert the Reference diskette in drive A and log onto that drive. 2.
Page 55: Preparing The Hard Disk For Moving
This protects the hard disk from being damaged if the computer is bumped accidentally. Many hard disk drives, including all Epson drives, automatically park their heads when you turn off the computer. If your hard disk drive does not do this, or if you are not sure that it does, be sure to run HDSIT.
Page 56: Using Autoexec.bat And Other Batch Files
If you have not already done so, copy the HDSIT.COM and HDSIT.VER files from the Reference diskette to your hard disk. Then, when you want to run HDSIT, log onto the directory files are stored. where these You see a message on the screen that tells you the disk drive’s read/write heads will remain locked until you reset the computer or turn the power off and on again.
Page 57 One batch file that you may find particularly useful is called AUTOEXEC.BAT. Every time you turn on your computer, MS-DOS looks for the AUTOEXEC.BAT file and automatically executes each of the commands in the file. When you install MS-DOS, it creates an AUTOEXEC.BAT file for you, which you can modify or replace as described above.
Page 58: Accessing Internal Components
Chapter 2 Accessing Internal Components To access your computer’s internal components, you need to remove the cover. In some cases, you may also need to remove the front panel and the subassembly (the metal case that holds the drive bays). The instructions in this chapter explain how to do the following: 0 Remove and replace the cover P Remove and replace the front panel...
Page 59: Special Precautions
Special Precautions As you perform the procedures described in this chapter and in Chapters 3 and 4, observe the following precautions to avoid damaging your equipment or injuring yourself: Do not attempt a procedure if you have any reservations about performing it; ask your dealer for assistance. Always turn off wait at least 30 seconds before you remove the cover.
Page 60: Removing The Cover
Removing the Cover Remove the computer’s cover to do any of the following: 0 Change jumper settings 0 Install or remove option cards 0 Install or remove single inline memory modules (SIMMs) 0 Install or remove a CPU card 0 Install or remove a math coprocessor 0 Install or remove an OverDrive module D Install or remove the video daughterboard Ll Install or remove disk drives or other storage devices.
Page 61 4. Loosen the three thumbscrews on the computer’s back panel by turning them counterclockwise, as shown below. (The screws disengage but don’t come all the way off.) 5. Grasp the sides of the cover (toward the front of the computer) and pull it firmly toward you, as shown below. Then lift it up and off the computer.
Page 62: Removing The Front Panel
Removing the Front Panel You must remove the computer’s front panel if you need to install or remove a disk drive in an external drive bay or if you need to remove the subassembly from the computer. (If you are installing an internal option, you do not need to remove the front panel.) Follow these steps:...
Page 63 3. Once the tabs are free, grasp the sides of the front panel and pull it straight toward you to disengage the two tabs at the bottom, as shown below. Be careful not to pull the panel off at an angle; this may bend or pop off the power and buttons.
Page 64: Removing The Subassembly
Removing the Subassembly You need to remove the subassembly only if you are installing or removing a hard disk drive that is mounted next to the power supply. (See the installation instructions in Chapter 4 if you are not sure if you need to remove the subassembly.) Follow these steps: 1.
Page 65 3. Open the clasps holding the power supply and drive cables to the side of the subassembly, as shown below. Then remove all the cables from the clasps. (Do not disconnect any cables from the main system board.) 4. Grasp the back of the subassembly by the edge on its upper left side, as shown below, and lift up the back end.
Page 66: Replacing The Subassembly
5. Pull the subassembly forward slightly to release it from the two pins beneath the front panel opening. Then lift it out of the computer and place it on your work surface. Replacing the Subassembly Follow these steps to replace the subassembly: 1.
Page 67 4. Lower the back end of the subassembly into the computer. If necessary, fit the post beneath the back right edge of the subassembly into the hole on the top of the power supply. Then lower the subassembly all the way down. 5.
Page 68: Replacing The Front Panel
6. Now you need to connect the drive and power supply cables to the backs of all your drives. See “Connecting the Cables” on page 4-9 for instructions. (If you also need to connect the diskette and/or hard disk drive cables to the main system board, follow steps 4 through 6 on pages 4-21 through 4-23.) Replacing the Front Panel Follow these steps to replace the computer’s front panel:...
Page 69: Replacing The Cover
Rep/acing the Cover Follow these steps to replace the computer’s cover: 1. Turn the computer so you are facing the back panel. 2. Hold the cover at a slight angle, as shown below, and lower the front part onto the computer. Then lower the back of the cover.
Page 70: Installing And Removing Options
Chapter 3 Installing and Removing Options You can enhance the performance of your computer by adding a variety of options or upgrading your system components, including the following: D Option cards LJ Memory modules cl Upgraded CPU card P Intel OverDrive module cl Math coprocessor cl Enhanced video daughterboard.
Page 71 This chapter provides instructions for installing the options listed above, and for changing the jumper settings inside the computer. Be sure to check the jumper information if you install or remove any options in your computer. On the next page, you’ll find an illustration of your main system board which shows the location of any components you may need to locate.
Page 72: Main System Board Map
Main System Board Map As you follow the instructions in this chapter and in Chapter 4, use the illustration below to locate the necessary components on your main system board. SIMM sockets option slots CPU card- connector monitor port larallel port hard disk drive connector blskette dr,ve...
Page 73: Jumper Settings
Jumper Settings A jumper is a small electrical connector that controls one of the computer’s functions. The jumper settings in your computer are preset at the factory; however, you can control certain features by changing the standard settings as follows: 0 Enable or disable the built-in mouse port Q Enable or disable an external mouse port 0 Set your monitor type to monochrome or color...
Page 74: Setting The Jumpers
