VESTEL CMH-XXL 9412 TE User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VESTEL
WASHING MACHINE
USER MANUAL
CMH-XXL 9412 TE

Advertisement

Table of Contents
loading

Related Manuals for VESTEL CMH-XXL 9412 TE

Summary of Contents for VESTEL CMH-XXL 9412 TE

  • Page 1 VESTEL WASHING MACHINE USER MANUAL CMH-XXL 9412 TE...

  • Page 2: Table Of Contents

    CONTENTS CHAPTER-1: TECHNICAL SPECIFICATIONS CHAPTER-2: BEFORE USING WASHING MACHINE Safety warnings Recommendations CHAPTER-3: SETTING UP ..Removing transport safety screws Adjusting adjustable stays Electrical connection Water inlet connection Water discharge connection CHAPTER-4: PRELIMINARY PREPARATION FOR LAUNDERING CHAPTER-5: CONTROL PANEL Detergent drawer Programme knob Electronic display CHAPTER-6: OPERATING YOUR MACHINE...

  • Page 3: Chapter-1: Technical Specifications

    CHAPTER -1: TECHNICAL SPECIFICATIONS 1.Detergent drawer 2.Upper tray 3.Programme knob 4.Electronic display 5.Door 6.Cover of pump filter 7.Transport safety screw 8.Power cable 9.Discharging hose 10.Water inlet valve...
  • Page 4 CHAPTER -1: TECHNICAL SPECIFICATIONS Operating voltage / frequency (220-240) V ~/60Hz (V/Hz) Total current (A) Maximum: 1 Mpa Water pressure (Mpa) Minimum: 0.1 MPa 2200 Total power (W) Maximum dry laundry capacity (kg) Wringing revolution (rev / min) Programme number Dimensions 845 x 597 x 582 (Height x Width x Depth) (mm)

  • Page 5: Chapter-2: Before Using Washing Machine

    CHAPTER -2: BEFORE USING YOUR WASHING MACHINE SAFETY WARNINGS SAFETY WARNINGS Do not use multiple receptacles or extension cord. Do not plug in damaged or torn plugs. In case of a breakdown of power cable, contact the nearest authorized service for replacing it. Never pull the cable when unplugging.

  • Page 6: Recommendations

    CHAPTER -2: BEFORE USING YOUR WASHING MACHINE SAFETY WARNINGS / RECOMMENDATIONS You should absolutely remove the transport screws of your machine before the first usage. Faults occurring in the machines operated with transport screw fitted shall be out of scope of warranty.

  • Page 7: Chapter-3: Setting Up

    CHAPTER -3: SETTING UP REMOVING TRANSPORT SAFETY SCREWS Before operating your washing machine, you should certainly remove the transport safety screw on the rear side of the machine. For this reason, transport safety screws shall be loosened by being rotated in counter-clockwise using an appropriate wrench.
  • Page 8 CHAPTER -3: SETTING UP REMOVING TRANSPORT SAFETY SCREWS Transport screws shall be removed by pulling out. Fit the plastic transport screw taps delivered in accessories bag to the places where transport screws have been removed. The transport safety screws should be stored to be used in case of a transportation.

  • Page 9: Adjusting Adjustable Stays

    CHAPTER -3: SETTING UP ADJUSTING ADJUSTABLE STAYS Do not install your machine on a carpet or suchlike grounds. To ensure silent and vibration-free operation of your machine, it should be deployed on a non-sliding and firm ground. Loosen the plastic adjustment nut. Adjust the stays upward and downward by rotating them.

  • Page 10: Electrical Connection

    CHAPTER -3: SETTING UP ELECTRICAL CONNECTION / WATER INLET CONNECTION Electrical connection Your washing machine is set to 220-240V and 60Hz. Mains cord of your washing machine is equipped with a specific grounded plug. This plug should always be inserted to a grounded receptacle of 10 amperes.

  • Page 11: Water Discharge Connection

    CHAPTER -3: SETTING UP WATER INLET CONNECTION / WATER D SCHARGE CONNECTION Water discharge connection Ensure that water discharge hose is not folded, twisted, crushed or elongated. Water discharge hose can be fitted minimum 60 cm and maximum 100 cm above the ground. The end of water discharge hose can be fitted to a specific apparatus directly attached to dirty water discharge hole or outlet joint of the basin elbow.

