- Page 1 OPERATION AND MAINTENANCE MANUAL MY5-0212L MY5-0319L MY5-0212LF MY5-0317LF MY5-0212P MY5-0319P MY5-0212PF MY5-0317PF DC-TYPE Automatic Non Carbon Brush Series ANLIDAR INDUSTRIAL CO., LTD. http://www.anlidar.com Y2F118A-3E-001...
- Page 2 NOTICE Metal Assembly Screwdrivers are designed for installing threaded fasteners in light industrial and appliance manufacturing applications. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. WARNING Important safety information enclosed. Read all these instructions before placing tool in service or operation this tool and save these instructions. It is the responsibility of the employer to place the information in this manual into the hands of the operator.
-
Page 3: Important Safety Rules
Important Safety Rules WARNING! Read all instructions Failure to follow all instructions listed below may result in electric shock fire and/or serious injure. The term “power tool” in all of the warning listed below refer to your mains operated (corded) power tool or battery operated (cordless) power tool. - Page 4 c) Disconnect the plug from the power source before making any adjustments, changing accessories, or storing the power tools.Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
-
Page 5: Do Not Operate This Tool Without Protective Earth Connected
WARNING！ DO NOT OPERATE THIS TOOL WITHOUT PROTECTIVE EARTH CONNECTED Grounding Instructions 1、This tool should be grounded while in use to protect the operator from electric shock. NOTICE ! To ensure the grounding result, the grounding conductor of the power cord must be well connected with the grounding terminal of power facility. This tool is equipped with grounding conductors. - Page 6 Operations Cautions 1) Whenever changing a bit, make certain the Forward / Reverse Switch is in the “ OFF “ position and tool is unplugged. 2) To avoid damaging the housing of screwdriver, do not allow chemicals get in touch with housing of screwdriver. Ex.: Acetone, benzene, thinner, trichloroethylene ketone, and other similar chemicals.
-
Page 7: Description Of Operation
Description of Operation Attaching / detaching bit and bit type Push up the holder clamp by finger tip, and it will be unlocked. Thus, the bit can be freely attached and detached (single finger notion type) select such a bit whose shank is equal to the size shown below. ... -
Page 8: Do Not Attempt To Repair This Electric Screwdriver
All repairs and maintenance of this tool and its word must be performed by an authorized service center. Anlidar is not responsible for customer modification of tools for applications on which Anlidar was not consulted. Repairs should be made only by authorized, trained personnel. Consult your nearest MYTORQ authorized service center. -
Page 9: Specifications
Specifications MODEL MY5-0212L MY5-0319L MY5-0212LF MY5-0317LF MY5-0212P MY5-0319P MY5-0212PF MY5-0317PF Input voltage(DC) DC 24V OR 32V Power Consumption (kgf.cm) 1.5-12 3-19 1.5-12 3~17 2-12 3-19 2-12 3~17 Torque (Lbf.in) 1.33-10.44 2.57-16.46 1.33-10.44 2.57-16.46 2.57~14.78 1.77~10.44 1.77~10.44 2.57~14.78 (N.m) 0.15-1.18 0.29-1.86 0.15-1.18 0.29~1.67 0.2~1.18... -
Page 10: Torque Adjustment Operation
6. The power supplier will generate low power when the button of the power controller is switched to "LO." Also, the electric screwdriver's torque output setting value should be adjusted to middle torsion value accordingly. 7. Please refer to Anlidar website http://www.anlidar.com for the detail component list.