Main system board jumper settings Jumper number * Factory setting Setting the Jumpers If you need to change board, follow these steps: 1. Refer to the table above to identify you need to change. See the “Main System Board Map” on page 3-3 to locate 2.
Page 75: Option Cards
Your computer has six 16-bit option slots, accommodate authorized Epson dealers as well as other vendors. Before you install an option card, check the power requirements given in the card’s documentation. Make sure that the power required by the card does not exceed the power limit for its slot, and that the total power for all the cards does not exceed the power limits for all six slots.
Page 76 Although the computer’s power supply is protected against excessive power loads, you could still damage the main system board if you install an option card that draws more power than the limits shown in the table. This section explains how to install option cards in your computer.
Page 77: Installing An Option Card
Installing an Option Card Follow these steps to install an option card 1. If you are installing an option card that controls a mouse, you may need to change the setting of jumper JP3 or JP4 before you install the card. If you install a display adapter card, you may need to change the settings of jumpers JP5 and JP7.
Page 78 3. Unpack the option card. When you handle it, be careful not to touch any of the components on the card or the gold- edged onnectors If you need to set it down before you install it, place it gently on top of its original packing materials with the component side facing up.
Page 79: Removing An Option Card
5. Secure the end of the card to the back of the computer with the retaining screw. 6. After you replace the computer’s cover, check the documentation that came with your card to see if there are any post-installation procedures you need to perform before you start using the option.
Page 80: Memory Modules (Simms)
2. Cover the option slot opening with the original metal slot cover and secure it with the retaining screw. 3. If you are removing an option card that controls a mouse, you may need to change the setting of jumper JP3 or JP4 on the main system board.
Page 81 0 Although your computer can use any SIMM that complies with industry standards, it is best to use Epson SIMM option kits to ensure reliability and compatibility. If you choose another type of SIMM kit, check the shape of the SIMM to make sure it will fit in your computer.
Page 82 (continued) SIMM configurations 64MB ** * Standard soldered memory ** Check with your dealer to see If this SIMM Is available t With this memory configuration, the 4MB of soldered memory Is disabled. Once you have the SIMMs you need, you or your dealer can install them in your computer.
Page 83: Installing Simms
Installing SIMMs Follow these steps to install SIMMs: 1. Refer to the “Main System Board Map” on page 3-3 to locate the SIMM sockets (at the back of the board, toward the middle). If you are installing two SIMMs, it is easiest to install the first SIMM in the left socket (labelled U12) first.
Page 84 3. Gently push the SIMM into the socket and then tilt it left until it is vertical, guiding the holes at each end of the SIMM over the retaining posts at each end of the SIMM socket. retaining post The SIMM should snap into place over the retaining posts. If it does not go in smoothly, do not force it;...
Page 85: Removing Simms
Removing SIMMs If you need to remove SIMMs from your computer, have your dealer do it for you or follow the steps below. 1. If you are removing two SIMMs, remove the one in the right socket (labeled U11) first. Use your fingers or two small screwdrivers to pull away the tabs that secure the SIMM at each end.
Page 86: Replacing The Cpu Card
Replacing the CPU Card The components for your computer’s microprocessor are contained on the CPU card installed inside the computer. This allows you to easily upgrade your system by replacing the CPU card with a faster one. There are three cards available for your computer: cl 486SX/25 0 486DX/33...
Page 87: Removing The Cpu Card
Removing the CPU Card Follow these steps to remove the CPU card from your computer: 1. Remove the retaining screw securing the card to the front of the computer case, as shown below. 2. Pull the card straight up and out of its socket, as shown above. 3.
Page 88: Installing The Cpu Card
Insfalling the CPU Card This section explains how to install a CPU card in your computer. You need to do this if you have removed your card to install a math coprocessor or OverDrive module on it or if you are installing a new CPU card. If you are installing the 486DX2/66 card, go on to “Installing the card”...
Page 89 486DX/33 There is only one jumper on always be set to position B. If you have the 486DX/33 card, refer to the following table to make sure the jumpers are set correctly before you install the card in your computer, and change them if necessary. 486SX/33 CPU card jumpers CPU card configuration Card only;...
Page 90 Follow these steps to install the CPU card in your computer: 1. Position the card as shown below, aligning the two connectors on the bottom of the card with the two slots in the socket on the main system board. The hole in the bottom of the bracket should fit over the vertical post on the bottom of the computer case.
Page 91: Installing An Overdrive Module
Installing on OverDrive Module If you have the 486SX/25 or 486DX/33 CPU card, you can enhance your system’s performance by installing an Intel OverDrive module on the card. This allows you to effectively double the internal clock speed of your computer’s microprocessor with a very simple upgrade procedure.
Page 92 1. Remove the CPU card as described on page 3-18. 2. Place the card on an anti-static work surface with the components facing up. 3. Position the OverDrive module above the socket so the comer with the extra pin is over the comer in the socket with the extra hole.
Page 93: Installing A Math Coprocessor
5. If you installed the ODP486DX/33, you need to change the jumper setting of W3. See page 3-19 for instructions. Reinstall the CPU card as described on page 3-19. 7. After you replace the computer’s cover, run the SETUP program so your computer can update its configuration. See Chapter 2 of the Setup Guide for instructions.
Page 94 The following table lists which math coprocessors are available. Available math coprocessors If you have this CPU card 486SX/25 486DX/33 486DX2/66 Check with your dealer if you are not sure which type of math coprocessor to purchase. You may prefer to have your dealer install the coprocessor for you because it can be easily damaged if installed incorrectly.
Page 95: Installing The Intel 487Sx/25 Microprocessor
Installing the Intel 487SX/25 Microprocessor Carefully follow these steps to install an Intel 487SX/25 microprocessor on the 486SX/25 CPU card 1. Remove the CPU card as described on page 3-18. 2. Place the card on an anti-static work surface with the components facing up.
