- Page 1 Store behind closed doors. Base Cabinet NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. English pg 1-16 Français pg 17-18 Español pg 19-20 Share your journey! Lot # Purchased: __________________...
- Page 2 Table of Contents Assembly Tools Required Part Identifi cation No. 2 Phillips Screwdriver Tip Shown Actual Size Hardware Identifi cation Assembly Steps 5-16 Hammer Not actual size Français 17-18 Español 19-20 Skip the power trip. Safety 21-22 This time. Warranty Page 2...
- Page 3 Now you know Part Identifi cation our ABCs. å While not all parts are labeled, some of the parts will have a label or an inked letter on the edge to help distinguish similar parts from each other. Use this part identifi cation to help identify similar parts. RIGHT END (1) LEFT END (1) TOP (1)
- Page 4 Hardware Identifi cation å Screws are shown actual size. You may receive extra hardware with your unit. TWIST-LOCK® FRONT FOOT - 2 REAR FOOT - 2 HINGE - 4 FASTENER - 7 SAFETY LARGE RUBBER PULL - 2 BRACKET - 1 PLATE - 1 SLEEVE - 1 ADJUSTABLE...
- Page 5 Step 1 Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. To begin assembly, push four TWIST-LOCK® FASTENERS å (L) into the large holes in the ENDS (A and B). Repeat this step for the TOP (C).
- Page 6 Step 2 Fasten the ENDS (A and B) to the TOP (C). Tighten four å Caution TWIST-LOCK® FASTENERS. Do not stand the unit upright without the BACK fastened. The unit may collapse. How to use the TWIST-LOCK ® FASTENER 1. Insert the dowel end of the FASTENER into the hole of the adjoining part.
- Page 7 Step 3 Fasten the BOTTOM (D) to the ENDS (A and B). Use four å BLACK 1-7/8" FLAT HEAD SCREWS (W). Remember: Righty tighty. Lefty loosey. Rounded edge U n fi n i s h s u r f a c BLACK 1-7/8"...
- Page 8 Step 4 Fasten the TOP MOLDING (J) to the TOP (C). Tighten å three TWIST-LOCK® FASTENERS. Slip a LARGE RUBBER SLEEVE (P) over the TIE å PLATE (O). The RUBBER SLEEVE will be a tight fi t. Then, fasten the TIE PLATE (O) to the TOP MOLDING (J). å...
- Page 9 Step 5 Slide the FEET (I and K) into the notches in the SKIRTS (H å and R). Use a hammer to drive a PROPEL NUT (T) into the holes å in the FEET (I and K). Now, turn an ADJUSTABLE GLIDE (S) into each PROPEL NUT.
- Page 10 Step 6 Fasten the SKIRTS (H and R) to the BOTTOM (D). Use å four BLACK 9/16" WAFER HEAD SCREWS (AA) through Don't worry. It isn't the FEET and into the BOTTOM. Rome. This can be built in a day. NOTE: To raise a corner of the unit, turn the å...
- Page 11 Step 7 Carefully turn your unit over onto its front edges. Unfold å Caution the BACK (E) and lay it over your unit. Do not stand the unit upright without the BACK fastened. The unit may collapse. Make equal margins along all four edges of the BACK (E). å...
- Page 12 Step 8 Fasten two HINGES (M) to each DOOR (F). Use eight å BLACK 1/2" FLAT HEAD SCREWS (BB). BLACK 1/2" FLAT HEAD SCREW (8 used for the HINGES) Page 12...
- Page 13 Step 9 Carefully stand your unit upright. å Pro Tip: Lift with your Before fastening the DOOR to your unit, be sure the å legs. And, you know, mounting screw is against the stops as shown in the right your arms. diagram.
- Page 14 Step 10 Refer to the enlarged diagram to identify the parts on the HINGES. å The DOORS may need some adjustments. Follow the text below to make needed adjustments. å DOOR ADJUSTMENTS: å To adjust the DOORS from side to side (horizontal), loosen the mounting screw several turns, then turn the adjusting screw in or out.
- Page 15 Step 11 IMPORTANT: Units that are stacked on top of another å STACKING OPTION: unit must be attached to each other as indicated in this (If not stacking units, go to step 12) step. These units must be positioned against a wall and the upper unit must be attached to a wall.
- Page 16 Step 12 Place your unit into its fi nal position against a wall. å Fasten the SAFETY BRACKET (N) for added stability. Use a BLACK 9/16” LARGE HEAD SCREW (Z) into the top of the å unit and a BLACK 1-7/8” FLAT HEAD SCREW (W) into a stud in your wall. Push the RUBBER SLEEVES (V) over the METAL PINS (U).
- Page 17 Meuble de base Utilisez les instructions d’ a ssemblage en français avec les NOUS SOMMES LA POUR VOUS AIDER! schémas étape par étape du manuel d’instruction en anglais. Nous faisons de notre mieux pour nous assurer que votre meuble arrive dans d’excellentes conditions. Nos représentants du service Chaque étape en français correspond à...
- Page 18 ÉTAPE 1 ÉTAPE 8 Assembler l'élément sur un sol à moquette ou sur le carton vide pour éviter Fixer deux CHARNIÈRES (M) à chaque PORTE (F). Utiliser huit VIS NOIRES TÊTE d'endommager l'élément ou le sol. PLATE 13 mm (BB). Pour commencer l'assemblage, enfoncer quatre FIXATIONS TWIST-LOCK®...
- Page 19 Gabinete de base Use estas instrucciones de ensamblaje en español junto con las ESTAMOS AQUI PARA AYUDAR! fi guras paso-a-paso provistas en el folleto inglés. Cada paso Tratamos de asegurar que su mueble llega en condición excelente. en español corresponde al mismo paso en inglés. Se destacan Nuestros representantes de Servicio al Cliente son amables y las fi...
- Page 20 PASO 1 PASO 8 Ensamble la unidad sobre un piso alfombrado o sobre el cartón Fije dos BISAGRAS (M) a cada PUERTA (F). Utilice ocho TORNILLOS NEGROS DE CABEZA vacío para evitar rayar la unidad o el piso. PERDIDA de 13 mm (BB). Para comenzar el ensamblaje, empuje cuatro SUJETADORES TWIST-LOCK®...
- Page 21 WARNING Please use your furniture correctly and safely. Improper use can cause safety hazards, or damage to your furniture or household items. Carefully read the following chart. Look out for: What can happen: How to avoid the problem: • Overloaded shelves. •...
- Page 22 ADVERTENCIA Por favor use el mobiliario correcta y seguramente. El mal uso puede causar riesgos de seguridad o daño a las unidades o artículos domésticos. Cuidadosamente lea la tabla a continuación. Esté alerto de: Puede ocurrir: Evitar el problema: • Cajones y estantes sobrecargados. •...
- Page 23 So, how did it go? Set a world record for speed? Feeling good about yourself? Nice. Get social with it on any of these quality share sites. And don’t forget to rate and review your piece in the product detail page. ...
