"EGO II" CROSS HANDLE COMBINATION BATH & SHOWER SET TX445SEC
SPECIFICATIONS
150±10
G½
TX445SECM
"EGO" Cross Handle Combination Bath & Shower Set
150±10
G½
TX445SECV1BR
"EGO" Cross Handle Combination Bath & Shower Mixer w/o Hand Shower Set
OPERATING CONDITIONS
1. Water supply pressure : 0.05 ~ 0.75 MPa
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
MAINTENANCE
All Finishes : Clean the finish with mild soap and warm water. Wipe
entire surface completely dry with clean soft cloth. Many cleaners may
contain chemicals, such as ammonia, chlorine, toilet cleaner etc.
which could adversely affect the finish and are not recommended for
cleaning
S06465MS
INSTALLATION
1
MOUNT CONNECTORS PARALLEL WITH THE WALL
Hot
Water
Supply
Leg
2
* Tighten the nut
0
187
-7
3
G ½ 4
187 0
-7
Hand Shower
Packing
Cold
150±10
Water
Supply
Use Seal tape
(Not Include)
150
Packing
Body
Cover
O-Ring
Nut *
2 X Ø8 Holes
Sleeve Anchor
Hanger
Screw
Massage
Spray Button
Rain Spray
Button
Packing
Flexible Hose
TROUBLESHOOTING
CHECK
PROBLEM
POINT
Unsatisfactory spray 1
Flow rate unsatisfactory 2
3
Water leaks around the handle
1. NOZZLES
Flow Regulator Inside
(Don t remove)
2. AERATOR
ATTENTION
1. Don t use abrasive cleaners or solvents on faucets and fittings.
2. Flow Regulator should not be remove because it could damage
the system
3. As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the basic
installation principles are the same.
The hot water supply side of the faucets is in a condition of high
4.
temperature. Do not allow skin to contact with the hardware
surface directly. Otherwise,
scalding may occur.
SOLUTION
Clean
Remove & Clean
Tighten
3. CERAMIC
HEAD WORK
R7
