Desk
Harvey Park Collection | Model 420284
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-445-1527.
Share your journey!
The original desktop.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-27
Français pg 28-31
Español pg 32-36
Lot #: 507749
Date Purchased: __________________
08/07/17
Be sure to give us a ring before
making any returns. 1-800-445-1527

Advertisement

loading
Need help?

Need help?

Do you have a question about the Harvey Park 420284 and is the answer not in the manual?

Questions and answers

Related Manuals for Sauder Harvey Park 420284

Summary of Contents for Sauder Harvey Park 420284

  • Page 1 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. FUTURE REFERENCE. Prefer the phone? Call 1-800-445-1527. English pg 1-27 Français pg 28-31 Español pg 32-36...
  • Page 2 Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-27 Hammer Français 28-31 Not actual size Español 32-36 Safety Skip the power trip. 37-38 This time. Warranty Page 2 www.sauder.com 420284...
  • Page 3 BACK (1) PENCIL DRAWER BACK (1) FILE DRAWER BOTTOM (1) LARGE BOTTOM (1) RIGHT PENCIL DRAWER SIDE (1) FILE DRAWER FRONT (1) SMALL BOTTOM (1) PENCIL DRAWER BOTTOM (1) TOP BRACE (1) PENCIL DRAWER BRACE (1) 420284 www.sauder.com Page 3...
  • Page 4 BLACK 7/8" MACHINE SCREW - 3 BLACK 1-1/2" FLAT HEAD SCREW - 10 BLACK 1/2" MACHINE SCREW - 4 BLACK 9/16" WAFER HEAD SCREW - 16 BLACK 1/2" PAN HEAD SCREW - 12 BLACK 1/2" FLAT HEAD SCREW - 12 Page 4 www.sauder.com 420284...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Push twenty-seven LARGE HIDDEN CAMS (1) into the å...
  • Page 6 NOTE: Be sure to fl ip over the UPRIGHT (C) to turn two å ANGLE HEAD CAM SCREWS (3) into the opposite surface as shown in the lower left of this page. Angled head (27 used) Remember: Righty tighty. Lefty loosey. Page 6 www.sauder.com 420284...
  • Page 7 ENDS (A and B), UPRIGHT (C), TOP (D), and BACK (E). NOTE: Be sure to fl ip over the UPRIGHT (C) to insert two å more WOOD DOWELS into the opposite surface as shown in the lower left of this page. (24 used) 420284 www.sauder.com Page 7...
  • Page 8 NOTE: The EXTENSION SLIDES will be used later for the DRAWERS. å Pull up or down on the black lever and pull the SLIDE from the RAIL. Rounded corner BLACK 1/2" PAN HEAD SCREW (6 used in this step) Open end Open end Rounded corner Page 8 www.sauder.com 420284...
  • Page 9 Fasten the CABINET RAILS (CC and DD) to the UPRIGHT (C) and å LEFT END (B). Use six BLACK 1/2" FLAT HEAD SCREWS (17). Roller end BLACK 1/2" FLAT HEAD SCREW (6 used in this step) Rounded corner Roller end Rounded corner 420284 www.sauder.com Page 9...
  • Page 10 Step 6 Fasten the TOP BRACE (H) to the TOP (D). Use four å BLACK 1-1/16" WAFER HEAD SCREWS (19). BLACK 1-1/16" WAFER HEAD SCREW (4 used in this step) Page 10 www.sauder.com 420284...
  • Page 11 TOP BRACE (H) and into the LEFT END (B). BLACK 9/16" WAFER HEAD SCREW (2 used for the TOP BRACE) S u r f a c H I D D E N i t h 420284 www.sauder.com Page 11...
  • Page 12 Tighten two LARGE HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the LEFT END å insert into the holes in the LARGE BOTTOM. S u r f a c H I D D E N i t h Page 12 www.sauder.com 420284...
  • Page 13 LARGE BOTTOM. NOTE: Be sure the WOOD DOWELS in the TOP insert å into the holes in the UPRIGHT. i t h f a c S u r D E N H I D 420284 www.sauder.com Page 13...
  • Page 14 Tighten two LARGE HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS in the UPRIGHT å insert into the holes in the SMALL BOTTOM. S u r f a c H I D D E N i t h Page 14 www.sauder.com 420284...
  • Page 15 TOP BRACE (H) and into the RIGHT END (A). BLACK 9/16" WAFER HEAD SCREW (2 used for the TOP BRACE) o l e u t h i t h o f a c S u r 420284 www.sauder.com Page 15...
  • Page 16 BOTTOMS (F and G). Tighten thirteen LARGE HIDDEN It's going to be ok. CAMS with the ASSEMBLY TOOL (18). NOTE: Be sure the WOOD DOWELS in the BACK insert å into the holes in the ENDS, UPRIGHTS, and BOTTOMS. Page 16 www.sauder.com 420284...
  • Page 17 Fasten the STRETCHER (J) to the LEGS (I and K). Use four å BLACK 1/2" MACHINE SCREWS (15). NOTE: The STRETCHER will fi t over the brackets on the å LEGS. BLACK 1/2" MACHINE SCREW (4 used in the step) 420284 www.sauder.com Page 17...
  • Page 18 Fasten the LEFT LEG (I) to the BACK (E). Use two BLACK 2" å MACHINE SCREWS (10). NOTE: Do not completely tighten the SCREWS at this time. å BLACK 2" MACHINE SCREW (2 used in this step) Page 18 www.sauder.com 420284...
