S S p p e e c c i i f f i i c c a a t t i i o o n n s s

Network Protocols Supported

Network Interface

Printer Interface

Printing Modes Supported

Power Adapter Specifications

Dimensions/Weight

Warranty

Regulatory Certifications

Network Connection/Activity

Powered/Online

Ready to Print

Instruction Manual

TCP/IP (static or DCHP modes), NetBEUI, SNMP, IPX/SPX,

Apple Talk

RJ-45 Ethernet (auto-detects straight through/crossover)

10 or 100 Mbits/sec. (auto negotiated)

1 x USB 2.0/1.1 Type A (PM1115U)

1 x Integrated Centronics 36-pin (male) (PM1115P)

LPR, RAW, IPP, SMB/TCP, UNIX Logical Printer

DC9V, 200mA, center positive

PM1115U 2.9" x 2.25" x 0.75" (74 x 56 x 20 mm) LxWxH

PM1115P 3.4" x 2.5" x 0.75" (83 x 64 x 20 mm) LxWxH

Weight 2.4 oz. (68g)

1 year (see Warranty Statement for further details)

FCC Class B, CE, C-Tick

Reset (hold for 5 seconds)
