- Page 1 Installation Guide Cube C-KBF1024-KPW100 www.kibiusa.com...
-
Page 2: Before Installation
Contact KIBI VOLUME-C 855-883-0888 ✉ support@kibiusa.com �� www.kibiusa.com PRIOR TO INSTALLATION 1- For best results, we recommends that this unit be installed by a licensed, professional plumber. - Page 3 Dimensions Critical dimensions show in mm 6-11/16" (171 mm) 1-3/4" 1-7/16" (44 mm) (36 mm) 1-15/16" 3-15/16" (50 mm) (100 mm) 4" 4" 5-5/16" (102 mm) (102 mm) (135 mm) 2-7/16” (Φ62 mm) 2-7/16 (max 62 mm) Φ1-5/8” G1-1/4 Thread 1-1/4”...
-
Page 4: Parts List
Parts List Handle Assemblies Internal hex screw M5x4 Cold stem unit Assembly 402060000 Aerator Hot stem unit Assembly WaterLine O-ring M10_3/8”_27-1/2” Rubber Washer Metal Washer Rubber Washer Mounting Nut Mounitng Screws Matel Washer Mounting Nut Allen Key 2.5mm Hose Assembly Pop up Drain... -
Page 5: Faucet Installation
Faucet Installation Shut off water suppliers. Remove the old faucet, clean the Remove the mounting hardware from the mounting mounting surface. pipe. Note: For first time install, flush the pipes first by open the angel valve to run 60s. From below the sink, Slide rubber washer, metal washer and mounting bracket onto the thread shank, Then tighten the mounting nuts with phillips screwdriver until Connect the water supply lines to faucet. - Page 6 Pop-up drain Installation Remove all components from drain piece including: thin and thick silicone washer, hard washer, drain nut and tail piece. Insert thick silicone washer and hard washer over the Insert drain and thin silicone washer into basin. Apply exposed mail threaded area and screw drain nut onto Teflon to the exposed male threading area of drain piece.
-
Page 8: Troubleshooting
Here are the details of our warranty policy: Kibi USA warrants the structure and finish of the faucets and accessories to be free from defects in material and workmanship under normal usage for as long as the original purchaser resides in the residence in which the product was first installed.