Page 96: Installing A Weitek 4167 Coprocessor
4. Make sure the pins in the microprocessor are directly over the holes in the socket. Then gently push it straight into the socket, pressing evenly on all sides. 5. Reinstall the CPU card as described on page 3-19. 6. After you replace the computer’s cover, be sure to run the SETUP program so your computer can update its configuration.
Page 97 3. Position the coprocessor over the socket as shown below. Align the notched corner of the coprocessor-marked with the orientation (index) dot-over the corresponding comer in the socket. Caution Be sure to align the pins in the coprocessor directly over the holes in the socket.
Page 98: Replacing The Video Daughterboard
6. After you replace the computer’s cover, be sure to run the SETUP program so your computer can update its configuration. (See Chapter 2 of the Setup Guide for instructions.) Additionally, if the math coprocessor came with any diagnostic software, you may want to run it to test the coprocessor.
Page 99 Follow these steps to remove the video daughterboard in your computer and install the enhanced one: 1. Remove the two hex screws securing the video port to the back of the computer. (If you do not have an appropriate hex driver to remove the screws, you can try using a small pair of needle-nosed pliers;...
Page 100 2. The daughterboard has two sockets which fit over two of the four pin connectors on the main system board (the two closest to the back panel). To remove the daughterboard, carefully lift up the socketed end of the board to release it as shown in the following illustration.
Page 101 3. The enhanced daughterboard has four sockets which fit over the four pin connectors on the main system board. To install it, guide the board into the computer so the interface port extends through the opening in the back panel. Then align the daughterboard’s four sockets over the pin connectors on the main system board, as shown below.
Page 102 4. When you are sure the pins and holes are aligned correctly, push the board into place, pressing evenly on all sides. Be careful not to bend any pins. 5. Secure the port to the back of the computer with the two hex screws you removed in step 1.
Page 103: Using The Vga Feature Connector
Using the VGA Feature Connector The VGA feature connector on your computer’s main system board allows you to connect an optional, high-resolution graphics adapter card interface cable. See the “Main System Board Map” on page 3-3 to locate the connector. If you want to attach a graphics adapter card cable to the VGA feature connector, follow these steps: 1.
Page 104: Installing And Removing Drives
Although your drive may look different from the ones illustrated here, you should be able to install it the same way. If you are installing or removing a non-Epson drive, some of the steps in this chapter may not apply; see the documentation that came with your drive for more information.
Page 105: Choosing The Correct Drive Bay
before you perform any of the procedures described below, remove the computer’s cover as described in Chapter 2. You may also need to remove the front panel and subassembly; the instructions in this chapter tell you when this is necessary. Choosing the Correct Drive Bay Your system can hold up to five drives.
Page 106: Installation/Removal Sequence
You can install either one full-height or two half-height hard disk drives in the internal drive bay. If you are installing a hard disk, it is best to install it in the internal bay. This reserves the external bay for any devices that need to be accessible from the outside, such as a diskette drive or tape drive.
Page 107: Checking The Ide Hard Disk Drive Jumpers
Checking the IDE Hard Disk Drive Jumpers IDE (Integrated Drive Electronics) hard disk drives have jumpers that must be set for the drive to work properly with your computer. The jumpers tell the computer whether you are using one hard disk drive or two. If you purchased your system with a hard disk drive already installed, these jumpers have been set for you.
Page 108: Where To Go Next
Note If you are removing one hard disk drive and leaving one in your computer, be sure to set the jumpers on the remaining drive to indicate that you have only one hard disk drive. Where to Go Next If you are installing your first hard disk drive (i.e., there is no other hard disk in your computer), you should install it in the internal drive bay.
Page 109: Installing A Drive In The External Bay
Installing a Drive in the External Bay This section describes how to install an Epson diskette drive; however, you can use these instructions to install another type of storage device in the external bay. See the manual that came with it for additional installation instructions.
Page 110 Follow these steps to install a disk drive in the external bay: 1. Locate the following parts included with your computer: Cl Two metal drive brackets Q Four retaining screws (with attached flat washers) P Two nuts (with attached star washers) 0 Small wrench.
Page 111 3. Slide the drive into the bay as shown below, guiding the bracket screws on each side along the appropriate grooves in the drive bay. Guide the holes in the front of the brackets over the threaded posts on the front of the subassembly, as shown above. Then push the drive into the bay so that the bracket lies flush against the front of the drive bay.
Page 112: Connecting The Cables
7. When the drive position is correct, remove the nuts securing it to the drive bay and pull it gently out of the bay. Then tighten the four screws on the brackets, slide the drive back into the bay, and replace the two nuts. 8.
Page 113 Follow these steps to connect the cables: 1. If you are installing a diskette or tape drive, go to step 2. If you are installing a hard disk drive, skip to step 3. 2. Locate the diskette drive ribbon cable. (One end is connected to the main system board and the other end, is attached to the top diskette drive.) To connect diskette drive B, use the connector...
Page 114 3. If you are connecting a hard disk drive, locate the hard disk drive ribbon cable. It is a flat cable with a red wire running down one side. (If you are installing your second drive, one end of the cable is connected to the main system board and another connector is already attached to the hard disk drive in the internal drive bay.
Page 115 4. Locate one of the five power supply cables secured by the clasps on the side of the subassembly. The cables are labeled through P5; you can use any one of them. Position the cable connector so its notched corners line up with the notched comers of the power supply socket on your drive, as shown below.
