  • Page 1 Product Manual Seagate Surveillance HDD ® ST3000VX006 ST2000VX003 ST1000VX001 100762805 Rev. A September 2014...
  • Page 2 U.S. Department of Commerce, Bureau of Industry and Security (for more information, visit www.bis.doc.gov), and controlled for import and use outside of the U.S. Seagate reserves the right to change, without notice, product offerings or specifications.

  • Page 3: Table Of Contents

    S.M.A.R.T. commands ..........30 Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 4 Mounting dimensions (1TB model) ..........20 Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 5: Seagate Technology Support Services

    Authorized Service Centers For information regarding Warranty Support, visit: http://www.seagate.com/support/warranty-and-replacements/ For information regarding data recovery services, visit http://www.seagate.com/services-software/data-recovery-services/ For Seagate OEM and Distribution partner portal, visit: http://www.seagate.com/partners/ For Seagate reseller portal, visit: http://www.seagate.com/partners/my-spp-dashboard/ Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 6: Introduction

    • Native Command Queuing with command ordering to increase performance in demanding applications • Full-track multiple-sector transfer capability without local processor intervention • Seagate AcuTrac™ servo technology delivers dependable performance, even with hard drive track widths of only 75 nanometers.

  • Page 7: About The Serial Ata Interface

    Serial ATA devices behave like Device 0 devices. For additional information about how Serial ATA emulates parallel ATA, refer to the “Serial ATA International Organization: Serial ATA Revision 3.2”. The specification can be downloaded from www.sata-io.org. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 8: Drive Specifications

    Power-on to ready (max) <17s <6s Standby to ready (max) <17s <6s <1.0ms read; Track-to-track seek time (typical) <1.2ms write <8.5ms read; Average seek (typical) <9ms write 1.2A Startup current (typical) 12V (peak) 1.8A Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 9 *One GB equals one billion bytes and 1TB equals one trillion bytes when referring to hard drive capacity. Accessible capacity may vary depending on operating environment and formatting. **During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 10: Formatted Capacity

    Recording density (max) 1807kFCI Track density (avg) 352ktracks/in Areal density (avg) 625Gfc/in Spindle speed (RPM) 5900 ± 0.2% Internal data transfer rate (max) 2147Mb/s Sustained data transfer rate (max) 159MB/s I/O data-transfer rate (max) 600MB/s Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 11: Physical Characteristics

    (such as track-to-track and average), are expected to meet the noted values. Note However, due to the manner in which these drives are formatted, benchmark tests that include command overhead or measure logical seeks may produce results that vary from these specifications. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 12: Start/Stop Times

    Idle mode power is measured with the drive up to speed, with servo electronics active and with the heads in a random track location. • Standby mode During Standby mode, the drive accepts commands, but the drive is not spinning, and the servo and read/ write electronics are in power-down mode. Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 13 *During periods of drive idle, some offline activity may occur according to the S.M.A.R.T. specification, which may increase acoustic and power to operational levels. Measurement was taken in Idle 1 mode. †5W IDLE, Standby and Sleep, with DIPLM enabled Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 14: Figure 1 Typical Current Profiles (5V)

    Figure 1 Typical Current Profiles (5V) Figure 2 Typical Current Profiles (12V) Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 15: Conducted Noise

    If the standby timer reaches zero before any drive activity is required, the drive makes a transition to Standby mode. In both Idle and Standby mode, the drive accepts all commands and returns to Active mode when disk access is necessary. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 16: Environmental Specifications

    The nonoperating shock level that the drive can experience without incurring physical damage or degradation in performance when subsequently put into operation is 300 Gs (for 3TB and 2TB model) and 350 Gs (for 1TB) based on a nonrepetitive half-sine shock pulse of 2ms duration. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 17: Vibration

    Seagate follows the ECMA-74 standards for measurement and identification of PDTs. An exception to this process is the use of the absolute threshold of hearing. Seagate uses this threshold curve (originated in ISO 389- 7) to discern tone audibility and to compensate for the inaudible components of sound prior to computation of tone ratios according to Annex D of the ECMA-74 standards.

  • Page 18: Electromagnetic Immunity

    Operation at excessive I/O duty cycle may degrade product reliability. The consumer electronics environment of power-on-hours, temperature, and I/O duty cycle affect the product MTBF. The MTBF will be degraded if used in an enterprise application. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 19: Warranty

    EN55022, Class B and the immunity levels are defined by EN55024. Drives are tested in representative end-user systems. Although CE-marked Seagate drives comply with the directives when used in the test systems, we cannot guarantee that all systems will comply with the directives.

  • Page 20: 2.14.3 Fcc Verification

    Users may find helpful the following booklet prepared by the Federal Communications Commission: How to Identify and Resolve Radio-Television Interference Problems. This booklet is available from the Superintendent of Documents, U.S. Government Printing Office, Washington, DC 20402. Refer to publication number 004-000-00345-4. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 21: Environmental Protection

    The silver, copper, nickel and gold films used in Seagate products are especially sensitive to the presence of sulfide, chloride, and nitrate contaminants. Sulfur is found to be the most damaging. In addition, electronic components should never be exposed to condensing water on the surface of the printed circuit board assembly (PCBA) or exposed to an ambient relative humidity greater than 95%.

