Sauder HomePlus 411572 Assembly Instructions Manual

Sauder HomePlus 411572 Assembly Instructions Manual

Storage cabinet
Hide thumbs Also See for HomePlus 411572:

Advertisement

Quick Links

Download this manual
411572
Storage Cabinet
HomePlus Collection
PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English .................Page 1-20
Français ...........Pages 21-24
Made in the USA
Espanol ......... Páginas 25-28
Archbold, OH
Lot #: 337920
Date Purchased: ____________________
04 / 11 / 11

Advertisement

loading
Need help?

Need help?

Do you have a question about the HomePlus 411572 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sauder HomePlus 411572

Summary of Contents for Sauder HomePlus 411572

  • Page 1 PLEASE READ AND KEEP FOR FUTURE REFERENCE. BEFORE RETURNING English ....Page 1-20 YOUR UNIT TO THE STORE Français ...Pages 21-24 1-800-523-3987 Made in the USA Espanol ..Páginas 25-28 Archbold, OH www.sauder.com Lot #: 337920 04 / 11 / 11 Date Purchased: ____________________...
  • Page 2 No. 2 Phillips Screwdriver Hardware Identifi cation .....4 Tip Shown Actual Size Assembly Steps ....5-20 Safety ......... 29-30 Hammer Warranty ........31 Français ......21-24 Straight Edge Screwdriver Espanol ....... 25-28 Electric drill with 1/4" bit Page 2 www.sauder.com/services 411572...

  • Page 3: Part Identification

    ADJUSTABLE DOOR SMALL END DOOR UPRIGHT SHELF SMALL ADJUSTABLE LARGE END LARGE SHELF SHELF DOOR END SMALL SHELF FRONT SKIRT UPRIGHT BACK SIDE SKIRT LARGE DOOR TOP MOLDING BOTTOM SMALL DOOR LARGE ADJUSTABLE DOOR SHELF SHELF 411572 www.sauder.com/services Page 3...