Page 116 6. If you installed a hard disk drive, skip to step 7. If you installed a diskette drive, tape drive, or other accessible drive, you need to remove the slot cover for that drive from the front panel. Turn the front panel so you are looking at the inside.
Page 117: Removing A Drive From The External Bay
Removing a Drive From the External Bay Follow these steps to remove a drive from the external bay: 1. Disconnect the power supply and drive cables from the back of the drive you want to remove, as shown below. power supply cable drive cable 2.
Page 118 3. Grasp the front of the drive and pull it out of the bay. Note If you removed an IDE hard disk drive from the external bay and it is your only hard disk drive, you must also remove the hard disk drive cable from its connector on the main system board.
Page 119 Before you install a hard disk drive in the internal drive bay, read the following guidelines: The internal drive bay can accommodate only half- or full-height hard disk drives that are 3 M inches wide. If you are installing your first half-height hard disk drive, install it in the position farthest from the power supply.
Page 120 Follow these steps to install a new hard disk drive (or reinstall a drive you removed) in the internal bay: 1. Your hard disk drive may have come with mounting frames attached to each side of the drive, as shown below. On one side, there may also be a plastic guiderail.
Page 121 If a plastic guiderail is attached, remove the screws securing the guiderail and the metal grounding plate to one of the mounting frames, as shown below. 2. Remove the two screws securing the mounting frames to each side of the drive. 4-18 Installing and Removing Drives...
Page 122 3. Position the drive above the drive bay, as shown below. Make sure the power supply and drive sockets face the front of the subassembly. Then lower the drive into the bay. 4. Adjust the drive’s position so the four holes on the drive are aligned with the corresponding holes in the drive bay.
Page 123: Connecting The Cables
Connecting the Cables To connect the drive to the computer, you’ll attach it to two cables: a power supply cable and a drive ribbon cable. Follow these steps to connect the cables: 1. If the subassembly is out of the computer, follow the steps in Chapter 2 to replace it.
Page 124 4. If the drive you installed is the second hard disk drive (there was already one installed), go to step 7. If the drive you installed is the only hard disk drive, you need to attach the hard disk drive ribbon cable to the main system board.
Page 125 To attach the cable to the main system board, select a connector on one end of the cable. Align the small tab in the middle of the connector with the notch on the socket, as shown below. notch (If you need to connect the diskette drive cable to the main system board as well, use the connector with a tab on one end of the cable and insert it as described above.) If you have difficulty reaching the socket, you can remove...
Page 126 6. Thread the cable through the rear clasp on the side of the subassembly, as shown below. (You may have to fold the cable as shown.) Then snap the clasp shut. 7. Now you can attach the hard disk drive cable to your drive. If only one hard disk drive is installed, you can use either of the two free connectors on the cable.
Page 127 The connector has two rows of holes designed to fit over the pins in the drive socket. Notice the red wire running down one side of the cable. This wire helps you orient the cable connector to the drive socket. Align the connector with the socket so the side of the cable with the the red wire faces the drive’s power supply socket, as shown below.
Page 128: Removing A Hard Disk Drive From The Internal Bay
Removing a Hard Disk Drive From the Internal Buy Follow these steps to remove a hard disk drive from the internal drive bay: 1. If you are removing a hard disk drive in the position next to the power supply, first remove the subassembly as described in Chapter 2 2.
Page 129 3. Remove the four screws securing the drive to the internal drive bay. Then lift the drive out of the bay and set it aside. Note If you removed one IDE hard disk drive and are leaving another one in the system, you must set the jumpers on the remaining drive to indicate that you have only one IDE drive installed.
Page 130: Post-Installation Procedures
2. If you installed a hard disk drive that did not receive a low-level format, you need to format the drive before you can use it. (All Epson drives are sold already formatted.) Check the manual that came with the drive to see if it is already formatted.
Page 131 Installing and Removing Drives 4-28...
Page 132: Running System Diagnostics
Chapter 5 Running System Diagnostics You can test the following devices using System diagnostics: Q Systemboard D Numeric coprocessor 0 System memory 0 Diskette drive(s) 0 Hard disk drive(s) cl serial port(s) Ll Parallel port(s) CI Video adapter c3 Dot matrix printer(s). See the table on page 5-7 for a list of the tests available for each device.
Page 133: Starting The Program
Starting the Program Follow these steps to start the System Insert the Reference diskette in drive A and turn on or reset the computer. Note Always boot the computer from the Reference diskette to start System diagnostics. This clears any terminate-and- stay-resident (TSR) programs or other utilities from memory and frees it for use by the diagnostics program.
Page 134: Deleting Tests
Deleting Tests To remove devices from the Items Detected list so the System diagnostics program cannot test them, follow these steps: Press [-t) to select Delete Tests. menu, such as the following: System Board Numeric Coprocessor system Memory Diskette Drive A Hard Disk Drive #1 Serial Port COM1 Parallel Port LPT1...
Page 135: Adding Tests
Adding Tests If you want to add devices to the Items Detected list, follow these steps: Press menu, such as the following: Diskette Hard Disk Drive #2 Serial Port COM2 Parallel Port LPT2 LPT1 LPT2 Printer Test The Add menu lists the testable devices that the computer has not detected as Enabled in your system.
Page 136: Running Tests
Running Tests Follow these steps to run a test from the Execute menu: 1. Press it) or m to select Execute. You see the Execute menu, such as the following: System Board Numeric Coprocessor System Memory Diskette Drive A Hard Disk Drive #1 Serial Port COM1 Parallel Port LPT1 Video Adapter Test...
Page 137: Resuming From An Error
Use [T) or m or type the number of the desired option to highlight a test and then press m to run it. 5. When the test is completed, you see the Execute menu or the test submenu again. You can select another test or exit the menu.
Page 138: System Diagnostic Tests
System Diagnostic Tests The table below lists all the System diagnostic tests you can run on your system. System diagnostic tests Device System Board Numeric Coprocessor System Memory Diskette Drive(s) A or B Hard Disk Drive(s) # 1 or #2 Serial Port(s) COM1 or COM2...
