pickering
User Manual
SYSTEM 10/20
GPIB Switching Matrix Module
(Model Nos. 10-510/520/530)
*Please contact Pickering for alternative
PXI/LXI/USB solutions
Issue 3.1 June 2019
pickeringtest.com
pickering
SWITCHING MATRIX MODULE 10-510/520/530
Page (1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SYSTEM 10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pickering SYSTEM 10

Summary of Contents for Pickering SYSTEM 10

  • Page 1 User Manual SYSTEM 10/20 GPIB Switching Matrix Module (Model Nos. 10-510/520/530) *Please contact Pickering for alternative PXI/LXI/USB solutions Issue 3.1 June 2019 pickeringtest.com pickering SWITCHING MATRIX MODULE 10-510/520/530 Page (1)
  • Page 2 © COPYRIGHT (2019) PICKERING INTERFACES. ALL RIGHTS RESERVED. No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by any means without the written permission of Pickering Interfaces. Technical details contained within this publication are subject to change without notice.
  • Page 3 Pickering Interfaces strives to fulfil all relevant environmental laws and regulations and reduce wastes and releases to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

  • Page 4: Product Safety

    PRODUCT SAFETY SAFETY SYMBOLS The following safety symbols may be used on the product and throughout the product documentation. MEANING / DESCRIPTION SYMBOL PROTECTIVE EARTH (GROUND) To identify any terminal which is intended for connection to an external conductor for protection against electric shock in case of a fault, or the terminal of a protective earth (ground) electrode.

  • Page 5: Table Of Contents

    CONTENTS Copyright Statement ..............II Technical Support and Warranty ..........III Product Safety ................IV Contents (this page) ..............V Warnings and Cautions ..............VII Section 1 Technical Specification ...............1.1 Section 2 Technical Description ..............2.1 Functional Description ............2.1 Section 3 Installation ..................3.1 Pre-Operation Checks ............3.1 Hardware Installation ............3.1...
  • Page 6 THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page (VI)

  • Page 7: Warnings And Cautions

    Unused slots in the System 10/20 chassis are populated with blanking plates to prevent access to user I/O signals that may be present. Blanking panels are available to order from Pickering in a variety of slot widths. If the product is not used in this manner for example by using an extender card then additional care must be taken to avoid contact with exposed signals.
  • Page 8 THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page (VIII)
  • Page 9 • Switch up to 100 Volts DC, 0.5 Amps (1A Carry Current) • 50W Max Power • Uses High Reliability Pickering Ruthenium Reed Relays For Maximum Performance The 10-510, 10-520 and 10-530 are a range of matrix modules arranged in 8x4, 16x4 and 8x8 configurations respectively, available with either 1 or 2 pole switching to suit many switching requirements.
  • Page 10 Relay Type Creating Larger Matrices The module uses instrument grade sputtered Ruthenium Reed Each System 10 interface can directly support matrices to over Switches which are suitable for switching very low level signals 2000 crosspoints. Larger sizes are supported using multiple with a low and stable contact resistance.
  • Page 11 -R. Product Customization Pickering System 10 modules are designed and manufactured on our own flexible manufacturing lines, giving complete product control and enabling simple customization to meet very specific requirements.
  • Page 12 SECTION 1 - TECHNICAL SPECIFICATION pickering Electrical & Mechanical Specifications Approx Weight (g) Dimensions (mm) Front Panel Width 60.9 Height 128.5 Overall Length † Power /Current Consumption Maximum 250mA 12V‡ 800/2000mA Minimum 150mA 12V‡ † Approx dimensions. Standard 160mm 3U Eurocard (as specified in DIN 41494.) ‡...

  • Page 13: Technical Description

    SECTION 2 - TECHNICAL DESCRIPTION pickering SECTION 2 - TECHNICAL DESCRIPTION FUNCTIONAL DESCRIPTION A functional block diagram is provided in Figure 2.1. The Matrix Module is powered by +5V, +12V and +5V logic supplies via the backplane connector J1 on the Driver board (most models) or via the Relay card on Models 10-520-011/012.
  • Page 14 SECTION 2 - TECHNICAL DESCRIPTION pickering THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page 2.2...

