Summary of Contents for ANLIDAR MyTorq MY8-EP0103L
Page 1
OPERATION AND MAINTENANCE MANUAL MY8-EP0103L MY8-EP0205L MY8-EP0103LF MY8-EP0103P MY8-EP0205P MY8-EP0103PF 版本 3.C DC-TYPE Automatic Non-Carbon-Brush with Counter Series ANLIDAR INDUSTRIAL CO., LTD. http://www.anlidar.com Y2F055A-8E-001...
Page 2
NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injury. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool.
Page 4
d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power tools are dangerous in the hands of untrained users. Do not let visitors touch the tool or extension cord. All visitors should be kept away from work area. e) Maintain power tools.
Grounding Instructions 1、 This tool should be grounded while in use to protect the operator from electric shock. NOTICE! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors.
Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in “OFF “position and tool is unplugged. 2) Do not allow chemicals such as acetone, benzene, thinner, trichloroethylene ketone, or other similar chemicals to come in contact with the screwdriver housing as damage will result.
All repairs and maintenance of this tool and its word must be performed by an authorized service center. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. Repairs should be made only by authorized, trained personnel. Consult your nearest MYTORQ authorized service center.
Panel Specifications Name Function Three-Color Light To Show operating is OK, N.G or in the mode condition. Panel To show set value, set screws number and other value Push five seconds: to disable COUNTING FUNCTION Power Switch CLEAR Push three seconds: CLEAR SELECT Key Push three seconds: Enter the system Up Key...
Page 10
※There is a new judgment which is the screwdriver will judge a N.G.in the case of there is a start signal and it is OFF before Lt. NO. Function Color Black OK ONE Brown OK All Orange open collector contact (4) OK All (3) N.G (2) OK ONE...
Page 11
※Push R key to restore to factory settings. General execution of pre-set program: Ht=2.0 * If stop is among dots, it is normal fastening. “OK”will be shown. * If stop is before Lt or over Ht, it is “N.G.”. * User can freely adjust Lt. However, if Ht and Lt is closer, it will LL=1.0 Lt=0.02 request more accuracy.
4. The power supplier will generate low power when the button of the power controller is switched to "LO." Also, the electric screwdriver's torque output setting value should be adjusted to middle torsion value accordingly. 5. Please refer to Anlidar website http://www.anlidar.com for the detail component list.