Page 139: Error Messages
System diagnostic tests (continued) Device Video Adapter LPT1 or LPT2 Printer Test(s) * The Write, read check destroys data on the disk. Be sure to back up data on a hard disk or insert a blank, formatted diskette before running this test. Error Messages The following table lists all the error messages that may appear during System diagnostic testing.
Page 140 System diagnostic error messages (continued) Error code Message System board 0112 CMOS battery error 0113 Interrupt controller error 0114 Protect mode error 1 0115 Protect mode error 2 Memory 0201 Memory error 0201 Parity error Diskette drive(s) 0601 Diskette drive controller error 0602 Sequential seek error 0603...
Page 141: Formatting A Hard Disk
You may need to use the procedure in this chapter to physically format a hard disk if you installed a non-Epson hard disk in your computer that has never received the low-level format and did not come with its own format utility. If you installed a hard disk that came with its own format utility, use that program to physically format the disk.
Page 142: Starting The Program
Note Sometimes, after a hard disk has been used for a long time, its data becomes fragmented, causing the disk to perform less efficiently or produce errors. If this happens, check your operating system manual for procedures you can perform to reorganize your data on the hard disk.
Page 143: Formatting A New Disk
Other hard disks (such as Epson disks) come with the bad tracks already flagged. Reformatting a Used Disk To reformat a disk you have been using follow these steps: Use the Nondestructive surface analysis option to check for unflagged bad tracks.
Page 144: Selecting An Option
selecting an Option When you use this program, you often need to select an option from a menu. There are two ways to do this: D Use the arrow keys ([t), [-i-l,[tl, [T] ) to highlight the option and press [Enbrl Cl Type the number of the option and press m You can select almost any option that appears on the screen using either method.
Page 145 Accept recommended skewed sectors in format : 1 1 (Y/N) For an Epson hard disk drive, it is best to accept the recommended skewed sector (also called the interleave factor) of 1, since this setting allows your drive to perform more efficiently.
Page 146 3. Next you see this prompt: Accept head in format : 0 ? (Y/N) For an Epson hard disk drive, accept the recommended value of 0. For another type of drive, use the value recommended in the documentation for the drive.
Page 147: Modifying The Defective Track Table
Modifying the Defective Tack Table If you select to modify the table, you see the following options at the bottom of the table: Defective desired track with cursor = Add track, C D = Delete Enter command : To add a bad track, follow these steps: 1.
Page 148: Formatting The Disk
When you finish adding all the bad tracks, press m without typing a value. Then check the entries in the defective track table. When you are sure the table is correct, press [Fl. The program displays a warning about the consequences of proceeding with formatting, as described in the next section.
Page 149: Option 2, Destructive Surface Analysis
When formatting is complete, the program flags any bad tracks and you see a series of messages like these: Format finished. Flagging bad tracks... Cylinder is nann, head is zm Format completed. Press ENTER to return to the menu. Press m to return to the Hard Disk Format Menu. Option 2, Destructive Surface Analysis You can performa Distructive surface analysis...
Page 150 As the program checks each track, it decreases the cylinder numbers to zero. When the test is complete, the program displays a report on the status of the disk, including a table of unflagged tracks that produced write, read errors-such as the following: Analysis finished.
Page 151: Option 3, Nondestructive Surface Analysis
Option 3, Non-destructive Surface Analysis The Nondestructive surface analysis does not destroy any data, and you can use it to safely check the condition of your hard disk drive. However, this test does not flag any bad tracks it detects. To start the test, select from the Hard Disk Format Menu.
Page 152: Exiting The Program
Exiting the Program To leave the Hard Disk Format Menu, select Exit. You see the operating system command prompt. If you formatted the hard disk or ran the Destructive surface analysis option, you must now prepare your hard disk for use with your operating system.
Page 153: Chapter 7 Troubleshooting
Chapter 7 Troubleshooting You should not encounter any difficulties as you set up and use your computer, but if anything out of the ordinary happens, refer to this chapter. You can correct most problems by adjusting a cable connection, repeating a software procedure, or resetting the computer.
Page 154: Error Messages
3. When the computer performs its power-on memory test, the version numbers of your VGA BIOS and system BIOS appear at the top of the screen. Quickly write down the version numbers. If you do not have enough time to do this, press the RESET When you see Press <F2>...
Page 155 If the error is serious, the computer cancels further checking and halts system initialization. The error message remains on the screen and the computer locks up. If this happens, contact your dealer as soon as possible. Report any error messages when you request technical assistance.
Page 156 Power-on diagnostics error messages (continued) Error code Shadow RAM and C a c h e Memory Keyboard Monitor Diskette drive(s) and controller Parallel port Serial port 1101 7-4 Troubleshooting message BIOS shadow RAM error Cache options error Memory error RAM memory error Memory address error Keyboard error Keyboard or system unit error...
Page 157: The Computer Won't Start
Power-on diagnostics Error code Hard disk drive(s) and controller 1760 1761 1770 1771 1780 1781 1782 1790 1791 Auxiliary device(s) 8601 8602 8603 The Computer Won’t Start If your computer does not start when you turn on the power, check the following: 1.
Page 158: The Computer Does Not Respond
2. If the power light still does not come on, check the electrical outlet for power. Turn off your computer, unplug the power cord, and plug a lamp into the outlet. Turn it on to see if the outlet supplies power. 3.
Page 159 If that doesn’t work, insert your main operating system diskette in drive A and press the button. If the computer still does not boot, contact your Epson dealer. 3. Did you enter the correct password? See “Password Problems,” below.
Page 160: Restoring The Power Supply
9. If you installed a display adapter card (and did not connect it to the feature connector on the main system board), you must set jumper JP7 to disable the built-in VGA adapter. Otherwise, you will not see any display on the screen. You may also need to change the setting of jumper JP5.
