ANLIDAR MYTORQ MYBT-AS0212 Operation And Maintenance Manual

Automatic industrial cordless brushless power torque screwdrivers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Automatic Industrial Cordless Brushless
Power Torque Screwdrivers Series
OPERATION AND MAINTENANCE MANUAL
MYBT-AS0212
MYBT-AS0212S1
Rechargeable -TYPE Automatic Brushless Series
ANLIDAR INDUSTRIAL CO., LTD.
http://www.anlidar.com
Y2F228A-3E-001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MYTORQ MYBT-AS0212 and is the answer not in the manual?

Questions and answers

Related Manuals for ANLIDAR MYTORQ MYBT-AS0212

Summary of Contents for ANLIDAR MYTORQ MYBT-AS0212

  • Page 1 Automatic Industrial Cordless Brushless Power Torque Screwdrivers Series OPERATION AND MAINTENANCE MANUAL MYBT-AS0212 MYBT-AS0212S1 Rechargeable -TYPE Automatic Brushless Series ANLIDAR INDUSTRIAL CO., LTD. http://www.anlidar.com Y2F228A-3E-001...

  • Page 2: Icon Instructions

    Before you use the Cordless Screwdriver for the first time, it is essential to read and understand the manual completely (including the spare parts view). The term “Cordless Screwdriver” in all of the warning listed below refers to your main operated appliance Icon Instructions 1.
  • Page 3 16. To prevent parts in gearbox from damage, replace the grease at least once for every year. 17. It is necessary for the operators to read and follow up all the operating instructions in this manual. ANLIDAR is not responsible for any personal injury that might cause of disobeying the safety advices.
  • Page 4 2. Do not attempt to disassemble or reassemble the device it may result in poor performance or danger of injury, the warranty applies only to initial package. 3. Do not repair the device with other than genuine ANLIDAR replacement parts may result in poor performance or danger of injury, the warranty will be considered void.
  • Page 5 Follow belw steps to correctly install & remove battery. Insert Battery Steps Remove Battery Steps (1) Press the release button and take it out of the (1) Take screwdriver and battery. Device. Battery Release Button (2) Insert the rechargeable battery into the device (2) Follow the arrow direction.

  • Page 6: Function / Operating Introduction

    Function / Operating Introduction Function Name Table Description Description Trigger Switch Torque Fixing Ring/Coupler Forward/Reverse Lever S Waist Hook Bit Sleeve OK/NG/Power/Hi&Lo Indicating Light Torque Fixing Ring battery...

  • Page 7: Manual / Function

    Manual / Function Full Auto Shut-Off Screwdriver It stops automatically when the screw has been tightened up and reached the set-up torque level. The device will not cause damage of task since no continue running after screws are tightened. (1) Trigger Switch The LED lights are on when the trigger switch has been pressed about one-third down, and then the screwdriver starts functioning when the switch trigger has been pressed half way down;...
  • Page 8 (3) Bit Sleeve To Switch the bit and compatibility, pull the head of the type B screwdriver, and install the bit according to the diagram below, and push it in following the arrow indicated on the diagram. Pull the bit holder Insert the bit (4) Torque Adjustment Ring: Turn torque adjust ring counter clock wise to increase torque output, on the other hand decrease...
  • Page 9 OK/NG/Power/Hi&Lo Indicating Light Explanation Protection Explanation: The indicating LEDS will show Hi/Lo when push Forward/Reverse lever to the middle position. Speed can't be adjusted when temperature protection is activated. Please wait until temperature protection is deactivated. Release Screw Current Start switch to reaches set Screw NG...

  • Page 10: Other Cautions

    3. ANLIDAR is not responsible for any poor performance or damage caused by customers own modification of the tool. 4. It is necessary for the management to have every operator to read and follow all instructions in this manual.

  • Page 11: Specifications

    Specifications MODEL MYBT-AS0212 MYBT-AS0212S1 INPUT VOLTAGE(DC) DC 10.8V hard joints 0.2-1.2 0.2-1.2 TORQUE soft joints (N.m) 0.2-0.96 0.2-0.96 80%↓ Torque accuracy (%) ±3% Torque adjustment Stepless Duty cycle 1.0s ON 3.0s OFF 1000 Unloaded Speed (min )±10% Machine Screw size (mm) 1.6~3.0 1.6~3.0 screw...

  • Page 12: Torque Adjustment Operation

    In reverse rotation, the clutch is turned off when a screw is tightened at large torque, set same or higher torque to unscrew. The number from zero to eight on the Torque Scale are reference number only and not an indication of actual torque output. Please refer to ANLIDAR website http://www.anlidar.com for the detail component list.

This manual is also suitable for:

Mytorq mybt-as0212s1