  • Page 19 BOTTOMS (F and G). Use twelve BLACK 9/16" WAFER HEAD SCREWS (14). Now, tighten the SCREWS into the BACK (E) completely å at this time. Tighten these BLACK 9/16" WAFER HEAD SCREW SCREWS completely. (12 used for the LEGS) 420284 www.sauder.com Page 19...
  • Page 20 DRAWER SIDES (L, N, R, and T) and PENCIL Straight head DRAWER BRACE (P). (10 used) Arrow Arrow Hole (10 used) The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 20 www.sauder.com 420284...
  • Page 21 Fasten the FILE DRAWER BACK (S) to the FILE DRAWER SIDES (R and T). Use four BLACK 1-1/2" FLAT HEAD SCREWS (12). å NOTE: Be sure the FILE DRAWER BOTTOM (U) inserts into the groove of the FILE DRAWER BACK (S). å 420284 www.sauder.com Page 21...
  • Page 22 SIDES (R and T). Use six BLACK 1/2" PAN HEAD SCREWS (16) through the 3rd, 6th, and 9th holes from the open end of the EXTENSION SLIDE. Open end BLACK 1/2" PAN HEAD SCREW (6 used in this step) Open end Page 22 www.sauder.com 420284...
  • Page 23 Fasten the PENCIL DRAWER BACK (M) to the PENCIL DRAWER SIDES (L and N) and PENCIL DRAWER BRACE (P). Use six å BLACK 1-1/2" FLAT HEAD SCREWS (12). NOTE: Be sure the FILE DRAWER BOTTOM (O) inserts into the groove of the PENCIL DRAWER BACK (M). å 420284 www.sauder.com Page 23...
  • Page 24 1. Push the FILE GLIDES (8) onto the FILE DRAWER å SIDES (R and T) as shown in the upper diagram. 2. Push the FILE HANGERS (9) onto the FILE GLIDES (8) å as shown in the lower diagram. Page 24 www.sauder.com 420284...
  • Page 25 DRAWER SIDES (L and N). Use six BLACK 1/2" FLAT If you're doing this to HEAD SCREWS (17). help a friend, don't leave without a bite. Roller end BLACK 1/2" FLAT HEAD SCREW (6 used in this step) Roller end 420284 www.sauder.com Page 25...
  • Page 26 Step 22 Fasten the KNOBS (6) to the DRAWER FRONTS (Q and V). å Use two BLACK 7/8" MACHINE SCREWS (13). BLACK 7/8" MACHINE SCREW (3 used in this step) Page 26 www.sauder.com 420284...
  • Page 27 This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. å And to celebrate, why not share your success story? Place the roller on the SLIDE behind the roller on the RAIL. 65 lbs. 30 lbs. 15 lbs. (27 used) To cover HIDDEN CAMS 420284 www.sauder.com Page 27...
  • Page 28 QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ DROITE ..........1 GRANDE EXCENTRIQUE Pour contacter Sauder ESCAMOTABLE ............27 EXTRÉMITÉ GAUCHE ..........1 en ce qui concerne cet PETITE EXCENTRIQUE ESCAMOTABLE 10 MONTANT................1 élément, faire référence DESSUS ................1...
  • Page 29 Fixer le PETIT DESSOUS (G) au MONTANT (C). Serrer deux ultérieurement pour les TIROIRS. GRANDES EXCENTRIQUES ESCAMOTABLES. REMARQUE : S’ a ssurer de bien insérer les CHEVILLES EN BOIS situées sur le MONTANT dans les trous du PETIT DESSOUS. 420284 www.sauder.com Page 29...
  • Page 30 Fixer les PIEDS GAUCHE et DROIT (I et K) aux DESSOUS (F et G). Utiliser douze VIS TÊTE MINCE 14 mm NOIRES (14). Maintenant, serrer à bloc les VIS dans l'ARRIÈRE (E) à ce stade de l'assemblage. Page 30 www.sauder.com 420284...
  • Page 31 ÉTAPE 21 pour meubles ou d’un chiff on humide. Essuyer. Fixer les COULISSES DE TIROIR (EE et FF) aux CÔTÉS DE TIROIR À CRAYONS (L et N). Utiliser six VIS TÊTE PLATE 13 mm NOIRES (17). 420284 www.sauder.com Page 31...
  • Page 32 SEPARADO) pour future référence. EXTREMO IZQUIERDO ............1 RIEL IZQUIERDO DE GABINETE ......1 Pour contacter Sauder PARAL ....................1 en ce qui concerne cet CORREDERA DERECHA DE CAJÓN ....1 PANEL SUPERIOR ..............1 élément, faire référence CORREDERA IZQUIERDA DE CAJÓN ..1...
  • Page 33 PANEL SUPERIOR en los agujeros del PARAL. alinean con los agujeros del EXTREMO. Atornille un TORNILLO dentro de estos agujeros. NOTA: Las CORREDERAS DE EXTENSIÓN se utilizarán más tarde para los CAJONES. 420284 www.sauder.com Page 33...
  • Page 34 GRANDES con la herramienta (18) provista. RIOSTRA DE CAJÓN PARA LÁPICES (P). NOTA: Asegúrese de que los PASADORES DE MADERA sujetados al DORSO se inserten dentro de los agujeros de los EXTREMOS, de los PARALES y de los FONDOS. Page 34 www.sauder.com 420284...
  • Page 35 LADOS DE CAJÓN DEL ARCHIVERO (R y T) como se muestra en el diagrama superior. 2. Empuje los SOPORTES DE ARCHIVERO (9) sobre los CORRIMIENTOS DE ARCHIVERO (8), tal como se muestra en el diagrama inferior. 420284 www.sauder.com Page 35...
  • Page 36 Separe una CUBIERTA DE EXCÉNTRICO de la TARJETA CON CUBIERTAS DE EXCÉNTRICO (7) y aplique las sobre cada EXCÉNTRICO ESCONDIDO visible. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 36 www.sauder.com 420284...