Page 161: Password Problems
An overload of the power supply limitations. Check the table in Appendix A to see if you have exceeded the option slot power limits. See your option card manual(s) for the power requirements for your option card(s). 3. After you correct the problem causing the overheating, allow the computer to cool down for at least five minutes at room temperature (about 78°F or 25°C).
Page 162: Accessing Your System
Accessing Your System If you have forgotten your current password, follow these steps to access your system: Turn off the computer. Follow the instructions to disable the password function by setting jumper JP6 to position A. Turn on the computer. When you see Press <F2>...
Page 163: Keyboard Problems
11. If you do not have a hard disk, insert your main operating system diskette in drive A. Turn on the computer. If you disabled password security, you do not see the key prompt and can access your computer immediately. If you set a new password, you see the key prompt ( (If you enabled network server mode, you may not see this prompt.) Enter your password as described in Chapter 1.
Page 164: Monitor Problems
For monitor problems, check the following: 1. If there is no display on the screen, check that the monitor’s power switch is on and that its power light is lit. If the power light is on but you still do not see anything on the screen, check the brightness and contrast controls.
Page 165: Diskette Problems
Note If your application program requires a monitor that supports graphics but you have a monochrome monitor, the results will be unpredictable. 7. If you installed a display adapter card (and did not connect to the feature connector on the main system board), you must set jumper JP7 to disable the built-in VGA adapter or you will not see anything on the screen.
Page 166 3. Check to see if you have inserted the right type of diskette. For example, are you trying to read a 1.44MB diskette in a 720KB diskette drive? See “Types of Diskette Drives” in Chapter 1 for more information. 4. If your diskette is the right type for your drive, see if it is write-protected.
Page 167: Diskette Drive Problems
(See Chapter 2 of the Setup Guide for instructions.) 4. Try running the Diskette drive diagnostic tests described in Chapter 5. If the diagnostics program indicates an error, contact your Epson dealer. Troubleshooting 7-15...
Page 168: Hard Disk Problems
5. If the diskette drive is making loud or unusual noises, do not attempt any further examination of it. Contact your Epson dealer. Hard Disk Problems If you have a problem with a hard disk, it could be the result of improper installation, incomplete disk preparation, or corrupted data.
Page 169: Installing The Drive
IDE drive to a controller on an option card, be sure you the built-in controller the Setup Guide for instructions. 4. If you installed a non-Epson hard disk drive, was it physically formatted by the manufacturer? A blank, new hard disk must be physically formatted (or initialized) before you can partition it and install an operating system on it.
Page 170: Preparing The Drive
Preparing the Drive Before you can store data on a new hard disk (which has already been physically formatted), you must do the following to prepare it for use: 1. Run the SETUP program to define your hard disk as part of the computer’s configuration.
Page 171: Software Problems
If you still have trouble with your hard disk, you can back up your data and physically reformat the disk Then you’ll need to reinstall the operating system and copy your files back onto the disk. See Chapter 6 and your operating system manual for instructions.
Page 172: Printer Problems
3. If you entered an MS-DOS command that you want to stop, there are special key combinations you can type to cancel the command. These methods may also work in your application programs: a Hold down [ and a Hold down [ and 4.
Page 173 If your printer does not work at all, check that the printer has power and is properly connected to the computer. (Also, make sure your printer has paper in it.) See Chapter 1 of the Setup Guide or your printer manual for instructions.
Page 174: Option Card Problems
7. Try running the Parallel port diagnostic test if you have a parallel printer, or the Serial port test if you have a serial printer. You can also test a dot-matrix printer, if you have one. Chapter 5 describes these tests. If the test(s) indicate(s) an error, contact your printer dealer.
Page 175: Memory Module Problems
If you have trouble with your mouse or you see an auxiliary device error message, check the following: 1. Make sure the mouse cable is securely connected to the mouse port and not the keyboard port. See Chapter 1 of the Setup Guide for instructions.
Page 176: Math Coprocessor Problems
3. If you still have trouble with your SIMMs, write down any error messages that appear and contact your dealer. Math Coprocessor Problems If the math coprocessor in your system does not seem to be operating properly, check the following: 1.
Page 177: Cpu And Memory
Appendix A Specifications CPU and Memory CPU (on card) System speed 486SX/25 card: Intel 486SX, 25 MHz microprocessor soldered on CPU card; additional socket for optional Intel ODP486SX/25 Over-Drive module to double internal clock speed (50 MHz); OverDrive module cannot be installed if 487SX/25 microprocessor chip is installed in shared socket 486DX/33 card: Intel 486DX,33 MHz...
Page 178 BIOS ROM into RAM; shadow RAM address control selectable through SETUP 8KB of internal cache (built into the microprocessor); cache testing and address control selectable through SETUP Epson proprietary VirtualCache feature automatically creates a “virtual cache” buffer the size of maximum system memory...
Page 179 Math coprocessor Clock/ calendar OverDrive Module 486SX/25 card: socket for optional Intel 487SX, 25 MHz microprocessor chip with built-in math coprocessor; microprocessor chip cannot be installed if OverDrive module is installed in shared socket 486DX/33 card: math coprocessor built into the 486DX microprocessor; additional socket for optional Weitek 4167,33 MHz math coprocessor 486DX2/66 card: math coprocessor built...
Page 180: Controllers
Controllers Video Diskette Hard disk Interfaces Monitor Parallel Serial A-4 Specifications Chips and Technologies Wingine VGA controller on main system board; ® Brooktree RAMDAC on video daughterboard provides resolutions up to 1024 x 768; optional enhanced video daughterboard provides resolutions up to 1280 x 1024 and 24-bit true color display Controller on main system board supports up to two diskette drives and one tape...
Page 181: Mass Storage
