sauder.com
Display Cabinet
Dakota Pass Collection | 418268
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
Your holder for all
things awesome.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-20
Français pg 21-24
Español pg 25-28
Lot # 365798
10/14/14
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Dakota Pass 418268

Summary of Contents for Sauder Dakota Pass 418268

  • Page 1 Dakota Pass Collection | 418268 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 50 pounds. Never use with a TV that weighs more.
  • Page 3 LEFT END (1) DOOR (2) TOP MOLDING (1) UPRIGHT (1) ADJUSTABLE SHELF (2) DOOR FRONT MOLDING (2) TOP (1) RIGHT FRONT LEG (1) ADJUSTABLE SHELF MOLDING (2) BOTTOM (1) LEFT FRONT LEG (1) BOTTOM MOLDING (1) www.sauder.com/services 418268 Page 3...
  • Page 4 BLACK 1/2" FLAT HEAD SCREW - 8 BLACK 1-7/8" FLAT HEAD SCREW - 3 12S BROWN 1" FLAT HEAD SCREW - 4 15S SILVER 5/8" MACHINE SCREW - 4 BLACK 2-1/4" FLAT HEAD SCREW - 6 SILVER 1-1/2" MACHINE SCREW - 2 Page 4 418268 www.sauder.com/services...
  • Page 5 fl oor. Scan this QR code or go to this address: http://qr.sauder.com/?ID=1420 To begin assembly, push a SAUDER TWIST-LOCK® to watch a video on how to assemble your unit. å FASTENER (10F) into the large holes in the ENDS (A and B).
  • Page 6 Push ten HIDDEN CAMS (1F) into the ENDS (A and B) and å TOP (D). (10 used) Arrow (10 used) Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 6 418268 www.sauder.com/services...
  • Page 7 TOP (D). Tighten four TWIST-LOCK® FASTENERS. Do not stand the unit upright without the BACK fastened. The unit may collapse. ® How to use the SAUDER TWIST-LOCK FASTENER 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
  • Page 8 fi nal location. BLACK 9/16" LARGE HEAD SCREW (3 used for the FOOT) BLACK 1-7/8" FLAT HEAD SCREW (3 used in this step) Use the BLACK 1-7/8" FLAT HEAD SCREWS into the UPRIGHT fi rst. Notched edge Page 8 418268 www.sauder.com/services...
  • Page 9 BOTTOM (E). Insert two DOOR STOPS (4I) into the holes in the å UPRIGHT (C). Notched edge *U.S. Patent No. 5,499,886 å Slide the BOTTOM MOLDING (O) onto the notched edge. Edge with HIDDEN CAMS www.sauder.com/services 418268 Page 9...
  • Page 10 Tap two MOLDING CONNECTORS (17F) into the notches å in the FRONT LEGS (I and J) and TOP MOLDING (L). Use your hammer to tap the MOLDING CONNECTOR (17F) into the notches in the MOLDINGS Flat end Flat end Page 10 418268 www.sauder.com/services...
  • Page 11 Fasten the FRONT LEGS (I and J) and TOP MOLDING (L) to å the ENDS (A and B) and TOP (D). Tighten ten HIDDEN CAMS. NOTE: Be careful in handling the FRONT LEGS/TOP å MOLDING assembly until it is fastened to your unit. www.sauder.com/services 418268 Page 11...
  • Page 12 Fasten the BACK LEGS (K) to the ENDS (A and B). Use six å Rome. This can be built BLACK 2-1/4" FLAT HEAD SCREWS (26S). in a day. BLACK 2-1/4" FLAT HEAD SCREW (6 used in this step) Flat edge Flat edge Page 12 418268 www.sauder.com/services...
  • Page 13 Fasten the BACK (F) to your unit using the NAILS (1N). å NOTE: Perforations have been provided for access å through the BACK. Carefully cut out the holes needed. NAIL (34 used in this step) These perforations should be closer to the bottom edge. www.sauder.com/services 418268 Page 13...
  • Page 14 Step 10 Fasten two HINGES (14H) to each DOOR (G). Use eight å BLACK 1/2" FLAT HEAD SCREWS (11S). BLACK 1/2” FLAT HEAD SCREW (8 used in this step) Page 14 418268 www.sauder.com/services...
  • Page 15 Repeat this step for the other DOOR (G). å See the next step for DOOR adjustments. å BROWN 1" FLAT HEAD SCREW SILVER 1-1/2" MACHINE SCREW (4 used in this step) (2 used for the KNOBS) www.sauder.com/services 418268 Page 15...
