Summary of Contents for DeLonghi GH160
- Page 1 GH160 gas hob Users Operating Instructions Before operating this hob, please read these instructions carefully...
- Page 2 Dear Customer Thank you for choosing one of our appliances which has been carefully designed and built by our specialist staff and thoroughly tested to satisfy all your cooking requirement. We suggest that you read this Instruction Booklet so that you will understand fully how to operate the appliances.
-
Page 3: Table Of Contents
Contents Model GH160 Page Number How to use your hob ..........4 Cleaning and maintenance . -
Page 4: How To Use Your Hob
How to use your gas hob 1. Medium burner 2. Medium burner 3. Large burner 4. Small burner 5. Operates burner 2 6. Operates burner 1 7. Operates burner 3 8. Operates burner 4 9. Ignition figure 1 Check that the electricity is switched on to allow automatic ignition. Make sure that all controls are turned to zero. -
Page 5: Cleaning And Maintenance
Always ensure you use the correct size of saucepan. See fig. 3. Always ensure that the bottom of the pan you are using is dry. figure 3 Cleaning and Maintenance General After use and while the hob is still warm it should be wiped with a damp cloth. When cleaning care should be taken to avoid water leaking into the control panel as this way cause damage to the controls. -
Page 6: Important Notes
Important notes Installation, and any demonstration, information or adjustments are not included in the warranty and, if requested, the customer must pay the after-sale service according to the standard fees. Before calling for assistance If any burner does not light, check the ignition is working, if not check the 3 amp fuse, make sure gas is turned on make sure burner caps are in Position correctly. -
Page 7: Do's And Do Not's
Do’s and do not’s Do’s and do not’s • Do read the User Instructions carefully before using the hob for the first time. • Do remove spills as soon as they occur. • Do not allow children near the hob when in use. •... -
Page 8: For The Installer
For the installer Gas connection - Important note This appliance is supplied for use on NATURAL GAS only and cannot be used on any other gas without modification. To purchase an L.P.G. conversion kit contact 0113 2310523 and quote part number 6305302. The gas hob must be installed by a qualified person in accordance with the Gas Safety Regulations 1984 and the relevant Building / I.E.E. - Page 9 Warning! This appliance must be earthed 3 amp fuse Green & Yellow Earth Blue Neutral Brown Live figure 4 A properly earthed three pin plug (fused at 3 amps, to BS 1362 ASTA approved) must be used. As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows.
-
Page 10: Hob Installation
Hob installation The hob requires a space in the kitchen work surface as shown in the diagram Fig. 5. A partition between the base of the hob and the cupboard below should be fitted 100 mm below the worktop if the cupboard is to be used for storage. figure 5 Note that the hob should be positioned 50 mm from the rear of the kitchen worktop. -
Page 11: Ventilation
Ventilation (gas hob) All rooms require an openable window or equivalent, while some rooms require a permanent vent in addition to a window that can be opened. This unit must not be used in a room with less than 6 m room volume air vent necessary (effective area) to 9 m... - Page 12 GH160 gas hob 1101119 ed. 3 - ß7...