Keyboard Mouse Option slots Speaker Alternate VGA Mass Storage Keyboard PS/2 compatible keyboard interface built into main system board; keyboard speed, delay, and num lock settings selectable through SETUP; 6-pin, mini DIN connector PS/2 compatible mouse interface built into main system board; 6-pin, mini DIN connector Six standard 16-bit I/O expansion slots;...
Page 182: Power Supply
Power Supply Type Input ranges Maximum outputs Frequency (Europe only) Cables Option slot power limits Maximum current For each slot For all six slots A-6 Specifications 200 Watt, fan-cooled, automatic input voltage sensing thermally protected 98 to 132 VAC and 195 to 264 VAC +5 VDC at 22 Amps, +12 VDC at 6.8 Amps, -5 VDC at 0.5 Amps, -12 VDC at 0.5 Amps...
Page 183: Environmental Requirements
Environmental Requirements Humidity 20%to80% (non- condensing) Altitude (-100 to 3,000 m) Maximum wet bulb Physical Characteristics Width Depth Height Weight Non-operating range 14° to 140° F ° (-20 to 60°C) 1O% to 90% -300 to 11,860ft (-100 to 3,600 m) 104°F (40°C) 17 inches (432 mm)
Page 184: Power Source Requirements
Power Source Requirements 120 Volt power source requirements AC plug 240 Volt power source requirements AC plug Specifications Plug type Reference standards North America ANSI C73.11, 125V, 10A NEMA 5-15-P. IEC 83 Reference Plug type standards BS 1362 240V, 10A BS 1363A IEC 83 IEC 127...
Page 185 FFFFFFFFh FFF!XTCDOh 2OlcToaIoh or Wingine video RAM: 1 MB or 2MB OBOClOCDOh OOlrXQOh System BIOS ROM shadow RAM: 64KB CICOH)oh Available for shadowing OBOEBOOOh VGA BIOS ROM shadow RAM: 32KB* OOOEOOOOh Available for shadowing 000C80a)h VGA BIOS ROM shadow RAM: 32KB* OOOCOOOOh VGA monochrome/color text: 64KB OCXIACDXIh...
Page 186: Extended Vga Modes
Extended VGA modes Mode* Size 132 x 25 132 x 50 * These modes require 512KB of video memory (mapped Into VGA memory). NI = Non-interlaced I = Interlaced A-10 Specifications color DotCLK Type 40 MHz Text (8 x 16) 40MHz Text (8 x 8)
Page 187 These modes require 1MB of video memory (mapped Into extended memory), except modes 3A and 50, which require 2MB of video memory. NI = Non-interlaced I = Interlaced Specifications A-11...
Page 188: Analog Monitor
Glossary Access speed The length of time it takes for an information storage device, such as memory or a disk drive, to return a piece of data requested by another device. For example, your computer’s SIMMs return data requested by the microprocessor at an access speed of 70 ns (nanoseconds).
Page 189: Base Memory
ASCII American Standard Code for Information Interchange. A standardized numeric coding system for representing characters, such as numbers, letters, and graphic symbols. Each of the 256 ASCII codes occupies one byte of storage. All computers, printers, and programs can use files transmitted in standard ASCII code.
Page 190 Botch file type file that Batch files are text files with the filename extension .BAT. When you type the filename, your operating system executes all the commands in that file sequentially. BIOS Basic Input/Output System. Routines in ROM (Read Only Memory) that handle the transfer of information among various hardware components, and between the hardware and your operating system and other software.
Page 191 Cache A high-speed type of memory buffer that stores frequently used data where your microprocessor can access it faster. Your computer includes 8KB of internal cache as well as VirtualCache. See also VirtualCache. Color Graphics Adapter. A type of display adapter card that can generate up to 25 lines of text with 80 characters on each line, two-color graphics at 640 x 200 resolution, or four-color graphics at 320 x 200 resolution.
Page 192: Command Prompt
Command An instruction you enter or select to direct a computer program to perform a specific function. Command prompt The symbol or message that displays on the screen to tell you that the operating system is loaded and ready to receive instructions.
Page 193 Coprocessor See Math coprocessor. Central Processing Unit. The primary computer device that interprets instructions, performs the tasks you indicate, keeps track of stored data, and controls all input and output operations. See also Microprocessor. Cursor The highlighted marker or pointer that shows the screen position at which keystrokes will appear when typed or where the next mouse command will be executed.
Page 194 Default Any value or setting choice that the computer or a program makes when the user does not specify an alternative. A default value stays in effect unless you override it temporarily by changing the value or you reset the default value itself. Device A piece of equipment that is part of a computer system and performs a specific task, such as a disk drive, a monitor, or a...
Page 195 Disk The collective term for diskettes and hard disks, the devices on which the computer stores data magnetically. Disk drive The electromechanical device that reads data from and writes data to a disk, tape, or other storage media. A diskette drive accepts removable diskettes in its disk slot while a hard disk is sealed inside a protective casing.
Page 196: Extended Memory
Drive designator The letter name of a disk drive, followed by a colon-for example, C : . Enhanced Graphics Adapter. A type of display adapter card that allows you to display high-resolution graphics on an EGA monitor. It can display up to 43 lines of text with 80 characters on each line, or it can display monochrome or X-color graphics at resolutions up to 640 x 350.
Page 197: Hard Disk
File A collection of information called records, or entries, stored together on a disk under a single name. Text files consist of words and sentences. Program files consist of codes and are used by computers to interpret and execute commands. See also Filename.
Page 198 Hardware Any physical component of a computer system, such as a monitor, printer, keyboard, main system board, disk drive, or CPU. Hexadecimal A base-16 numbering system frequently used by programmers to represent the binary numbers used by the computer. Any decimal number between 0 and 255 can be expressed by a two-digit hexadecimal number consisting of the numbers 0 through 9 and the letters A through F.
Page 199: Main System Board
Jumper A small moveable plug that connects two pins on a device’s circuit board. Jumpers can be used to alter the operation of a particular function. Key disk A diskette containing a copy-protected program and that must remain in a diskette drive while you use the program. See also Copy-protected program.
Page 200: Memory Module
MCGA Multi-color Graphics Array. A type of display adapter that emulates a color graphics adapter (CGA). MCGA provides two additional modes: 640 x 480 in two colors and 320 x 200 in 256 colors. See also CGA. Monochrome Display Adapter. A type of display adapter that displays in 80 column by 25 line text mode in only one color, such as green or amber.
Page 201: Monochrome Monitor
