- Page 1 Installation Guide Handmade Stainless Steel Undermount Kitchen Sink K1-S23 K1-S26 K1-S28 K1-S30 K1-S33 K1-D32 K1-D33-BS K1-D33-EQ K1-D33-LD www.kibiusa.com...
- Page 3 Determine Reveal Type KIBI Undermount sinks can be installed in three different types: Use scissors to cut along the line of paper template for your desired reveal type (Negative, Positive or Flushed reveal) 1/8“ Negative Reveal Flushed/Zero Reveal KIBI Recommended Installation type 3/8“...
- Page 4 3/8” 1/2” 1/2” (13mm)
-
Page 5: Installation
Installation Install anchors into drilled holes and lightly Apply a bead of silicone adhesive (not included) tap with a hammer until flush. to the sink edges. Do not use epoxy. Position the sink in the opening. Tighten the fasteners until just snug. Check the alignment of the sink in the opening. - Page 6 (584.2 mm) (660 mm) 21" 24” (533.4 mm) (610 mm) Φ3-1/2” (Φ90 mm) 1" 1” (25.4 mm) (25.4 mm) K1-S23 K1-S26 23”X18”X10” 26”X18”X10” Min Cabinet Size: 27” Min Cabinet Size: 30” 28" (711.2 mm) 30" 26" (762 mm) (660.4 mm) 28"...
- Page 7 Dimensions 32-3/4" (832 mm) 30-3/4" (781.2 mm) 1" (25.4 mm) 1" 1" (25.4 mm) (25.4 mm) 18" 11" (457.2 mm) (279.4 mm) 32" (812.8 mm) K1-S33 K1-D32 32-3/4”X19”X10” 32”X20”X10” Min Cabinet Size: 36” Min Cabinet Size: 36” 32-3/4" 32-3/4" (832 mm) (832 mm) 14-7/8"...
- Page 8 Dimensions 32-3/4" (832 mm) 30-3/4" (781.2 mm) 18-5/8" 12" (473 mm) (305.2 mm) 1" (25.4 mm) K1-D33-LD 32-3/4”X19”X10” Min Cabinet Size: 36”...
-
Page 9: Troubleshooting
Trouble-Shooting If you’ve followed the instructions carefully and your sink still does not work properly, take these cor- rective steps. Trouble - Shooting PROBLEM ACTION Use a nylon pad with an iron-free abrasive polishing compound. Follow the direc- tion of the original brush lines and the scratch will disappear as it’s blended into Scratches the original finish. - Page 10 • This warranty applies to residential installations only. • Kibi reserves the right to examine product in question Never use a steel wool pad to clean your sink. Doing and its installation prior to replacement.
