Sauder Palladia 411830 Manual

Dresser
Hide thumbs

Advertisement

Quick Links

Download this manual
sauder.com
Dresser
Palladia Collection | Model 411830
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-25
Español pg 26-28
Lot # 387301
12/18/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Advertisement

loading

Related Manuals for Sauder Palladia 411830

Summary of Contents for Sauder Palladia 411830

  • Page 1 Palladia Collection | Model 411830 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 DRAWER LEFT SIDE (2) BASE (1) FRONT MOLDING (1) LARGE DRAWER FRONT (4) BOTTOM MOLDING (1) D171 LARGE DRAWER BACK (4) DRAWER FRONT MOLDING (2) D262 LARGE DRAWER RIGHT SIDE (4) PLINTH (2) D257 LARGE DRAWER LEFT SIDE (4) Page 2 411830 www.sauder.com/services...
  • Page 3 Now you know Part Identifi cation our ABCs. D245 D262 D171 D979 D979 D271 D257 www.sauder.com/services 411830 Page 3...
  • Page 4 (Refer to Step 17 for proper location and application) SAFETY DRYWALL NAIL - 60 SAFETY STRAP - 1 WASHER - 1 ANCHOR - 1 Locate this nylon SAFETY STRAP (60M) to be used later in assembly. Do not accidentally throw away. Page 4 411830 www.sauder.com/services...
  • Page 5 GOLD 5/16" FLAT HEAD SCREW - 48 BLACK 1-1/4" FLAT HEAD SCREW - 9 BROWN 1" FLAT HEAD SCREW - 6 30S BLACK 1-9/16" FLAT HEAD SCREW - 30 GOLD 1" MACHINE SCREW - 4 SILVER 1/2" MACHINE SCREW - 8 www.sauder.com/services 411830 Page 5...
  • Page 6 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push a SAUDER TWIST-LOCK® å FASTENER (10F) into the large holes in the ENDS (A2 and B2).
  • Page 7 Then, insert the metal end of a CAM DOWEL (2F) into each HIDDEN CAM. Do not tighten the HIDDEN CAMS in this step. Arrow (4 used) Arrow Insert the metal end of the CAM DOWEL into the HIDDEN CAM. www.sauder.com/services 411830 Page 7...
  • Page 8 Step 3 Tap two MOLDING CONNECTORS (17F) into the notches å in the MOLDINGS (M, N, and R). Use your hammer to tap the MOLDING CONNECTORS (17F) into the notches in the MOLDINGS. Flat end Flat end Page 8 411830 www.sauder.com/services...
  • Page 9 BLACK 1-1/4" FLAT HEAD SCREWS (7S). Remember: Righty tighty. NOTE: Do not overtighten the SCREWS into the TOP. å Lefty loosey. Finished surface BLACK 1-1/4" FLAT HEAD SCREW (9 used in this step) Long fl at edge www.sauder.com/services 411830 Page 9...
  • Page 10 #1 and #3. *patent pending glide system å Glide end Edge with TWIST-LOCK® FASTENER Glide end GOLD 5/16" FLAT HEAD SCREW Edge with (24 used in this step) TWIST-LOCK® FASTENER Finished edge Glide end Page 10 411830 www.sauder.com/services...
  • Page 11 å the TOP (D). Tighten two TWIST-LOCK® FASTENERS. Fasten the UPRIGHT (C2) to the TOP (D). Tighten two å How to use the SAUDER TWIST-LOCK ® FASTENER TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
  • Page 12 FASTENER S u r f a c i t h I S T - L O F A S T E N ® E R S BLACK 1-7/8" FLAT HEAD SCREW (2 used in this step) Page 12 411830 www.sauder.com/services...
  • Page 13 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees www.sauder.com/services 411830 Page 13...
  • Page 14 BASE. Fasten the BASE (H) to the BOTTOM (E). Use six BLACK å 9/16" LARGE HEAD SCREWS (1S) through the METAL BRACKETS and into the BOTTOM. BLACK 9/16" LARGE HEAD SCREW (12 used in this step) Page 14 411830 www.sauder.com/services...
  • Page 15 BLACK 9/16" LARGE HEAD SCREWS (1S). These holes must line up over the UPRIGHT (C2). Th BACK will overhang the BOTTOM slightly. Cut-out (used for mirror) BLACK 9/16" LARGE HEAD SCREW (4 used for the TIE PLATES) www.sauder.com/services 411830 Page 15...
  • Page 16 Push six HIDDEN CAMS (1F) into the DRAWER BRACES (M64). å (6 used) Do not tighten the HIDDEN CAMS in this step. Arrow Hole Arrow (6 used) The arrow in the HIDDEN CAM must point toward the hole in the edge of the board. Page 16 411830 www.sauder.com/services...