  • Page 12: Chapter-4: Preliminary Preparation For Laundering

    CHAPTER-4: PRELIMINARY PREPARATION FOR LAUNDERING SEPARATING LAUNDRIES Separate your laundries according to their types (cotton, synthetic, sensitive, woollen, etc.), their temperatures (cold, 30°, 40°, 60°, 90°) and degree of contamination (slightly stained, stained, highly stained). Never wash your coloured and white laundries together. Wash your coloured laundries separately in the first washing as they may bleed.
  • Page 13 CHAPTER-4: PRELIMINARY PREPARATION FOR LAUNDERING SEPARATING LAUNDRIES Ironing No whitening Whitening temperature is available maximum 110°C Ironing Ironing temperature is temperature is No ironing maximum 150°C maximum 200°C No dry cleaning Dry cleaning Leave on a flat available place Drying by twirling Hang when wet Dry by hanging is not allowed...
  • Page 14 CHAPTER-4: PRELIMINARY PREPARATION FOR LAUNDERING PUTTING LAUNDRIES IN THE MACHINE Open the door of your machine. Spread your laundries in your machine. Note: Maximum loading capacity may vary based on the laundry type you will wash, degree of contamination and the programme you have chosen.
  • Page 15 CHAPTER-4: PRELIMINARY PREPARATION FOR LAUNDERING ADDING DETERGENT INTO MACHINE The amount of detergent you will put in your machine will depend on the following criteria: Your detergent utilization will be based on the degree of contamination of your laundries. Do not prewash your less stained laundries and put your slight amount of detergent in the 2 compartment of the detergent drawer.

  • Page 16: Chapter-5: Control Panel

    CHAPTER 5: CONTROL PANEL...

  • Page 17: Detergent Drawer

    CHAPTER 5: CONTROL PANEL DETERGENT DRAWER A. Prewashing compartment B. Main washing compartment C. Softener compartment D. Siphon cover E. Liquid level detergent plate...

  • Page 18: Programme Knob

    CHAPTER 5: CONTROL PANEL PROGRAMME KNOB You may select the programme you like to wash your laundries through programme knob. You may set the programme selection operation by rotating the programme knob in both direction. Ensure that the programme knob is exactly on the programme you want to select.

  • Page 19: Electronic Display

    CHAPTER 5: CONTROL PANEL ELECTRONIC DISPLAY 1-Adjusting button for revolution speed 2-Adjusting button for temperature of washing water 3-Auxiliary function prewash 4-Auxiliary function for rapid wash 5-Auxiliary function for easy ironing 6-Auxiliary function for delay timer 7-Start/Pause button 8-Electronic display On the electronic display, you may view washing water temperature, wringing revolution speed of your machine, the amount time your machine will continue washing, the auxiliary functions you have...

  • Page 20: Chapter-6: Operating Your Machine

    CHAPTER 6: OPERATING YOUR MACHINE Plug your machine in. Open the water faucet. Open the machine door. Spread your laundries in your machine. Push the door of your machine until hearing the locking sound to close it. Put detergent and softener in the detergent drawer. First washing operation Some water may be left in your machine due to experiments and tests carried out during production.
  • Page 21 CHAPTER 6: OPERATING YOUR MACHINE Half-load detection system Your machine features a half-load detection system. In case you put approximately half or less amount of laundries of maximum laundry capacity in your machine, your machine will run so as to save washing time, water consumption and energy in some programmes (White cotton 95°, Colorfast cotton 60°, Non colorfast cotton 40°).
  • Page 22 CHAPTER 6: OPERATING YOUR MACHINE PROGRAM TABLE MAXIMUM AMOUNT OF TEMPERATURE DETERGENT PROGRAMME LAUNDRY TYPE (°C) COMPARTMENT LAUNDRY (kg) Very dirty cotton and flax textiles. (Underwears, linen, tablecloth, towel (maximum 1- COTTON 4 kg), bedclothes, etc. Dirty cotton and flax textiles. (Underwears, linen, tablecloth, towel (maximum 4 kg), 2- COTTON bedclothes, etc.
  • Page 23 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 1-Revolution speed selection and auxiliary function of soaking You can set the wringing revolution for your laundries via revolution speed setting button. When you select a new programme, the maximum wringing revolution speed of the programme you have selected will be viewed on the display of revolution speed.
  • Page 24 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS If this function is selected, your laundries will be soaked in the latest rinsing water. When your machine soaks your laundries in the latest rinsing water, symbol will blink on electronic display. If you want to take your laundries out, press on “Start / Pause” button. Your machine will empty the water in it and finish the programme without wringing.
  • Page 25 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 2-Washing water temperature selection You can select the washing water temperature with the washing water temperature adjustment button. Whenever you select a new programme, the maximum washing water temperature is shown on the washing water temperature display.
  • Page 26 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 3-Auxiliary function prewash You can expose your very dirty laundries to prewashing operation prior to main washing by using this auxiliary function. When using this function, you should put detergent in front washing compartment of the detergent drawer.
  • Page 27 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 6-Auxiliary function for delay timer By using this auxiliary function, you can let your machine start washing after half an hour to 23 hours. To use auxiliary function of delay timer: - Press time delay button once. - Expression of “0.5h”...
  • Page 28 CHAPTER 6: OPERATING YOUR MACHINE AUXILIARY FUNCTIONS 7-Anti-Allergic auxiliary function In the programmes where this auxiliary function is active, your machine will perform an extra rinsing operation on your laundries prior to latest rinsing operation. Note: Anti-Allergic auxiliary function is selected automatically only in Hygiene programme.