  • Page 22: Configuring And Mounting The Drive

    For installations which require cables, users can connect the drive as illustrated in Figure 3 Figure 3 Attaching SATA cabling Signal connector Power connector Signal cable Power cable Each cable is keyed to ensure correct orientation. Seagate Surveillance HDD drives support latching SATA connectors. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 23: Drive Mounting

    2x 0.125 in 3.18 mm 4X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.15 MAXIMUM FASTENER PENETRATION 2x 3.750 in 95.25 mm Note. Image is for reference only, and may not represent actual drive. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 24: Figure 5 Mounting Dimensions (1Tb Model)

    2x 0.125 in 3.18 mm 4X 6-32 UNC-2B 3 MINIMUM THREAD DEPTH 0.15 MAXIMUM FASTENER PENETRATION 2x 3.750 in 95.25 mm Note. Image is for reference only, and may not represent actual drive. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 25: Serial Ata Interface

    For detailed information about the Serial ATA interface, refer to the “Serial ATA: High Speed Serialized AT Attachment” specification. Hot-Plug compatibility Seagate Surveillance HDD drives incorporate connectors which enable users to hot plug these drives in accordance with the Serial ATA Revision 2.5 specification. This specification can be downloaded from www.serialata.org.

  • Page 26: Supported Ata Commands

    Identify Device Idle Idle Immediate Initialize Device Parameters Read Buffer Read DMA Read DMA Extended Read DMA Without Retries Read FPDMA Queued Read Log Ext Read Multiple Read Multiple Extended Read Native Max Address Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 27 / D2 S.M.A.R.T. Enable Operations / D8 S.M.A.R.T. Execute Offline / D4 S.M.A.R.T. Read Attribute Thresholds / D1 S.M.A.R.T. Read Data / D0 S.M.A.R.T. Read Log Sector / D5 S.M.A.R.T. Return Status / DA Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 28 Write FPDMA Queued Write Log Extended Write Multiple Write Multiple Extended Write Multiple FUA Extended Write Sectors Write Sectors Without Retries Write Sectors Extended Write Stream DMA Extended Write Stream Extended Write Uncorrectable Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 29: Identify Device Command

    PIO data-transfer cycle timing mode 0200 Retired 0200 Words 54–58, 64–70 and 88 are valid 0007 Number of current logical cylinders xxxx Number of current logical heads xxxx Number of current logical sectors per logical track xxxx Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 30 (4133 = 1000000100101 binary) Command sets enabled 34xx Command sets enabled BE01 Command sets enable extension 4133 Ultra DMA support and current mode (see note following this 00A4 table) Security erase time 00A4 Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 31 Multiword DMA mode 2 is currently active. Word 84 SMART error login is supported. SMART self-test is supported. Media serial number is supported. Media Card Pass Through Command feature set is supported. Streaming feature set is supported. Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 32 Ultra DMA mode 2 is currently active. Ultra DMA mode 3 is currently active. Ultra DMA mode 4 is currently active. Ultra DMA mode 5 is currently active. Ultra DMA mode 6 is currently active. Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 33: Set Features Command

    Disable use of SATA features. Enable read look-ahead (read cache) feature (default). Report full capacity available. At power-on, or after a hardware or software reset, the default values of the features are as indicated above. Note Seagate Surveillance HDD Product Manual, Rev. A...

  • Page 34: Commands

    S.M.A.R.T. Enable Operations S.M.A.R.T. Disable Operations S.M.A.R.T. Return Status If an appropriate code is not written to the Features Register, the Note command is aborted and 0x 04 (abort) is written to the Error register. Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 35 ISO document 7779 13 ITE 15 Electrical fast transient 14 Electromagnetic Compatibility (EMC) 15 KCC 15 Electromagnetic Compatibility control Regulation 15 Korean Communications Commission 15 Electromagnetic Compatibility Directive (2004/108/EC) Korean RRL 15 Electromagnetic immunity 14 Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 36 Read Native Max Address Extended 23 Specification summary table 4 Read Sectors 23 Spindle speed 6 Read Sectors Extended 23 Spinup 9 Read Sectors Without Retries 23 Spinup power 8 Read Verify Sectors 23 Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 37 Write DMA Without Retries 24 Write Log Extended 24 Write Multiple 24 Write Multiple Extended 24 Write Multiple FUA Extended 24 Write Sectors 24 Write Sectors Extended 24 Write Sectors Without Retries 24 Seagate Surveillance HDD Product Manual, Rev. A...
  • Page 38 ASIA/PACIFIC Seagate Singapore International Headquarters Pte. Ltd. 7000 Ang Mo Kio Avenue 5, Singapore 569877, 65-6485-3888 EUROPE, MIDDLE EAST AND AFRICA Seagate Technology SAS 16-18 rue du Dôme, 92100 Boulogne-Billancourt, France, 33 1-4186 10 00 Publication Number: 100762805, Rev. A...
