- Page 1 Store behind closed doors. Wardrobe/Storage Cabinet NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-21 Français pg 22-24 Español pg 25-28 Share your journey!
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 6-21 Hammer Not actual size Français 22-24 Español 25-28 Skip the power trip. Safety 29-30 This time. Warranty Part Identifi...
- Page 3 Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. D175 D983 Page 3...
- Page 4 Hardware Identifi cation 40CA CABINET RIGHT - 1 40CB CABINET LEFT - 1 40CC DRAWER RIGHT - 1 40CD DRAWER LEFT - 1 18E ADJUSTABLE ROD - 1 FOOT - 2 ROD HANGER SIDE FOOT - 2 GLIDE - 4 TWIST-LOCK®...
- Page 5 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. BLACK 9/16" LARGE HEAD SCREW - 7 BLACK 1-7/8" FLAT HEAD SCREW - 5 BLACK 1/2" FLAT HEAD SCREW - 12 GOLD 5/16" FLAT HEAD SCREW - 8 30S BLACK 1-9/16"...
- Page 6 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push a TWIST-LOCK® å FASTENER (10F) into the large holes in the TOP (C) and SHELF (F).
- Page 7 Step Step 2 Fasten the CABINET RIGHT (40CA) and CABINET å LEFT (40CB) to the ENDS (A and B). Use four GOLD Remember: 5/16" FLAT HEAD SCREWS (3S). Righty tighty. Lefty loosey. Fasten the ROD HANGERS (7A) to the ENDS (A and B). å...
- Page 8 Step Step 3 Fasten the LEFT END (B) to the TOP (C) and SHELF (F). å ® How to use this TWIST-LOCK FASTENER Tighten four TWIST-LOCK® FASTENERS. 1. Insert the dowel end of the FASTENER into the hole of the adjoining part. NOTE: The dowel end of the FASTENER must remain fully inserted in the hole of the adjoining part while locking the FASTENER.
- Page 9 Step Step 4 Fasten the RIGHT END (A) to the TOP (C) and SHELF (F). å Tighten four TWIST-LOCK® FASTENERS. Fasten the TOP MOLDING (P) to the TOP (C). Tighten two å TWIST-LOCK® FASTENERS. Wide edge Long fi nished edge Page 9...
- Page 10 Step Step 5 Push the DOOR STOP (4I) into the hole in the TOP (C). å Fasten the BOTTOM (D2) to the ENDS (A and B). Use four å BLACK 1-7/8" FLAT HEAD SCREWS (2S). Rounded edge r f a w i t l e s BLACK 1-7/8"...
- Page 11 Step Step 6 Slide the FEET (31E and 32E) into the notches in å the SKIRTS (J and K). Use a hammer to drive a PROPEL NUT (14M) into å (4 used) the holes in the FEET (31E and 32E). Now, turn an ADJUSTABLE GLIDE (18E) into each PROPEL NUT as shown in the upper diagram.
- Page 12 Step Step 7 Carefully turn your unit over onto its front edges. Unfold the å Caution BACK (E) and lay it over your unit. Do not stand the unit upright without the Make equal margins along all four edges of the BACK (E). å...
- Page 13 Step Step 8 Fasten three HINGES (13H) to each DOOR (H). Use twelve å BLACK 1/2" FLAT HEAD SCREWS (11S). BLACK 1/2" FLAT HEAD SCREW (12 used in this step) Page 13...
- Page 14 Step Step 9 Carefully stand your unit upright. å Pro Tip: Lift with your Before fastening the DOOR to your unit, be sure the å legs. And, you know, mounting screw is against the stops as shown in the right your arms.
- Page 15 Step Step 10 Refer to the enlarged diagram to identify the parts on the HINGES. å The DOORS may need some adjustments. Follow the text below to make å needed adjustments. DOOR ADJUSTMENTS: å To adjust the DOORS from side to side (horizontal), loosen the mounting å...
- Page 16 Step Step 11 Turn a CAM SCREW (8F) into the DRAWER FRONT (L). å Push a HIDDEN CAM (1F) into the DRAWER BRACE (M65). å Do not tighten the HIDDEN CAM in this step. Arrow Arrow Hole The arrow in the HIDDEN CAM must point toward the hole in the edge of the board.
- Page 17 Step Step 12 VIEW THE T-SLOT BOX VIDEO Pull the DRAWER FRONT BRACKETS (9G) apart and slide them into å the grooves in the DRAWER SIDES (D50 and D51). You may need to gently tap them in with a hammer. NOTE: The DRAWER FRONT BRACKETS are marked "RH"...