Multi-mode Graphics Adapter. A type of display adapter card that can display monochrome text and color graphics on the screen. Microprocessor A small CPU contained on one semiconductor chip. See also CPU. Modem MOdulator/DEModulator. A device that allows a computer to transfer data to and from another computer by transmitting signals over telephone lines.
Page 202: Network Server Mode
MS-DOS Microsoft Disk Operating System. The operating system most commonly used with your computer. MS-DOS is a command- based, single-user, single-tasking operating system. See also DOS, OS/2, and Operating system. Multifrequency monitor A monitor that accepts input at different frequencies and can display in a variety of resolutions.
Page 203: Operating System
Operating speed The speed at which the computer’s processor can execute commands, usually expressed in megahertz (MHz), such as 33 MHz. See also Megahertz. Operating system A collection of programs that manages a computer’s operations, such as interpreting input, managing files, and reading and writing data to disk.
Page 204 Parameter A qualifier added to a command that tells your operating system what data to process, where it should locate or store a file, or how it should operate. See also Stitch. Parity A method used to verify the accuracy of data transmissions by making the total of the number of l’s in a group of bits odd (odd parity), even (even parity), or none (no parity).
Page 205: Processor Speed
Port A physical input/output socket on a computer to which you can connect a peripheral device. Power-on diagnostics Tests stored in a computer’s ROM that the computer runs to check its internal circuitry, peripheral device configuration, and operating status each time you turn it on or reset it. Processor speed See Operating speed.
Page 206 Read To gather data from one source (such as a disk) and transfer it to a device (such as a monitor screen or a printer). For example, when you open a text file stored on disk, the computer reads the data from the disk and displays it on the screen. See also Write.
Page 207: Shadow Ram
Roof directory The highest or main directory in a hierarchical disk directory structure. All other directories are subdirectories of the root directory. MS-DOS designates the root directory with a \ (backslash). RS-232C A widely used, standard type of serial communication. You can connect an RS-232C device to the computer’s built-in RS-232C serial port.
Page 208: System Diagnostics
Software The collection of instructions (or programs) that tell your computer hardware to perform the tasks and functions you specify. See also Hardware and Program. Subdirectory In a hierarchical disk directory structure, a group of files in a directory that is contained within another directory or the root directory.
Page 209: Video Card
Video card See Display adapter card. VirtualCache The Epson proprietary feature that automatically creates a “virtual cache” buffer the size of your installed system memory to speed up data access. See also Cache. Write To transfer data to a storage device (such as a disk) or an output device (such as a monitor or printer).
Page 210 Write-protect To protect the data on a diskette from being changed by placing a write-protect tab over the notch on a 5.25-inch diskette or by setting the write-protect switch on a 3.5-inch diskette. You can also write-protect a file on a disk by using software to designate the file read-only.
Page 211 Index Accessing internal components, 2-1 -12 Adapter tests, video, 5-1, 5-8, 7-13 Addresses, I/O, A-4 memory, A-9 Alternate VGA interface, 3-3, 3-34, 7-8, 7-13, A-5 Altitude, A-7 Application programs, Intro-3, Intro-6, 7-19 -20 AUTOEXEC.BAT, 1-37 -38 Automatic speed, 1-29 -31, 1-33 -34, 7-19 Auxiliary device, 7-5, 7-23 Backing up data,...
Page 212 CPU speed, see Processor speed CTRL ALT *, 1-31 -32 CTRL ALT +, 1-31 -32 CTRL ALT -, 1-31-32 CTRL ALT DEL, 1-22, 7-7 CTRL BREAK, 1-21, 7-7, 7-20 CTRL C, 1-21, 7-7, 7-20 Customer Support Center number, Intro-6 Daughterboard, see Video daughterboard Defective track table, 6-4, 6-6 -3 Depth, A-7...
Page 213 EDIT, 1-37 EDLIN, 1-37 Enhanced daughterboard, see Video daughterboard Environmental requirements, A-7 EPROM, A-2 Epson Customer Support Center number, Intro-6 Error messages, MS-DOS, 7-14 power-on diagnostics, 7-2 -5, 7-20, 7-23 system diagnostics, 5-6, 5-8 -9 ESPEED program, 1-30 -34, A-1...
Page 214 Hard disk drive, preparing for moving, 1-19, 1-36 -37 preparing for use, 1-18 primary, 4-4 problems, 7-16 -19 read/write heads, 1-7, 1-36 -37 reformatting, 6-3 removing, 4-1, 4-3 -5, 4-14 -15, 4-25 -27 secondary, 4-4 slave drive, 4-4 socket, 4-21 specifications, A-4 storage capacity, 1-18 5-1, 5-5, 5-7 -8...
Page 215 Math coprocessor, configuring, 3-27 -29, 7-24 diagnostics, 5-1, 5-7, 7-24 installing, Intro-1, Intro-3, 3-1, 3-17, 3-24 -29, 7-24 problems, 7-24 removing, 7-24 specifications, A-3 test, 5-1, 5-7 Maximum wet bulb, A-7 Memory, configuration, Intro-1 -2, 3-11 -13, 3-15 -16, A-2 diagnostics, 5-1, 5-7 error messages, 7-4 extended, A-9...
Page 216 OverDrive module, installing, Intro-1, Intro-3, 3-1, 3-17 -19, 3-22 -24 specifications, A-1, A-3 Parallel, error messages, 7-4, 7-20 interface, 3-3, 7-20 -22, A-4 port, Intro-1, 3-3, 7-20 -22, A-4 port 5-1, 5-7, 7-22 tests, Partitions on hard disk, 1-18, 7-16 -18 Password, changing, 1-25 -26, 1-29, 3-3, 7-9 deleting, 1-26, 1-29, 7-9...
Page 217 Replacing cover, 2-12 Resetting computer, 1-22 -23, 7-7 Resolutions, video, Intro-4, 3-29 -30, 3-33, A-4 ROM, 7-1 -2, A-2, A-9 ROM BIOS, version, 7-1 -2 Runtime errors, 5-6 Safety precautions, 2-1 -2 Screen, see Monitor Secondary drive, 4-4 Sector, 1-6 -8 SELECT, 7-17 serial, error messages, 7-4, 7-20...
Page 218 Upgrading system, 3-1, 3-22 Utilities, VGA, Intro-4 Utility diskettes, 1-1 -2 VER, 7-2 Version number, identifying, 7-1 -2 VGA port, alternate interface, 3-34, 7-8, 7-13, BIOS, 7-2, A-2, A-9 card, see Video cards connector, 3-3 controller, Intro-1 -4, 3-29, A-4 diagnostics, 5-1, 5-8, 7-13 display adapter, 3-4 -6 feature connector, 3-3, 3-34, 7-8,...
Page 219 Avda. de Roma 18-26 08290 Cerdanyola de1 vaks 08036 Barcelona, Spain Phone: 3-582-1MO Fax: 3-582-15-55 TeIexz 50129 Epson Electronics Trading Ltd. Taiwan Branch lOF, No. 287, Nanking E. Road, Sec. 3, Taipei, Taiwan R.O.C. Phone: 886-2-n 7-7360 Flee phone: 8%-080-211172...

This manual is also suitable for:

Progression nx

Epson Progression User Manual

Chapter 1 Using Your Computer

Chapter 2 Accessing Internal Components

Chapter 3 Main System Board Map

Chapter 4 Installing and Removing Drives

Chapter 5 Running System Diagnostics

Chapter 6 Formatting a Hard Disk

Chapter 7 Troubleshooting

Appendix A Specifications

Quick Links

Related Manuals for Epson Progression

Summary of Contents for Epson Progression

This manual is also suitable for:

Table of Contents
