GT Series Installation Manual Supplement

Programming Guide for Assigning Tenant Station ID Numbers

Follow these instructions carefully when programming the GT entrance panel to call tenant stations.
Ensure that all units are installed and wired properly. If your system includes the GT-NS name scroll
module or GT-DM entry panel, program the resident information (tenant names and room numbers)
before assigning the ID's.
1. Turn the power switch on the GT-BC to the ON position.
2. At the Entrance Panel, loosen the screw on the bottom of the front frame
using the supplied #10 spanner tool (part # 262230) and remove the front
panel.
(Note: a #10 spanner bit is available at most hardware stores.)
3. To put the system into program mode, lift the rubber cap on the GT-DA-L
and press and release the program button
as a small screw driver. If using the GT-DM enter the programming mode
and select Programming in the menu. The In-Use LED will blink for
approximately 6-15 seconds, then remain lit solid.
4. After the In-Use LED is lit solid, press and release the talk button on the
first tenant station. You should have hands-free communication between
the tenant and the entry at this point. If programming a video system, you
should also have the video image from the entrance station.
5. For the GT-SW, press and release
tenant you are in communication with.
beep tone, you have just cleared the station. Press and release quickly; you will
hear a short blip tone upon releasing. This indicates that the unit has been
programmed correctly.)
For the GT-NS or GT-DM, scroll to the resident name and number you
wish to assign then
tone will be emitted at the entry panel indicating a successful program for
that tenant. See bullet point below if more than one blip is heard.
6. Press the talk button again on the tenant station to turn that unit off. If this
is your first time programming the system, it is recommended to exit
programming and test the station that you just programmed. Press the
program button on the GT-DA-L once or scroll to Quit on the GT-DM to exit
programming and the LED will go off. You should now be able to call the
tenant you just programmed. If it works, re-enter program mode and repeat
the previous steps to program the remaining tenant stations in the system.
If there is more than one tenant station in a unit (with the exception of GT-2C's and GH-2H's), each
station will have to be assigned to the entry panel using the procedure above. The entry panel will
emit 2 blip tones for the second unit, 3 blip tones for the third unit, and 4 blip tones for the fourth unit
that is programmed for entry from the panel.
tones are heard, you'll need to clear the program for the tenant and entry panel address. See page 2.
Pg. 1
0412
IMPORTANT:
the button you wish to assign to the
(If you press and hold until you hear the
press and release the bell (call) button. A short blip
using a long thin tool, such
5 blip tones indicates a programming error. If 5 blip