  • Page 16 To adjust the DOORS in or out (depth), loosen the mounting å screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Mounting screw (depth) Adjusting screw (horizontal) (vertical adjustment) Page 16 418268 www.sauder.com/services...
  • Page 17 Repeat this step for the other ADJUSTABLE SHELF (H). å *U.S. Patent No. 5,499,886 å Notched edge Slide the ADJUSTABLE SHELF MOLDING (N) onto the notched edge. Open end SILVER 5/8" MACHINE SCREW (4 used for the CARD HOLDERS) www.sauder.com/services 418268 Page 17...
  • Page 18 Push the RUBBER SLEEVES (2R) over the METAL å PINS (1R). Insert the METAL PINS into the hole locations of your choice in the ENDS (A and B) and UPRIGHT (C). Set the ADJUSTABLE SHELVES (H) onto the METAL PINS. (8 used) Page 18 418268 www.sauder.com/services...
  • Page 19 IMPORTANT: The ADJUSTABLE FOOT should not extend beyond the bottom edges of the FRONT LEGS (I and J). å Now, insert a HOLE PLUG (41P) into the hole in the BOTTOM (E). å With your No. 2 Phillips Screwdriver, turn the ADJUSTABLE FOOT downward until the FOOT touches the fl oor. Floor www.sauder.com/services 418268 Page 19...
  • Page 20 - The TV must weigh less than 50 lbs. - The base of the TV must be able to sit completely on this shelf. 50 lbs. 25 lbs. 25 lbs. 50 lbs. total (6 used) To cover HIDDEN CAMS Page 20 418268 www.sauder.com/services...
  • Page 21 QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 14H CHARNIÈRE ..............4 Pour contacter Sauder EXTRÉMITÉ GAUCHE ..........1 ARRÊT DE PORTE ............2 en ce qui concerne cet MONTANT................1 28K BOUTON ................2 élément, faire référence au numéro de lot et...
  • Page 22 ! attenante. • Cette unité Sauder est conçue pour les téléviseurs pesant moins REMARQUE : L'extrémité fi letée de la FIXATION doit rester de 22,6 kg. Ne jamais utiliser avec des téléviseurs plus lourds.
  • Page 23 VIS TÊTE PLATE 13 mm NOIRES (11S). Pour ajuster les PORTES vers l'intérieur où vers l'extérieur (profondeur), desserrer la vis de montage un tour et déplacer les PORTES vers l'intérieur ou vers l'extérieur. Serrer la vis de montage après avoir ajusté. www.sauder.com/services 418268 Page 23...
  • Page 24 REMARQUE : Prière de lire les informations importantes sur la sécurité fi gurant sur les pages arrière du manuel d’instructions. Ceci complète l'assemblage. Nettoyer à l’ a ide d’une encaustique pour meubles ou d’un chiff on humide. Essuyer. Page 24 418268 www.sauder.com/services...
  • Page 25 28K PERILLA ................2 et conserver le livret pour future référence. EXTREMO IZQUIERDO ..........1 ETIQUETA DE ADVERTENCIA ......1 Pour contacter Sauder PARAL ...................1 (Consulte el último paso para la ubicación e en ce qui concerne cet instalación apropiada) PANEL SUPERIOR ............1 élément, faire référence...
  • Page 26 - antes de comenzar el ensamblaje! la parte adjunta. • Esta unidad Sauder está diseñada para ser usada con NOTA: El extremo con cabilla del SUJETADOR debe quedarse televisores cuyo peso sea inferior a 22,6 Kg. Nunca la use para un completamente insertado en el agujero de la parte adjunta televisor de mayor peso.
  • Page 27 Para ajustar las PUERTAS hacia atrás o hacia adelante (profundidad), afl oje el tornillo de montaje una vuelta y mueva las PUERTAS hacia el interior o hacia el exterior según sea necesario. Apriete el tornillo de montaje después de hacer los ajustes. www.sauder.com/services 418268 Page 27...
  • Page 28 NOTA: Por favor, lea las páginas de atrás del folleto de instrucciones en cuanto a importante información de seguridad. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 28 418268 www.sauder.com/services...
  • Page 29 équipé. • Blessure physique. Le mobilier peut être très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 418268 Page 29...
  • Page 30 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 30 418268 www.sauder.com/services...
  • Page 31 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