  • Page 17 DRAWER FRONTS (O2). Use six BROWN 1" FLAT Don't worry. It isn't HEAD SCREWS (12S). Rome. This can be built in a day. BROWN 1" FLAT HEAD SCREW (6 used in this step) Rounded edge Finished surface Rounded edge Finished surface www.sauder.com/services 411830 Page 17...
  • Page 18 Use fi ve BLACK 1-9/16" FLAT HEAD SCREWS (30S). Fasten the DRAWER BRACE (M64) to the DRAWER å FRONT (O2). Tighten one HIDDEN CAM. Repeat this step for the other drawers. Use the LARGE å DRAWER FRONT BRACKETS (9G) for the large drawers. Page 18 411830 www.sauder.com/services...
  • Page 19 Glide end GOLD 1" MACHINE SCREW (4 used for the DRAWER FRONTS) D271 Glide end D245 SILVER 1/2" MACHINE SCREW (8 used for the LARGE DRAWER FRONTS) GOLD 5/16" FLAT HEAD SCREW (24 used in this step) www.sauder.com/services 411830 Page 19...
  • Page 20 NOTE: Before moving your unit to a diff erent location, unscrew the SAFETY DRYWALL ANCHOR (61M) from your wall. å The nylon sheath will remain behind your wall. BLACK 9/16" LARGE HEAD SCREW (1 used in this step) Page 20 411830 www.sauder.com/services...
  • Page 21 To make adjustments to the drawers, loosen the SCREWS in the å DRAWER FRONT BRACKETS, make needed adjustments, and tighten the SCREWS. Place the glide on the SLIDE behind the glide on the RAIL. www.sauder.com/services 411830 Page 21...
  • Page 22 -If equipped with a drawer interlock system, do not defeat or remove it. Use of tip-over restraints may only reduce, but not eliminate, the risk of tip-over. 40 lbs. 20 lbs. 20 lbs. 35 lbs. each Page 22 411830 www.sauder.com/services...
  • Page 23 élément et conserver le livret EXTRÉMITÉ DROITE ..........1 PIED ..................1 pour future référence. EXTRÉMITÉ GAUCHE ..........1 EXCENTRIQUE ESCAMOTABLE ....10 Pour contacter Sauder MONTANT................1 CHEVILLE D'EXCENTRIQUE ......4 en ce qui concerne cet élément, faire référence DESSUS ................1 VIS D'EXCENTRIQUE ..........6 au numéro de lot et...
  • Page 24 TÊTE PLATE 48 mm (2S). Pour commencer l'assemblage, enfoncer une FIXATION TWIST-LOCK® SAUDER (10F) dans les gros trous des EXTRÉMITÉS (A2 et B2). Répéter Fixer l'EXTRÉMITÉ DROITE (A2) au DESSOUS (E) et à la MOULURE cette étape pour le MONTANT (C2) et le DESSOUS (E).
  • Page 25 VIS DORÉES À MÉTAUX 25 mm (50S). meubles ou d’un chiff on humide. Essuyer. Répéter cette étape pour les autres tiroirs. Utiliser les VIS ARGENTÉES À MÉTAUX 13 mm (38S) pour les POIGNÉES des grands tiroirs. www.sauder.com/services 411830 Page 25...
  • Page 26 EXTREMO IZQUIERDO ..........1 10F SUJETADOR TWIST-LOCK® ......12 pour future référence. 17F CONECTOR DE MOLDURA ........2 PARAL ...................1 Pour contacter Sauder PLACA DE CONEXIÓN ...........2 PANEL SUPERIOR ............1 en ce qui concerne cet SOPORTE DE METAL ..........8 FONDO .................1 élément, faire référence...
  • Page 27 DE CABEZA PERDIDA de 48 mm (2S). Para comenzar el ensamblaje, empuje un SUJETADOR TWIST-LOCK® SAUDER (10F) dentro de los agujeros grandes de los EXTREMOS (A2 y B2). Fije el EXTREMO DERECHO (A2) al FONDO (E) y a la MOLDURA Repita este paso para el PARAL (C2) y el FONDO (E).
  • Page 28 TORNILLOS DORADOS PARA METAL de 25 mm (50S). preferido o un paño húmedo. Seque con un paño. Repita este paso para los otros cajones. Utilice los TORNILLOS PLATEADOS PARA METAL de 13 mm (38S) para los TIRADORES de los cajones grandes. Page 28 411830 www.sauder.com/services...
  • Page 29 équipé. • Blessure physique. Le mobilier peut • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. www.sauder.com/services 411830 Page 29...
  • Page 30 • No empuje la unidad, especialmente • Lesión física. El mobiliario puede ser sobre un piso alfombrado. muy pesado. Page 30 411830 www.sauder.com/services...
  • Page 31 GARANTIE LIMITÉE DE 5 ANS 1. Sauder Woodworking Co. (Sauder®) off re une couverture de garantie limitée à l’ a cheteur 4. La présente garantie ne s’ a pplique qu’ a ux défauts garantis qui se produisent pour initial du présent produit pendant une période de cinq ans à...
  • Page 32 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
