Sauder Dakota Pass 422592 Manual

Lift-top coff ee table
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Lift-Top Coff ee Table
Dakota Pass Collection | Model 422592
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
It's addicting.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-19
Français pg 20-22
Español pg 23-25
Lot # 506725
08/07/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Dakota Pass 422592

Summary of Contents for Sauder Dakota Pass 422592

  • Page 1 Dakota Pass Collection | Model 422592 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.

  • Page 2: Table Of Contents

    RIGHT END (1) SHELF (1) BRACE (1) LEFT END (1) RIGHT FRONT/LEFT REAR LEG (2) PANEL MOLDING (2) UPRIGHT (1) LEFT FRONT/RIGHT REAR LEG (2) SHELF MOLDING (2) TOP (1) PANEL (2) E2 BOTTOM (1) SKIRT (2) Page 2 422592 www.sauder.com/services...

  • Page 3: Part Identifi Cation

    Now you know Part Identifi cation Part Identifi cation our ABCs. www.sauder.com/services 422592 Page 3...

  • Page 4: Hardware Identifi Cation

    BLACK 9/16" LARGE HEAD SCREW - 24 SILVER 1-1/8" FLAT HEAD SCREW - 6 BLACK 3/4" PAN HEAD SCREW - 2 BLACK 3/4" MACHINE SCREW - 4 113S BLACK 1-15/16" FLAT HEAD SCREW - 10 BLACK 1-1/4" MACHINE SCREW - 4 Page 4 422592 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=2074...
  • Page 6 Push eight HIDDEN CAMS (1F) into the exact holes shown å in the ENDS (A and B). (8 used) Arrow (8 used) Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 6 422592 www.sauder.com/services...
  • Page 7 These holes must be here. These surfaces should be even. S u r f a c H I D D E N i t h The LEGS will overhang this edge. These surfaces should be even. www.sauder.com/services 422592 Page 7...
  • Page 8 1-15/16" FLAT HEAD SCREWS (113S). BLACK 9/16" LARGE HEAD SCREW (4 used for the METAL BRACKETS) 113S BLACK 1-15/16" FLAT HEAD SCREW (8 used in this step) These METAL BRACKETS should be located here and facing each other. Page 8 422592 www.sauder.com/services...
  • Page 9 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 422592 Page 9...
  • Page 10 Fasten the UPRIGHT (C) to the SHELF (F). Tighten two å HIDDEN CAMS. Minimum *U.S. Patent No. 5,499,886 å 190 degrees The groove is closer to this edge. Slide the SHELF MOLDING (N) onto the notched edge. Notched edge Notched edge Page 10 422592 www.sauder.com/services...
  • Page 11 Slide the SKIRT (K) onto the notched edge. S u r f a c H I D D E N i t h Notched edge Notched edge 113S BLACK 1-15/16" FLAT HEAD SCREW (2 used in this step) www.sauder.com/services 422592 Page 11...
  • Page 12 METAL BRACKETS and into the RIGHT END. Using your hammer, gently tap a CAM å COVER (12P) onto each HIDDEN CAM. BLACK 9/16" LARGE HEAD SCREW (2 used for the METAL BRACKETS) (18 used) To cover HIDDEN CAMS Page 12 422592 www.sauder.com/services...

