- Page 1 DE ’ L O N G H I C OO KING INSTALLATION and SERVICE INSTRUCTIONS USE and CARE INSTRUCTIONS N SL 460 NC M N SL 590 D N CM BUILT-IN GAS ON GLASS COOKING HOBS distributed by ELBA Appliances Australia (a Division of Fisher&Paykel Australia)
-
Page 2: Product Label
Dear Customer, Thank you for having purchased and given your preference to our product. The safety precautions and recommendations reported below are for your own safety and that of others. They will also provide a means by which to make full use of the features offered by your appliance. -
Page 3: Important Safety Precautions And Recommendations
IMPORTANT SAFETY PRECAUTIONS AND RECOMMENDATIONS IMPORTANT: This appliance is designed and manufactured solely for the cooking of domestic (household) food and is not suitable for any non domestic application and therefore should not be used in a commercial environment. The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. - Page 4 ■ CAUTION: this appIiance must only be installed in a permanently ventilated room in compliance with the applicable regulations. ■ Do not carry out cleaning or maintenance operations on the appliance without having previously disconnected it from the electric power supply. ■...
- Page 5 To avoid burns and scalds, young children should be kept away. – ■ Make sure that electrical cables connecting other appliances in the proximity of the cooktop cannot come into contact with the hob. ■ WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire.
-
Page 6: Installation
INSTALLATION CAUTION: ■ Important: The use of suitable protective clothing/gloves is recommended when handling or cleaning of this appliance. ■ This appliance must be installed in accordance with these installation instructions, local gas fitting regulations, municipal building codes, water supply regulations, electrical wiring regulations, - Gas Installations and ony other relevant statutory regulations. - Page 7 3. The wire which is coloured brown must be connected to the terminal marked “L” (Live) or “A” (Active) or coloured Red. ■ A suitable isolating switch providing full disconnection from the mains power supply (under overvoltage category III conditions) shall be incorporated in the permanent wiring, mounted and positioned to comply with the local wiring rules and regulations.
- Page 8 Thermal Clearance protection barrier Door Space for Figure 2b Figure 2c connections Measures (mm) Description (minimum) (minimum) Model NSL 460 NCM 54 (*) 60 (**) 200 (***) Model NSL 590D NCM 54 (*) 60 (**) 200 (***)
- Page 9 From top of countertop (**) Between the back edge of the cut-out and the back of the countertop. (***) From the side edge of the cut-out to any vertical combustible surface. If this distance is less than 200 mm, the surface shall be protected (in accordance with AS/NZS5601.1) to a height of not less than 150 mm above the hob for the full dimension (width or depth) of the cooking surface area.
- Page 10 30 to 40mm thick. Model NSL 460 NCM, (fig. 3a): The kit includes two “F” type brackets (for the front of the cooktop), two “R” type brackets (for the rear of the cooktop) and four self- threading screws “S”.
- Page 11 Figure 3d Figure 3e Rear Fixing Brackets Front Fixing Brackets G (G1) G (G2)
-
Page 12: Gas Supply
1 kPa: – with the two semi-rapid (SR) burners Gasket operating at the maximum - model NSL 460 NCM only; – with the double-ring (DR) burner Brass conical adaptor Test (Thread tight: use... - Page 13 The operation of the appliance MUST be tested before leaving. Adjust the test point pressure or supply pressure to the value which is appropriate for the gas type. Turn on the appliance gas controls and light each burner. Check for a well defined blue flame without any yellow tipping.
- Page 14 1.04 14.10 Only for the model NSL 590D NCM Only for the model NSL 460 NCM Only for the model NSL 590D NCM (Note: Gas type sticker and data plate are attached to the underside of the base of the appliance.)
- Page 15 The burners are designed so that regulation of primary air is not required. Figure 5a Double-ring compact burner (only for the model NSL 460 NCM) Figure 5b Double-ring burner (only for the model NSL 590D NCM) Figure 5c...
- Page 16 MINIMUM BURNER SETTING ADJUSTMENT Check whether the flame spreads to all burner ports when the burner is lit with the gas tap set to the minimum position. If some ports do not light, increase the minimum gas rate setting. Check whether the burner remains lit even when the gas tap is turned quickly from the maximum to the minimum position.
- Page 17 USE and CARE CAUTION: ■ This appliance must be used only for the task it has explicitly been designed for, that is for domestic cooking of foodstuffs. Any other form of usage is to be considered as inappropriate and therefore dangerous. Do not use this appliance as a space heater. ■...