  • Page 15: Installation

    The module is designed for indoor use only. PRE-OPERATION CHECKS (UNPACKING) 1. Check the module for transport damage and report any damage immediately to Pickering Interfaces. Do not attempt to install the product if any damage is evident. 2. Position the chassis relative to any other equipment the module(s) will connect with. Ensure the chassis is not connected to the electrical supply.
  • Page 16 (See the Pickering 10-910M IEEE-488 GPIB System 10/20 Ancillaries manual for further details). (When fitted, additional modules will be automatically recognised by the interface card. See Figure 3.1). 4. If necessary fit the module guide rails as supplied with the module to both the top and bottom of the chassis in that slot position.

  • Page 17: Software Installation

    Reconfiguring the Driver Card to Your Application Your multiplexer driver card will leave the factory preconfigured, so take great care if you wish to change any of the settings. If in doubt contact Pickering for further details. Universal Driver Card: Configuration Links There are four choices of relay settling time, this is to allow for different applications and relay types (e.g.
  • Page 18 SECTION 3 - INSTALLATION pickering THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page 3.4...

  • Page 19: Programming Guide

    SECTION 4 - PROGRAMMING GUIDE pickering SECTION 4 - PROGRAMMING GUIDE PROGRAMMING THE MODULE Selecting the Module Address Choose a primary device address (from 0 - 30) using the address select switch SW1 on the driver card. Each module must have a different address to the existing modules in the rack or system.
  • Page 20 SECTION 4 - PROGRAMMING GUIDE pickering Programming Using the Intelligent GPIB/RS-232 Interface The programming computer will need a GPIB card, a USB to GPIB Interface (Figure 4.3) or an Ethernet connection to talk to the interface and communicate with the system depending on the type of interface fitted.
  • Page 21 All modules use the same pin outs on two 37 way D-Type connectors. Therefore upgrading from a smaller matrix to a larger one simply means adding pins for the extra connections. Note: Connector shield is tied to System 10/20 ground potential. X Connector Y Connector 37 Way D Type ‘X’...
  • Page 22 SECTION 5 - CONNECTOR INFORMATION pickering X Connector Y Connector 37 Way D Type ‘X’ Connector 37 Way D Type ‘Y’ Connector Pin No. Signal Pin No. Signal Pin No. Signal Pin No. Signal X1.1 X9.1 Y1.1 X1.2 X9.2 Y1.2 X2.1...
  • Page 23 SECTION 5 - CONNECTOR INFORMATION pickering X Connector Y Connector 37 Way D Type ‘X’ Connector 37 Way D Type ‘Y’ Connector Pin No. Signal Pin No. Signal Pin No. Signal Pin No. Signal X1.1 Y1.1 X1.2 Y1.2 X2.1 Y2.1 X2.2...
  • Page 24 SECTION 5 - CONNECTOR INFORMATION pickering THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page 5.4...

  • Page 25: Trouble Shooting

    Refer to the Warnings and Cautions at the front of this manual INSTALLATION PROBLEMS The Plug & Play functionality of Pickering switch cards generally ensures trouble-free installation, however for the GPIB/RS-232 Interface to work correctly there must be at least one switching module present in the rack.
  • Page 26 SECTION 6 - TROUBLE SHOOTING pickering THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page 6.2...

  • Page 27: Maintenance Information

    • Wipe the product & chassis surfaces with a clean dry anti-static cloth only. SOFTWARE UPDATE For System 10/20 modules operating in a System 10/20 chassis, no software updates are required. For the pickeringtest.com latest version of the driver please refer to our web site...
  • Page 28 SECTION 7 - MAINTENANCE INFORMATION pickering RELAY LOOK-UP TABLES Table 7.1 - Relay Look-up Table (All Versions) Signal Path (with relay energised) (8 x 4 Matrix) (8 x 4 Matrix) (16 x 4 Matrix) (16 x 4 Matrix) (8 x 8 Matrix)
  • Page 29 SECTION 7 - MAINTENANCE INFORMATION pickering Table 7.2 - Relay Look-up Table (All Versions) Signal Path (with relay energised) (8 x 4 Matrix) (8 x 4 Matrix) (16 x 4 Matrix) (16 x 4 Matrix) (8 x 8 Matrix) (8 x 8 Matrix)