  • Page 4: Hardware Identification

    BLACK 9/16" WAFER HEAD SCREW - 4 BLACK 1/2” FLAT HEAD SCREW - 8 BLACK 9/16” LARGE HEAD SCREW - 19 NAIL - 72 Screws are shown actual size. You may receive extra hardware with your unit. Page 4 www.sauder.com/services 411572...
  • Page 5 (27 used) Assemble your unit on a carpeted fl oor or on the empty carton to avoid scratching your unit or the fl oor. To begin assembly, push a SAUDER TWIST-LOCK ® FASTENER (V) into the large holes in the ENDS (A and B), DOOR END (C),TOP (E), DOOR SHELVES (G), LARGE SHELF (I), DOOR UPRIGHT (H), and SMALL SHELF (J).
  • Page 6 LARGE DOOR ON LEFT Finished edge Dowel end ® How to use the SAUDER TWIST-LOCK FASTENER 1. Insert the dowel end of the FASTENER into the hole of the adjoining part. NOTE: The dowel end of the FASTENER must remain fully inserted in the hole of the adjoining part while locking the FASTENER.
  • Page 7 There are four pre-drilled holes in the top surface of the TOP (E). Finish drilling out two holes with your electric drill and 1/4" drill bit. Fasten the UPRIGHT (D) to the TOP (E). Use two BLACK 1-7/8" FLAT HEAD SCREWS (MM). Fasten the UPRIGHT (D) to the LARGE SHELF (I). Tighten two TWIST-LOCK ® FASTENERS. 411572 www.sauder.com/services Page 7...
  • Page 8 Angled edge LARGE DOOR ON RIGHT Finished edge ® Fasten the TOP MOLDING (S) to the TOP (E). Tighten three TWIST-LOCK FASTENERS. Fasten the SMALL SHELF (J) to the UPRIGHT (D). Tighten two TWIST-LOCK ® FASTENERS. Page 8 www.sauder.com/services 411572...
  • Page 9 LARGE DOOR ON LEFT Edge with TWIST-LOCK® FASTENERS LARGE DOOR ON RIGHT Edge with TWIST-LOCK® FASTENERS Fasten the SMALL END (A) to the TOP (E) and SMALL SHELF (J). Tighten four TWIST-LOCK ® FASTENERS. 411572 www.sauder.com/services Page 9...
  • Page 10 Finish drilling out the pre-drilled hole with your electric drill and 1/4" drill bit to fasten the BOTTOM(F) to the LARGE END (B) and UPRIGHT (D). Fasten the BOTTOM (F) to the ENDS (A and B) and UPRIGHT (D). Use six BLACK 1-7/8" FLAT HEAD SCREWS (MM). Page 10 www.sauder.com/services 411572...
  • Page 11 Fasten the SKIRTS (Q and R) to the BOTTOM (F). Use four BLACK 9/16" WAFER HEAD SCREWS (QQ) through the FEET and into the BOTTOM as shown in the lower diagram. NOTE: To raise a corner of the unit, turn the ADJUSTABLE GLIDE counter-clockwise. To lower a corner, turn the ADJUSTABLE GLIDE clockwise. 411572 www.sauder.com/services Page 11...
  • Page 12 Fasten the FOOT BASES (KK) to the BOTTOM (E). Use eight SILVER 5/8" FLAT HEAD SCREWS (PP). Then, push the FEET (JJ) into the FOOT BASES (KK). Fasten the METAL BRACKET (W) to the BOTTOM (F) and FRONT SKIRT (Q). Use two BLACK 9/16" LARGE HEAD SCREW (RR). Page 12 www.sauder.com/services 411572...
  • Page 13 Fasten the DOOR UPRIGHT (H) to the DOOR SHELVES (G). Tighten three TWIST-LOCK FASTENERS. ® NOTE: Be sure the PINS insert into the edges of the DOOR SHELVES and DOOR UPRIGHT before you tighten the TWIST-LOCK ® FASTENERS. 411572 www.sauder.com/services Page 13...
  • Page 14 Fasten the DOOR UPRIGHT (H) and DOOR END (C) to the SMALL DOOR (M). Tighten six TWIST-LOCK FASTENERS. ® Fasten the HINGES (LL) to the DOOR END (C). Use eight BLACK 9/16" LARGE HEAD SCREWS (RR). Page 14 www.sauder.com/services 411572...
  • Page 15 SMALL DOOR assembly for support while you fasten the HINGES (LL) to the SMALL END. Fasten the HINGES (LL) to the SMALL END (A). Use eight BLACK 9/16" LARGE HEAD SCREWS (RR). Push the DOOR STOPS (Z) into the holes in the top and bottom corners of the UPRIGHT (C). 411572 www.sauder.com/services Page 15...
  • Page 16 Fasten three HINGES (EE) to the LARGE DOOR (L). Use six BLACK 1/2" FLAT HEAD SCREWS (SS). NOTE: You may need to loosen the mounting and adjusting screws to slide it part way out of the slot. Retighten the screw before you mount the HINGE to the LARGE END. Page 16 www.sauder.com/services 411572...
  • Page 17 Fasten the LARGE DOOR (L) to the LARGE END (B). Use the screws in the HINGES. See the next step for adjustments. Fasten a PULL (X) to the DOOR (L). Use two SILVER 7/8" MACHINE SCREWS (NN). Place your unit into its final position against a wall. 411572 www.sauder.com/services Page 17...
  • Page 18 Tighten the screws after making adjustments. To adjust the DOORS in or out (depth), loosen the mounting screw one turn and move the DOORS in or out, as needed. Tighten the mounting screw after making adjustments. Page 18 www.sauder.com/services 411572...
  • Page 19 Push the RUBBER SLEEVES (BB) over sixteen METAL PINS (AA). Insert the METAL PINS into the hole locations of your choice in the LARGE END (B) and UPRIGHT (D). Set the ADJUSTABLE SHELVES (N and P) onto the METAL PINS. 411572 www.sauder.com/services Page 19...
  • Page 20 Push the HOLE PLUGS (FF and GG) into the visible holes, not including the adjustable shelf pin holes in the SMALL DOOR assembly and UPRIGHT (D). NOTE: Please read the back pages of the instruction booklet for important safety information. This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry. Page 20 www.sauder.com/services 411572...