- Page 18 Step Step 13 VIEW THE T-SLOT BOX VIDEO Fasten the DRAWER BRACE (M65) to the DRAWER FRONT (L). Tighten one å HIDDEN CAM. Fasten the DRAWER BACK (D175) to the DRAWER SIDES (D50 and D51) and å DRAWER BRACE (M65). Use fi ve BLACK 1-9/16" FLAT HEAD SCREWS (30S). Surface with HIDDEN CAM Start each screw a few turns before...
- Page 19 Step Step 14 Fasten the DRAWER RIGHT (40CC) and DRAWER LEFT (40CD) å to the DRAWER SIDES (D50 and D51). Use four GOLD 5/16" Almost time to FLAT HEAD SCREWS (3S) through holes #2 and #4. celebrate! With a nap. Fasten the PULL (35K) to the DRAWER FRONT (L).
- Page 20 Step Step 15 Place your unit into its fi nal position against a wall. å Push the RUBBER SLEEVES (2R) over the METAL PINS (1R). Insert å the METAL PINS into the hole locations of your choice in the ENDS (A and B).
- Page 21 Step Step 16 Fasten the SAFETY BRACKET (1G) for added stability. Use a BLACK 9/16" LARGE HEAD SCREW (1S) into the top of the å unit and a BLACK 1-7/8" FLAT HEAD SCREW (2S) into a stud in your wall. Apply the WARNING LABEL (5L) to the left DOOR (H).
- Page 22 Armoire/Meuble de Rangement Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble arrive dans d’excellentes conditions. Nos représentants du service Chaque étape en français correspond à...
- Page 23 ÉTAPE 1 ÉTAPE 6 Ne pas serrer les FIXATIONS TWIST-LOCK® à ce stade de l'assemblage. Faire glisser les PIEDS (31E et 32E) dans les crans des PLINTHES (J et K). À l'aide d'un marteau, enfoncer un TOURILLON (14M) à travers les trous dans Assembler l'élément sur un sol à...
- Page 24 ÉTAPE 10 ÉTAPE 14 Fixer le TIROIR DROIT (40CC) et le TIROIR GAUCHE (40CD) aux CÔTÉS DE Consulter le schéma agrandi pour identifi er les pièces des CHARNIÈRES. TIROIR (M). Utiliser quatre VIS TÊTE PLATE 8 mm DORÉES (3S) à travers les Il faut peut-être ajuster les PORTES.
- Page 25 Ropero/Armario de Almacenamiento Use estas instrucciones de ensamblaje en español junto con las ESTAMOS AQUI PARA AYUDAR! fi guras paso-a-paso provistas en el folleto inglés. Cada paso Tratamos de asegurar que su mueble llega en condición excelente. en español corresponde al mismo paso en inglés. Se destacan Nuestros representantes de Servicio al Cliente son amables y las fi...
- Page 26 PASO 1 PASO 4 NOTA: No apriete los SUJETADORES TWIST-LOCK® por ahora. Fije el EXTREMO DERECHO (A) al PANEL SUPERIOR (C) y al ESTANTE (F). Apriete cuatro SUJETADORES TWIST-LOCK®. Ensamble la unidad sobre un piso alfombrado o sobre el cartón vacío para evitar rayar la unidad o el piso.
- Page 27 PASO 7 PASO 10 Precaución: No coloque la unidad en posición vertical hasta que se Consulte el diagrama ampliado para identifi car las piezas de fi je el DORSO. La unidad podría caerse. las BISAGRAS. Cuidadosamente voltee la unidad para que repose sobre los bordes Las PUERTAS pueden requerir de ajustes.
- Page 28 PASO 12 PASO 15 Separe las MÉNSULAS DE CARA DE CAJÓN (9G) y deslícelas Coloque su unidad en su posición fi nal contra una pared. en las ranuras de los LADOS DE CAJÓN (D50 y D51). Puede ser Empuje los MANGUITOS DE GOMA (2R) sobre las ESPIGAS necesario que las clave ligeramente adentro con un martillo.
- Page 29 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded dresser drawers and •...
- Page 30 ADVERTENCIA Por favor use el mobiliario correcta y seguramente. El mal uso puede causar riesgos de seguridad o daño a las unidades o artículos domésticos. Cuidadosamente lea la tabla a continuación. Esté alerto de: Puede ocurrir: Evitar el problema: • Cajones y estantes de cómoda •...
