Table of Contents
Índice
Safety Information ....................................................................................................................................................................................................... 2
Información de seguridad ................................................................................................................................................................................... 2
Preparation ..................................................................................................................................................................................................................... 2
Preparación ............................................................................................................................................................................................................. 2
Features ........................................................................................................................................................................................................................... 3
Características ........................................................................................................................................................................................................ 3
Parts/Reference List ..................................................................................................................................................................................................... 4
Lista de piezas con letras de referencia ............................................................................................................................................................ 4
Installation Instructions ............................................................................................................................................................................................. 6
Instrucciones de instalación ............................................................................................................................................................................... 6
Operation ........................................................................................................................................................................................................................ 16
Operación ................................................................................................................................................................................................................ 17
Maintenance .................................................................................................................................................................................................................. 16
Mantenimiento ....................................................................................................................................................................................................... 17
Troubleshooting ........................................................................................................................................................................................................... 16
Solución de problemas ......................................................................................................................................................................................... 17
Net Weight:
14.55 LBS
Peso Neto:
6.6 KGS
ETL-ES-Sparta-WH09
Please write model number
here for future reference:
Por favor, incluya el número del
MR
modelo aquí para futura referencia:
78524
Sparta
TM
by
Advertisement
Table of Contents
Related Manuals for Westinghouse Sparta 78524
Summary of Contents for Westinghouse Sparta 78524
-
Page 1: Table Of Contents
78524 Sparta Table of Contents Índice Safety Information ........................................2 Información de seguridad ....................................2 Preparation ............................................. 2 Preparación ..........................................2 Features ............................................3 Características ........................................3 Parts/Reference List ........................................4 Lista de piezas con letras de referencia ................................4 Installation Instructions ...................................... -
Page 2: Safety Information
SafETy TipS / CoNSejoS de SeGuridad OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS / HAGA LO SIGUIENTE: LEA Y GUARDE ESTAS INSTRUCCIONES WaRNiNG: TO REDUCE THE RiSK Of fiRE, ELECTRiC SHOCK, OR pERSONaL iNJURy, MOUNT TO OUTLET BOX MaRKED "aCCEpTaBLE fOR faN SUppORT", aND USE THE OUTLET SCREWS pROViDED WiTH THE OUTLET BOX. -
Page 3: Features
fEaTURES / CaraCTerÍSTiCaS VaULTED CEiLiNG iNSTaLLaTiON DOWNROD iNSTaLLaTiON iNSTaLaCiÓN Para iNSTaLaCiÓN CoN VariLLa VerTiCaL CieLorraSoS aBoVedadoS For normal ceilings May require a longer downrod (sold separately) Para cielorrasos normales Podría requerir una varilla vertical más larga (se vende por separado) ETL-ES-Sparta-WH09... -
Page 4: Parts/Reference List
paRTS/REfERENCE LiST LiSTa de PieZaS CoN LeTraS de reFereNCia NOTE: The reference list below assigns a letter to each part referenced in the assembly instructions. Use this reference as both a descriptive listing, as well as designation of the parts’ final location. NoTa: La siguiente lista asocia una letra de referencia con cada pieza que se menciona en las instrucciones de montaje. - Page 5 EE EE ETL-ES-Sparta-WH09...
-
Page 6: Installation Instructions
iNSTaLLaTiON iNSTaLaCiÓN Unpack and inspect fan carefully to be certain all contents are included. Quite el envoltorio e inspeccione detenidamente el ventilador para verifi- car que todas las piezas estén incluidas. Turn off power at fuse box to avoid possible electrical shock. - Page 7 Choose a mounting option / elija una opción de montaje: NORMaL EXTENDED DOWNROD DOWNROD NORMaL DOWNROD iNSTaLLaTiON - If installing iNSTaLLaTiON iNSTaLLaTiON downrod supplied with fan, proceed to step 6. EXTENDED DOWNROD iNSTaLLaTiON - If installing with longer downrod than supplied with fan, proceed to step 8.
- Page 8 Re-install pin (Q) into extended downrod, and slide downrod ball (I) up to the top of the downrod. Re-install set screw (S) to secure ball to downrod. Note: Some extended downrods have a pre-drilled set-screw hole. If a pre-drilled hole is present in the extended downrod, tighten the set screw into the pre-drilled hole in the extended downrod.
- Page 9 This remote control unit is equipped with 16 code combinations to prevent possible interference from or to other remote units. The frequency switches on your receiver (N) and transmitter (M) have been preset at the factory. Please recheck to make sure the switches on transmitter (M) and receiver (N) are set to the same position, any combination of settings will operate the fan as long as the transmitter and receiver are set to the same position.
- Page 10 The inside canopy cover ring (H) has two keyhole slots that allow it to be mounted onto the screw heads on the two protruding screws from the mounting bracket. Slide the canopy cover ring up the downrod, and allow the two protruding screw heads from the mounting bracket to go into the keyhole slots on the canopy cover ring.
- Page 11 Insert the blade (C) through the slot on the flywheel (B). Make sure blade holes and holes on the flywheel are aligned. Secure the blade to the flywheel using blade screws (V) and metal washers (AA) provided. Repeat this step for remaining blade. Tighten screws securely.
- Page 12 Connect the wire plugs from the motor (A) to the wire plugs from the light kit (D), white to white, and black to black. Conecte los conectores para cables del motor (A) a los conectores para cables del juego de luces (D) blanco a blanco y negro a negro.
- Page 13 Install E11 base, max 100W bulb (CC) (included). Caution: Do not touch glass part of bulbs with bare hands. Instale las bombilla (CC) de base E11 de un máximo de 100 vatios (se incluyen). Advertencia: No toque la parte de vidrio de las lámparas directamente con las manos.
- Page 14 Mount wall bracket to the wall using screws provided. Instale el soporte de pared sobre la pared con los tornillos incluidos. Place the transmitter into the mounted holder. Coloque el transmisor en el soporte montado. Remote Control Operation 1. Fan Control– press and release. The remote control operates the fan speed as follows: 1 - high;...
- Page 15 NOTiCE This ‘Energy Policy Act 2005’ compliant fan includes a device that limits the total wattage of its light fixture to 190 watts. By installing a combination of light bulbs that exceeds 190 watts or if an electrical surge causes the wattage to exceed 190 watts, the light fixture will either dim the lights to 190 watts or will automatically turn off.
-
Page 16: Operation
Operation Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so on. The slide switch controls direction, forward or reverse. Warm weather - (Forward) Fan turns counterclockwise direction. A downward air flow creates a cooling effect as shown in illustration A. -
Page 17: Operación
operación Las velocidades para clima cálido o frío dependen de factores como el tamaño de la habitación, la altura del ventilador, el número de ventiladores, etc. El conmutador de tipo deslizante controla la dirección, hacia adelante o hacia atrás. Clima cálido - (Adelante) El ventilador gira en sentido contrahorario. Una corriente de aire descendente crea un efecto refrescante como lo indica la ilustración A. - Page 18 ETL-ES-Sparta-WH09...
- Page 19 ETL-ES-Sparta-WH09...
- Page 20 Westinghouse Lighting Corporation, Westinghouse Lighting Corporation, a Westinghouse Electric Corporation licensee titular de la licencia de Westinghouse Electric Corporation is a registered trademark of es una marca registrada de Westinghouse Electric Corporation Westinghouse Electric Corporation Made in China Fabricado en China ©...