  • Page 13: Upright

    To cover screws (10S) (6 used) SILVER 1-1/8" FLAT HEAD SCREW (6 used in this step) The top edges of the PANELS and PANEL MOLDINGS should be even. The groove is closer to this edge. www.sauder.com/services 422592 Page 13...
  • Page 14 Use six BLACK 9/16" LARGE HEAD SCREWS (1S). NOTE: Be sure to position the LIFT TABLE MECHANISMS on å the TOP exactly as shown. BLACK 9/16" LARGE HEAD SCREW (6 used in this step) The holes are closer to this edge. Page 14 422592 www.sauder.com/services...
  • Page 15 Fasten the SUPPORT BRACKETS (37G) to the LIFT å TABLE MECHANISMS (23M). Use four WASHERS (13M), NUTS (24M), and BLACK 3/4" MACHINE SCREWS (92S). NOTE: Use the adjustable wrench in this step. å BLACK 3/4" MACHINE SCREW (4 used in this step) www.sauder.com/services 422592 Page 15...
  • Page 16 LIFT TABLE MECHANISMS to fi nd the back holes. These four holes must be here. Do not insert a SCREW into this hole. Do not insert a SCREW into this hole. BLACK 9/16" LARGE HEAD SCREW (10 used in this step) Page 16 422592 www.sauder.com/services...
  • Page 17 SCREWS (85S) through the exact holes shown in the LIFT TABLE MECHANISMS (23M) and into the holes in the ENDS. NOTE: Do not overtighten the SCREWS (85S). å BLACK 3/4" PAN HEAD SCREW (2 used for the BUSHINGS) www.sauder.com/services 422592 Page 17...
  • Page 18 LIFT TABLE MECHANISMS (23M). Use four WASHERS (13M), Almost time to NUTS (24M), and BLACK 1-1/4" MACHINE SCREWS (93S). celebrate! With a nap. NOTE: Use the adjustable wrench in this step. å BLACK 1-1/4" MACHINE SCREW (4 used in this step) Page 18 422592 www.sauder.com/services...
  • Page 19 NOTE: Please read the back pages of the instruction booklet for important safety information. å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? 40 lbs. 25 lbs. 40 lbs. total www.sauder.com/services 422592 Page 19...
  • Page 20 QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 EXCENTRIQUE ESCAMOTABLE ....18 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 CHEVILLE D'EXCENTRIQUE ......10 en ce qui concerne cet MONTANT................1 VIS D'EXCENTRIQUE ..........8 élément, faire référence au numéro de lot et...
  • Page 21 Attention: Risque des dégâts ou blessures. Les Excentriques Escamotables doivent être serrés à bloc. Les Excentriques Escamotables que ne sont pas serrées à bloc peuvent desserrer et les pièces peuvent séparer. Pour serrer à bloc, faire tourner l'excentrique escamotable de 210 degrés. www.sauder.com/services 422592 Page 21...
  • Page 22 REMARQUE : Il est préférable de donner quelques tours de tournevis à chaque VIS avant de les serrer toutes à bloc. Il faudra relever le dos des MÉCANISMES DE LEVAGE DE TABLE pour trouver les trous arrière. Page 22 422592 www.sauder.com/services...
  • Page 23 EXTREMO DERECHO ..........1 EXCÉNTRICO ESCONDIDO ......18 et conserver le livret pour future référence. EXTREMO IZQUIERDO ..........1 PASADOR DE EXCÉNTRICO ......10 Pour contacter Sauder PARAL ...................1 BIELA DE EXCÉNTRICO ........8 en ce qui concerne cet PANEL SUPERIOR ............1 SOPORTE DE METAL ..........4 élément, faire référence...
  • Page 24 Precaución: Riesgo de daños o heridas. Los Excéntricos Escondidos deben apretarse completamente. Los Excéntricos Escondidos que no se aprieten completamente se afl ojarán y las partes pueden separarse. Para apretar completamente, atornille el excéntrico escondido 210 grados. Page 24 422592 www.sauder.com/services...
  • Page 25 EXTREMOS. NOTA: Debe apretar cada TORNILLO unas vueltas antes de apretar cualquier tornillo fi rmemente. Tendrá que levantar sobre la parte posterior de los MECANISMOS DE ELEVACIÓN DE LA MESA para encontrar los agujeros traseros. www.sauder.com/services 422592 Page 25...
  • Page 26 Además, el peso y la ubicación del tubo de imagen tienden a causar la inestabilidad de televisores y son propensos a inclinarse hacia adelante. Page 26 422592 www.sauder.com/services...
  • Page 27 à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