  • Page 21: Liste De Pièces

    PORTE ..........3 NN VIS ARGENTÉE À MÉTAUX pour future référence. PETITE TABLETTE RÉGLABLE ..2 22 mm ..........2 Pour contacter Sauder PLINTHE AVANT ......1 OO VIS ARGENTÉE À en ce qui concerne cet MÉTAUX 19 mm ......2 élément, faire référence PLINTHE LATÉRALE .......2...
  • Page 22 Fixer la PETITE EXTRÉMITÉ (A) au DESSUS (E) et à la PETTE TABLETTE (J). Serrer quatre FIXATIONS TWIST-LOCK®. Utilisation de la FIXATION TWIST-LOCK® SAUDER 1. Insérer l'extrémité fi letée de la FIXATION dans le trou de la pièce attenante. ÉTAPE 6 Finir de percer le trou pré...
  • Page 23 REMARQUE : Il est peut-être nécessaire de desserrer TWIST-LOCK®. les vis de fi xation et vis de réglage pour les glisser partiellement hors de la fente. Resserrer la vis avant de monter la CHARNIÈRE à la GRANDE EXTRÉMITÉ. 411572 www.sauder.com/services Page 23...
  • Page 24 fi gurent sur la couverture arrière du manuel un tour et déplacer les PORTES vers l'intérieur ou vers d'instructions. l'extérieur. Serrer la vis de montage après avoir ajusté. Ceci complète l'assemblage. Pour nettoyer, utiliser l'encaustique pour meubles préférée ou un chiffon humide. Essuyer. Page 24 www.sauder.com/services 411572...

  • Page 25: Lista De Partes

    FALDÓN DELANTERO ......1 de 19 mm ..........2 en contacto con FALDÓN LATERAL ........ 2 TORNILLO PLATEADO DE CABEZA ..Sauder en cuanto a MOLDURA DE PANEL PERDIDA de 16 mm ......8 esta unidad, refi érase SUPERIOR ..........1 al número de lote y...
  • Page 26 Fije el EXTREMO PEQUEÑO (A) al PANEL SUPERIOR (E) y al ESTANTE PEQUEÑO (J). Apriete cuatro SUJETADORES TWIST-LOCK®. Cómo utilizar el SUJETADOR TWIST-LOCK® SAUDER 1. Inserte el extremo con cabilla del SUJETADOR dentro del agujero de la parte adjunta. PASO 6...
  • Page 27 PARAL DE LA PUERTA antes de apretar los SUJETADORES TWIST-LOCK®. NOTA: Puede ser necesario afl ojar el tornillo de montaje y de ajuste para deslizar parcialmente fuera de la ranura. Vuelva a apretar los tornillos antes de montar la BISAGRA al EXTREMO GRANDE. 411572 www.sauder.com/services Page 27...
  • Page 28 PUERTAS hacia el interior o hacia el exterior seguridad. según sea necesario. Apriete el tornillo de montaje después de hacer los ajustes. Esto completa el ensamblaje. Limpie con su pulimento para muebles preferido o un paño húmedo. Seque con un paño. Page 28 www.sauder.com/services 411572...
  • Page 29 • Ne pas pousser le mobilier, surtout sur la être très lourd. moquette. Se faire aider par une autre personne pour soulever la commode et la mettre en place. • Cette unité doit être placée contre un mur. 411572 www.sauder.com/services Page 29...
  • Page 30 • Lesión física. El mobiliario puede sobre un piso alfombrado. Pide a otra ser muy pesado. persona su ayuda en levantar la cómoda y colocarla en lugar. • Esta unidad debe ser colocada contra una pared. Page 30 www.sauder.com/services 411572...

  • Page 31: Year Limited Warranty

    4. La présente garantie ne s’applique qu’aux défauts garantis qui se produisent des composantes de mobilier Sauder. Le mot « défaut », tel qu’il est utilisé sous pour la première fois et qui sont signalés à Sauder dans les limites de ouverture les termes de la présente garantie, comprend les imperfections des pièces qui...
  • Page 32 Archbold, Ohio, where it all began. Certifi cate of Conformity The Sauder name on the box ensures that 1. This certifi cate applies to the Sauder Woodworking Product indentifi ed by this Instruction Book. the item you have purchased is made with 2.
