Product Manual
Pipeline HD
ST2000VM0002
ST1500VM0002
100773923
Rev. A
February 2015
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pipeline HD ST2000VM0002 and is the answer not in the manual?

Questions and answers

Summary of Contents for Seagate Pipeline HD ST2000VM0002

  • Page 1 Product Manual ® Pipeline HD ST2000VM0002 ST1500VM0002 100773923 Rev. A February 2015...
  • Page 2 U.S. Department of Commerce, Bureau of Industry and Security (for more information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.
  • Page 3: Table Of Contents

    Seagate® Technology Support Services ........
  • Page 4 Figures Figure 1 Typical Current Profiles (5V) ..........12 Figure 2 Typical Current Profiles (12V) .
  • Page 5: Seagate Technology Support Services

    • Authorized Service Centers For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/ For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Pipeline HD Product Manual, Rev. A...
  • Page 6: Introduction

    1.0 Introduction This manual describes the functional, mechanical and interface specifications for the following Seagate ® Pipeline HD SATA model drives: ST2000VM0002 ST1500VM0002 These drives provide the following key features: • 5900 RPM spindle speed • High instantaneous (burst) data-transfer rates with a default of 3Gb/s (ST1500VM002 and ST2000VM002).
  • Page 7: About The Serial Ata Interface

    1.1 About the Serial ATA Interface The Serial ATA interface provides several advantages over the traditional (parallel) ATA interface. The primary advantages include: • Easy installation and configuration with true plug-and-play connectivity. It is not necessary to set any jumpers or other configuration options.
  • Page 8: Drive Specifications

    2.0 Drive Specifications Unless otherwise noted, all specifications are measured under ambient conditions, at 25°C, and nominal power. For convenience, the phrases the drive and this drive are used throughout this manual to indicate the following drive models: ST2000VM0002 ST1500VM0002 2.1 Specification summary tables The specifications listed in the following tables are for quick reference.
  • Page 9 Table 1 Drive specifications summary for 2TB,1.5TB, and 1TB models (Continued) Drive Specification ST2000VM0002 ST1500VM0002 Voltage tolerance 5V: ± 5% (including noise) 12V: ±10% 0° to 75°C (operating) Ambient temperature –40° to 70°C (nonoperating) 20°C per hour (operating) Temperature gradient (max) 30°C per hour (nonoperating)
  • Page 10: Formatted Capacity

    2.2 Formatted capacity Formatted Guaranteed Model Bytes per sector capacity* sectors ST2000VM0002 3,907,029,168 4096 (512 bytes per sector emulated at the interface) ST1500VM0002 1.5TB 2,930,277,168 *One Gbyte equals one billion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting.
  • Page 11: Physical Characteristics

    2.5 Physical characteristics Maximum height 2TB and 1.5TB models 26.1mm / 1.028 in Maximum width 101.6mm / 4.0 in (± 0.010 in) Maximum length 147.00mm / 5.78 in Typical weight 2TB and 1.5TB models 635g / 1.39 lb Cache buffer 64MB (65,536kb) 2.6 Seek time...
  • Page 12: Power Specifications

    2.8 Power specifications The drive receives DC power (+5V or +12V) through a native SATA power connector. (Refer to Figure 3 2.8.1 Power consumption Power requirements for the drives are listed in . Typical power measurements are based on an Table 2 on page 11 average of drives tested, under nominal conditions, using 5.0V and 12.0V input voltage at 25°C ambient...
  • Page 13: Figure 1 Typical Current Profiles (5V)

    Figure 1 Typical Current Profiles (5V) Figure 2 Typical Current Profiles (12V) Pipeline HD Product Manual, Rev. A...
  • Page 14: Conducted Noise

    2.8.2 Conducted noise Input noise ripple is measured at the host system power supply across an equivalent 80-ohm resistive load on the +12V line or an equivalent 15-ohm resistive load on the +5V line. • Using 12V power, the drive is expected to operate with a maximum of 120 mV peak-to-peak square-wave injected noise at up to 10MHz.
  • Page 15: Environmental Specifications

    2.9 Environmental specifications 2.9.1 Drive case temperature Ambient temperature is defined as the temperature of the environment immediately surrounding the drive. Drive case temperature should be measured at the location indicated in Figure 4 Operating 0° to 75°C (32° to 167°F) Nonoperating –40°...
  • Page 16: Vibration

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389- 7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.
  • Page 17: Electromagnetic Immunity