-
Page 18: Gas Burners
GAS BURNERS Auxiliary (A) Semi-rapid (SR) Semi-rapid (SR) Rapid (R) Double-ring compact (DRC) Double-ring (DR) CONTROL KNOBS Burner control knob (1) - Auxiliary Burner control knob (2) - Semi-rapid Burner control knob (3) - Semi-rapid 10. Burner control knob (4) - Rapid 11. -
Page 19: Using Gas Burners
USING GAS BURNERS ■ Check that the electricity is switched on to allow spark ignition. ■ ” (burner off). Make sure that all controls are turned to “ ■ The gas flow to the burner is controlled by a tap incorporating a safety cut-off valve. If the burner flame should go out for some reason, the safety valve will automatically stop the gas flow. - Page 20 LIGHTING GAS BURNERS FITTED WITH FLAME FAILURE SAFETY DEVICE In order to light the burner, you must: Turn the knob (figs. 8a - 8b) in anti-clockwise direction up to the maximum aperture (symbol “ ”), push in and hold the knob; this will light the gas. If there is no mains electrical supply, bring a lighted match close to the burner.
- Page 21 14 cm Semi-rapid 16 cm 24 cm Rapid (model NSL 590D NCM) 24 cm 26 cm Double-ring compact (model NSL 460 NCM) 26 cm 28 cm Double-ring (model NSL 590D NCM) 26 cm 28 cm Wok (*) Max 36 cm...
- Page 22 WOK STAND (THE WOK PAN ADAPTOR IS NOT SUPPLIED WITH THE APPLIANCE BUT IT CAN BE PURCHASED SEPARATELY) (figs. 11 - 12) This special grille for woks should be placed over the pan-rest for the double-ring compact or double ring burner (depending on models). Warning: ■...
- Page 23 Do not place anything, e.g. flame tamer, asbestos mat, between pan and pan support as serious damage to the appliance may result. Do not remove the pan support and enclose the burner with a wok stand as this will concentrate and deflect heat onto the hotplate.
-
Page 24: Cleaning And Maintenance
CLEANING and MAINTENANCE GENERAL ADVICE Before you begin cleaning, you must ensure that the appliance is switched off ■ and disconnected from the electrical power supply. ■ Important: The use of suitable protective clothing/gloves is recommended when handling or cleaning of this appliance. ■... -
Page 25: Enamelled Parts
ENAMELLED PARTS ■ All the enamelled parts must be cleaned with a sponge and soapy water only or other non-abrasive products. ■ Dry preferably with a soft cloth. ■ If acid substances such as lemon juice, tomato conserve, vinegar etc. are left on the enamel for a long time they will etch it, making it opaque. - Page 26 They shall be level and the flame spreader must not rotate. CORRECT REPLACEMENT OF THE DOUBLE-RING COMPACT (model NSL 460 NCM) AND DOUBLE-RING BURNER (model NSL 590D NCM) It is very important to check that the burner flame spreader “F1” and “F2” and the caps “A”, “B”...
- Page 27 DOUBLE-RING BURNER DOUBLE-RING COMPACT BURNER (Model: NSL 460 NCM) (Model: NSL 590D NCM) Figure 15c Figure 15d Figure 15e Figure 15f...
-
Page 28: Pan Supports
This is a natural phenomenon and does not prevent the parts from working properly. DOUBLE-RING COMPACT (model AUXILIARY, SEMI-RAPID AND RAPID NSL 460 NCM) AND DOUBLE RING BURNER (Rapid burner model BURNER (model NSL 590D NCM) -
Page 29: Service And Maintenance
SERVICE AND MAINTENANCE If the ignition spark fails to ignite or does not light the gas, check the following items before calling our Customer Service Centre to obtain the nearest Authorised ELBA APPLIANCES Service Agent shared services with Fisher and Paykel Australia PTY LTD (ELBA Appliances AUS, a division of F&P AUS PTY LTD). - Page 32 Descri pt i ons an d ill ustrati ons in this booklet a re giv en as simpl y ind icat ive. T h e ma nuf a ct ur er r es erv es the right, consider ing t he cha ract eri stics o f t he models described here, at any time and without notice, to make eventual necessary mo d ifi cat i on s f or the ir constr ucti on or for com merc ial n eeds.