  • Page 30: Pcb And Component Layout

    SECTION 7 - MAINTENANCE INFORMATION pickering PCB AND COMPONENT LAYOUT R12 Y3 X16.2 RL16 X16.1 X15.2 X15.1 X14.2 X14.1 X13.2 X13.1 X12.2 X12.1 X11.2 X11.1 X10.2 X10.1 X9.2 X9.1 X8.2 X8.1 X7.2 X7.1 X6.2 X6.1 X5.2 X5.1 X4.2 X4.1 X3.2 X3.1...
  • Page 31 SECTION 7 - MAINTENANCE INFORMATION pickering R14 Y6 RL57 X8.2 X7.2 X6.2 X5.2 X4.2 X3.2 X2.2 RL64 X1.2 X8.1 X7.1 X6.1 X5.1 X4.1 X3.1 X2.1 X1.1 Squares Figure 7.2 - 8 x4 and 8 x 8 Matrix PCB Layout A/PC/052 (10-510/530) SWITCHING MATRIX MODULE 10-510/520/530 Page 7.5...
  • Page 32 SECTION 7 - MAINTENANCE INFORMATION pickering Figure 7.3 - SIMM Controller Assy A/PC/178 and 16 x 4 Matrix PCB Layout A/PC/210 Models: 10-520-011/012 and 10-520A-022 SWITCHING MATRIX MODULE 10-510/520/530 Page 7.6...
  • Page 33 SECTION 7 - MAINTENANCE INFORMATION pickering 16 8 4 2 1 16 8 4 2 1 Address UNIVERSAL DRIVER CARD Pickering Interfaces Figure 7.4 - Driver PCB Layout A/PC/050 (10-510/520/530) Note: 10-520-011/012 and 10-520A-022 do not use this driver board.
  • Page 34 SECTION 7 - MAINTENANCE INFORMATION pickering SPARE SPARE R14 Y6 RL57 X8.2 X7.2 X6.2 X5.2 X4.2 X3.2 X2.2 RL64 X1.2 RL32 RL16 RL24 X8.1 RL15 RL31 RL23 X7.1 RL14 RL30 RL22 X6.1 RL13 RL29 RL21 X5.1 RL12 RL28 RL20 X4.1...
  • Page 35 SECTION 7 - MAINTENANCE INFORMATION pickering R12 Y3 X16.2 RL16 RL16 RL32 RL48 RL64 X16.1 X15.2 RL31 RL15 RL47 RL63 X15.1 X14.2 RL46 RL14 RL30 RL62 X14.1 X13.2 RL13 RL29 RL45 RL61 X13.1 X12.2 RL12 RL28 RL44 RL60 X12.1 X11.2...
  • Page 36 SECTION 7 - MAINTENANCE INFORMATION pickering R14 Y6 RL57 RL49 RL57 RL41 RL33 X8.2 RL50 RL58 RL42 RL34 X7.2 RL51 RL43 RL59 RL35 X6.2 RL60 RL52 RL44 RL36 X5.2 RL61 RL53 RL45 RL37 X4.2 RL46 RL38 RL54 RL62 X3.2 RL55...
  • Page 37 SECTION 7 - MAINTENANCE INFORMATION pickering RL17 RL33 RL49 RL34 RL50 RL18 RL19 RL35 RL51 RL20 RL36 RL52 RL21 RL37 RL53 RL22 RL38 RL54 RL23 RL39 RL55 RL24 RL40 RL56 RL25 RL41 RL57 RL10 RL26 RL58 RL42 RL27 RL11 RL43...
  • Page 38 SECTION 7 - MAINTENANCE INFORMATION pickering THIS PAGE INTENTIONALLY BLANK SWITCHING MATRIX MODULE 10-510/520/530 Page 7.12...