  • Page 29: Starting The Programme

    CHAPTER 6: OPERATING YOUR MACHINE STARTING THE PROGRAMME Start/Pause button By pressing on Start/Pause button, you may start the programme you have selected, suspend a running programme. If you switch your machine to pause mode, electronic display will blink. When you start your machine, the following symbols for the programmes you have selected will be available on electronic display.

  • Page 30: Adding/Removing Laundry

    CHAPTER 6: OPERATING YOUR MACHINE ADDING/REMOVING LAUNDRY Laundry adding to / removing from the machine If you want to add or remove laundries when your machine is running: - Switch your machine to pause mode by pressing on Start/Pause button. - After a while, if you realize that symbol moves over electronic display, this means that the door of your machine will be convenient...

  • Page 31: Child Lock

    CHAPTER 6: OPERATING YOUR MACHINE CHILD LOCK Child lock To avoid programme flow from being affected if programme knobs are pressed or programme knob is turned when performing washing operation in your machine, child lock is available. Child lock will be activated in case pressed on both auxiliary functions of quick washing and wrinkle removing at the same time in excess of 3 seconds.

  • Page 32: Cancelling Programme

    CHAPTER 6: OPERATING YOUR MACHINE CANCELLING PROGRAMME Cancelling programme If you want to cancel any programme running: - Switch the programme knob to 0. - Your machine will stop the washing operation and the programme will be cancelled. - To get rid of the water accumulated in the machine switch the programme knob to any programme.

  • Page 33: Finishing Programme

    CHAPTER 6: OPERATING YOUR MACHINE FINISHING PROGRAMME Finishing programme - Your machine will stop by itself as soon as the programme you have selected finishes. -Expression of “END” will flash on the electronic display. Note: Within 2 minutes after the programme has finished, your machine will extinguish the electronic display to save energy.

  • Page 34: Chapter-7: Electronic Display Warning Symbols

    CHAPTER -7: ELECTRONIC DISPLAY WARNING SYMBOLS WARNING OF WATER CUT-OFF / LOW MAINS WATER PRESSURE If symbol flashes on the electronic display: - Water faucet may be closed. Check. - Mains water may be cut-off. Check. If so, switch the programme knob to position 0.

  • Page 35: Warning Of Clogged Pump Fitler

    CHAPTER -7: ELECTRONIC DISPLAY WARNING SYMBOLS WARNING OF CLOGGED PUMP FILTER If symbol flashes on the electronic display: - Pump filter may be clogged. Clean the pump filter. (*) - Discharging hose may be clogged or twisted. Check the discharging hose.

  • Page 36: Chapter-8: Maintenance And Cleaning Of Your Machine

    CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE Unplug your machine. Turn the water faucet off. WATER INLET FILTERS Filters to avoid dirt and foreign substances in the water from penetrating into the machine are available both on the side of faucet and on the ends of water valves along the water inlet hose of your machine.
  • Page 37 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / PUMP FILTER A filter system which avoids threads remaining from your laundries and tiny materials from entering into the pump during water discharging operation carried out by your machine after completing washing so prolonging the lifecycle of your pump is available.
  • Page 38 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / PUMP FILTER After cleaning the filter, fit the filter cover by rotating it in clockwise. Fit the pump section of the toe board. Remember that water will leak if you do not fit the filter cover properly.
  • Page 39 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / DETERGENT DRAWER Your detergents may deposit residue in detergent drawer and housing of detergent drawer over time. To clean the residue formed, disassemble the detergent drawer in particular periods. To eject the detergent drawer: Pull the detergent drawer up to the end Keep on pulling by depressing on the flush cover in the detergent...
  • Page 40 CHAPTER -8: MAINTENANCE AND CLEANING OF YOUR MACHINE / SIPHON PLUG / BODY / DRUM Siphon plug Disassemble the detergent drawer. Disassemble the flush stopper and clean the softener residues completely. Refit the flush stopper after cleaning it. Check whether it has settled properly. Body Clean the outer body of your machine with warm water and a non- inflammable cleaning agent that will not abrade the body of your...