    2.11 Electromagnetic immunity When properly installed in a representative host system, the drive operates without errors or degradation in performance when subjected to the radio frequency (RF) environments defined in the following table: Table 4 Radio frequency environments Test...
  • Page 18: Agency Certification

    As a subassembly, no Federal Communications Commission verification or certification of the device is required. Seagate has tested this device in enclosures as described above to ensure that the total assembly (enclosure,disk drive, motherboard, power supply, etc.) does comply with the limits for a Class B computing device, pursuant to Subpart J, Part 15 of the FCC rules.
  • Page 19: Environmental Protection

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.
  • Page 20: Configuring And Mounting The Drive

    3.0 Configuring and Mounting the Drive This section contains the specifications and instructions for configuring and mounting the drive. 3.1 Handling and static-discharge precautions After unpacking, and before installation, the drive may be exposed to potential handling and electrostatic discharge (ESD) hazards.
  • Page 21: Drive Mounting

    3.4 Drive mounting You can mount the drive in any orientation using four screws in the side-mounting holes or four screws in the bottom-mounting holes. See for drive mounting dimensions. Follow these important mounting Figure 4 precautions when mounting the drive: •...
  • Page 22: Serial Ata Interface

    4.0 Serial ATA Interface These drives use the industry-standard Serial ATA (SATA) interface that supports FIS data transfers. It supports ATA programmed input/output (PIO) modes 0 to 4; multiword DMA modes 0 to 2, and Ultra DMA modes 0 to 6.
  • Page 23: Supported Ata Commands

    Notes: 1. All pins are in a single row, with a 1.27mm (0.050”) pitch. 2. The comments on the mating sequence apply to the case of backplane blindmate connector only. In this case, the mating sequences are: • the ground pins P4 and P12.
  • Page 24 Table 6 Supported ATA commands (Continued) Command name Command code (in hex) Read Log Ext Read Multiple Read Multiple Extended Read Native Max Address Read Native Max Address Extended Read Sectors Read Stream DMA Extended Read Stream Extended Read Sectors Extended...
  • Page 25 Table 6 Supported ATA commands (Continued) Command name Command code (in hex) S.M.A.R.T. Read Attribute Thresholds / D1 S.M.A.R.T. Read Data / D0 S.M.A.R.T. Read Log Sector / D5 S.M.A.R.T. Return Status / DA S.M.A.R.T. Save Attribute Values / D3 S.M.A.R.T.
  • Page 26: Identify Device Command

    4.3.1 Identify Device command The Identify Device command (command code EC ) transfers information about the drive to the host following power up. The data is organized as a single 4096-byte block of data, whose contents are shown on page 22. All reserved bits or words should be set to zero.
  • Page 27 Table 7 Identify Device commands (Continued) Word Description Value 57–58 Current capacity in sectors xxxx Number of sectors transferred during a Read Multiple xxxx or Write Multiple command 60–61 Total number of user-addressable LBA sectors available 0FFFFFFFh* (see Section 2.2 for related information) *Note: The maximum value allowed in this field is: 0FFFFFFFh (268,435,455 sectors, 137 Gbytes).
  • Page 28 Table 7 Identify Device commands (Continued) Word Description Value Security erase time 00A4 Enhanced security erase time 00A9 Master password revision code FFFE Hardware reset value xxxx 95–99 ATA-reserved 0000 100–103 Total number of user-addressable LBA sectors available ST2000VM0002 = 3,907,029,168 ST1500VM0002 = 2,930,277,168 (see Section 2.2 for related information).
  • Page 29 Table 8 Bit Descriptions (Continued) Word 84 SMART error login is supported. SMART self-test is supported. Media serial number is supported. Media Card Pass Through Command feature set is supported. Streaming feature set is supported. GPL feature set is supported.
  • Page 30: Set Features Command

    4.3.2 Set Features command This command controls the implementation of various features that the drive supports. When the drive receives this command, it sets BSY, checks the contents of the Features register, clears BSY and generates an interrupt. If the value in the register does not represent a feature that the drive supports, the command is aborted.
  • Page 31: Commands

    4.3.3 S.M.A.R.T. commands S.M.A.R.T. provides near-term failure prediction for disk drives. When S.M.A.R.T. is enabled, the drive monitors predetermined drive attributes that are susceptible to degradation over time. If self-monitoring determines that a failure is likely, S.M.A.R.T. makes a status report available to the host. Not all failures are predictable. S.M.A.R.T.
  • Page 32 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100773923, Rev. A...
