- Page 1 Installation Guide Handmade Stainless Steel Farmhouse Kitchen Sink K1-SF27 K1-SF30 K1-SF33 K1-SF36 K1-DF33 K1-DF36 www.kibiusa.com...
-
Page 2: Installation
5- Keep this booklet and the receipt (or other proof of date and place of purchase) for this product in a safe place. The receipt is necessary to request warranty parts. 6- KIBI does not accept any liability for damage to countertop, sink fixture, faucets or personal injury during installa- tion. Warranty is void if installation guide is not followed. - Page 3 Determine Reveal Type KIBI Farmhouse sinks can be installed in three different types: 1/8“ Negative Reveal Flushed/Zero Reveal KIBI Recommended installation type 3/8“ Positive Reveal Caution: When determining sink placement, be sure to check that there is adequate clearance behind the sink for any faucet(s) and your backsplash, as well as clearance for a full range of motion for faucet spouts and handles.
- Page 4 Installation Supports Prepare the sink base cabinet. Build structural supports on the inside frame of Measure the actual height of apron, Add 1/16” to the the sink base cabinet. The structural supports must dimension when you mark base cabinet front cutout. support the weight of the sink and any attachments such as garbage disposals.
- Page 5 (38.1 mm) (38 mm) 3-1/8" 3-9/16” 9” 9" (80 mm) (90 mm) (229 mm) (228.6 mm) 3/4" (20 mm) K1-SF27 K1-SF30 27”x22”x10” 30”x22”x10” Min cabinet Size: 30” Min cabinet Size: 33” 33" (838.2 mm) 36" (914.4 mm) 2" 30" (50 mm) 2"...
- Page 6 Dimensions 33" 36" (838.2 mm) (914.4 mm) 2" 17-3/8" 11-5/8" 2" 19" 13" (50 mm) (441.3 mm) (50 mm) (295.3 mm) (482.6 mm) (330.2 mm) 1" 1" (25.4 mm) (25.4 mm) 1-1/2" 1-1/2" (38.1 mm) (38.1 mm) 3-1/8" 3-1/8" (80 mm) 9"...
-
Page 7: Troubleshooting
Trouble-Shooting If you’ve followed the instructions carefully and your sink still does not work properly, take these corrective steps. Trouble - Shooting PROBLEM ACTION Use a nylon pad with an iron-free abrasive polishing compound. Follow the direction of the original brush lines and the scratch will disappear as it’s blended into the original finish. Be Scratches careful to not polish too aggressively since you’ll polish out the original brush lines and end up with a shiny spot. - Page 8 If left on the sink too long it can cause • This warranty applies to residential installations only. surface pitting. • Kibi reserves the right to examine product in question and its installation prior to replacement. Never use a steel wool pad to clean your sink. Doing so may •...