  • Page 41: Chapter-9: Practical Information

    CHAPTER -9: PRACTICAL INFORMATION Alcoholic drinks: Spotted area should initially be washed using cold water, and then be wiped with glycerine and water and rinsed with vinegar-mixed water. Shoe shine: Spot should be rubbed out gently without damaging the cloth and be scrubbed and rinsed with detergent.
  • Page 42 CHAPTER -9: PRACTICAL INFORMATION Blood stain: Submerge your laundries in cold water for 30 minutes. If the stain is not removed, then submerge in a mixture of water and ammoniac (3 spoons of ammoniac in 4 litres of water) for 30 minutes. Cream, ice cream and milk: Submerge your laundries in cold water and scrub the spotted area with detergent.

  • Page 43: Chapter-10: Troubleshooting

    CHAPTER -10: TROUBLESHOOTING All repairing operations required for your machine should be carried out by our authorised service. If your machine requires a repair or if you cannot remove the fault by the help of the information provided as follows: Unplug your machine.
  • Page 44 CHAPTER -10: TROUBLESHOOTING REMOVING FAULT POSSIBLE CAUSE METHODS Discharging hose Check the clogged or twisted. discharging hose. Clean the pump Pump filter clogged. Your machine does filter. (*) not discharge water. Spread your Laundries settled in laundries in the the machine non- machine properly homogeneously.
  • Page 45 CHAPTER -10: TROUBLESHOOTING REMOVING FAULT POSSIBLE CAUSE METHODS Press on Start/Pause button. To eliminate foam formation, mix a spoon of softener with half litres of water, and pour the mixture Excessive amount of in the detergent detergent used. drawer. After 5-10 Excessive foam is minutes, press on formed in the...
  • Page 46 CHAPTER -10: TROUBLESHOOTING REMOVING FAULT POSSIBLE CAUSE METHODS Adjust the amount of detergent based on Water being hard. the instruction of (Dirty, hard, etc.) detergent Unsatisfactory manufacturer. washing result. Spread your laundries Laundries distributed in the machine in your machine non- properly and homogenously.
  • Page 47 CHAPTER -10: TROUBLESHOOTING REMOVING FAULT POSSIBLE CAUSE METHODS Unbalanced load control system will try to spread your laundries homogeneously. Wringing operation No fault. Unbalanced Wringing operation is will start after load control system not performed or spreading your has been activated. runs late.

  • Page 48: Chapter-11: Automatic Fault Warnings And What To Be Done

    CHAPTER -11: AUTOMATIC FAULT WARNINGS AND WHAT TO BE DONE Your machine is equipped with the systems which are capable of both taking necessary precautions and warning you in case of any breakdown by means of continuous self-checking during washing operations.
  • Page 49 CHAPTER -11: AUTOMATIC FAULT WARNINGS AND WHAT TO BE DONE TROUBLE CODE POSSIBLE WHAT TO DO FAULT - Water faucet may be closed. Check. - Mains water may be cut-off. Check. - If so, switch the programme knob to position 0. You can select a programme and run your machine after the mains water is supplied.

  • Page 50: Chapter-12: Describing And Saving Energy

    CHAPTER -12: DESCRIBING SAVING ENERGY Energy and water consumption may vary based on water pressure, water hardness, water temperature, ambient temperature, laundry amount, additional function selection, voltage fluctuations. It will reduce energy and water consumption to use your machine with the laundry capacity proposed for the selected programme, wash your laundries less dirty or daily laundries in short programmes, carry out cleaning and maintenance periodically, use your machine in convenient time intervals specified by electricity...
  • Page 51 DISPOSAL OF YOUR OLD MACHINE This symbol on the product or package implies that the product should not be treated as domestic waste. Instead, it should be delivered to applicable waste collection places recycling electrical and electronic equipment. You will contribute to avoid potential negative results regarding environment and human health, which will arise due to wrong waste procedure for the product by ensuring that this product is...
  • Page 52 The lifetime of your product (the period during which the spare parts will be provided for its proper functioning) evaluated and announced by the Ministry of Customs and Trade is 10 years Producer Company: Vestel Beyaz Eşya Sanayi ve Ticaret A.Ş. Organize Sanayi Bölgesi 45030 Manisa - Türkiye Phone: 44 44 123 Fax: (0212) 321 17 90...
