- Page 1 ProCair User Guide Static Mode Programming Option novis.com.au 1300 738 885 Enabling Independence...
-
Page 2: Important Notice
If you have any questions, please contact Novis Healthcare on 1300 738 885. Class II Protection against Electric Shock Type BF Applied part Novis Healthcare has a policy of continuous Alternating Current product improvement and reserves the right to amend specifications presented in this guide. - Page 3 Contents System Overview Intended Use Safety Precautions System Preparation Patient Set Up Operation - Control Panel Operation Care and Cleaning Troubleshooting Technical Specifications Warranty Statement SOFT GOODS CONTROL UNIT 3 YEAR WARRANTY 3 YEAR WARRANTY ProCair User Guide...
-
Page 4: System Overview
System Overview The ProCair is an alternating mattress replacement The system consists of the following components: system for the prevention and treatment of skin Mattress replacement with umbilical air † breakdown and pressure injuries in patients of hoses and CPR release high to very high risk. -
Page 5: Intended Use
ProCair mattress bases. replacement systems contraindications include: Instable spinal cord injury † The ProCair control unit can be fitted to the foot Cervical traction † board of most hospital or aged care beds. Therapeutic devices should only be used in Intended Care Setting accordance with manufacturer’s instructions and... -
Page 6: General Safety Precautions
Only the control unit and mattress combination outlet by the head of the bed. as indicated by Novis Healthcare should be used, otherwise the correct function of the Minimise layers between patient and product cannot be guaranteed. -
Page 7: Protection Against Hazards
Ensure there is no moisture in or near the heated surfaces. Should the power cord be found to power inlet, control handset and power cord be worn or damaged, contact Novis Healthcare for before reconnecting the power supply. a replacement. -
Page 8: System Preparation
Carefully unpack the system and inspect each item for any damage that may have occurred during transit and handling. Any damage or missing components should be reported to Novis Healthcare as soon as possible. Confirm there are no sharp objects in the immediate area which may risk damage to the mattress replacement. - Page 9 Ensure the umbilical cord is not trapped between the mattress and bed. Failure to do so could result in an under inflated mattress leading to patient injury. ProCair User Guide...
- Page 10 System Preparation Feed power cord through the cord retention loops along either side of the mattress base. Insert power cord plug into the side of the control unit, then connect to an appropriate electrical outlet and switch on mains power. The Power indicator will glow amber, confirming the control unit is connected to a power source.
-
Page 11: Patient Set Up
Alt to return to an alternation cycle. Wait at least one more cycle (12 minutes) for pressure to increase before repeating step 3. We recommend repeating the Bottoming Out test at least 12 minutes after any manual pressure readjustment. ProCair User Guide... -
Page 12: Operation - Control Panel
Operation - Control Panel ALARM POWER FAILURE MUTE FOWLER 3 SEC SERVICE PRESSURE SETTING AUTO INFLATE STATIC ‹ SOFT FIRM › 3 SEC A Pressure Setting B Alarm Code Display Allows for manual pressure setting (softer or Displays visual alarm code. Refer to Alarm Codes firmer)after the AutoCair feature is deactivated. - Page 13 Press to set Alternating mode (alternate cells periodical service and maintenance procedures. cyclically inflating and deflating). Light illuminates Please contact Novis Healthcare for support. to indicate Alternating mode is active. Equipment must only be serviced by qualified personnel.Refer to the next page on details of the I Fowler Boost above modes of operation.
-
Page 14: Alarm Codes
Pressure Pressure Fail Failure If the problem persists, contact Novis Healthcare for further advice about repair. Do not try to open the control unit unless qualified. Doing so will void warranty and could cause personal injury or equipment damage. Mode... -
Page 15: Operation
‘CLOSED’ position markers, ensure control unit is switched on and wait for the system to regain optimal pressure. Sealed Mattress Base CPR “CLOSED” CLOSED indicator arrows should align with CPR indicator arrow. ProCair User Guide... - Page 16 Operation Deflation and Storage Press the power button for a minimum of three seconds to switch off the control unit. Switch off mains power and unplug the power cord from the mains outlet. Turn the Quick Twist CPR to OPEN to release air and Note: Non-Sealed Mattress model shown in image.
-
Page 17: Care And Cleaning
This could result in damage to the equipment and may result in damage to the polyurethane coating, or negate the biocompatibility properties of the fabric. Cleaning and Infection Control It is recommended that the ProCair system is cleaned every two weeks if in constant use. Top Cover Cleaning Control Unit/Handset Cleaning... - Page 18 Care and Cleaning For infection control, swab with a solution of sodium hypochlorite or similar (up to 10,000 ppm available chlorine). Dry thoroughly before reattaching and use. Top Cover Removal Raise the waterfall skirt and locate the zippers at the foot end of the mattress. Starting with either zipper, run the zipper along the side of the mattress towards the centre of the head end.
-
Page 19: Troubleshooting
Reconnect to power after 1 minute and restart initiation process, return patient to mattress once initiated Air cells have failed to and alternation has resumed. Alternation alternate Alternation Failure If issue persists, contact Novis Healthcare – a service may be Failure required. ProCair User Guide... -
Page 20: General Troubleshooting
Turn off and unplug the control unit Control unit controls lock up, ‘freeze’. Rest the control unit for one minute before reconnecting the control unit to mains power and switching on. If the problem persists, move patient to an alternate product and contact Novis Healthcare. -
Page 21: Technical Specifications
Technical Specifications Technical Specifications ProCair ProCair Sealed Base MODEL APMPC-R01 APMPC-R01S SYSTEM CODE 40 - 200 kg CAPACITY SYSTEM 18, including 3 static head cells, NO OF CELLS All cells include a static lower chamber (cell-in-cell) IEC60601-1, IEC60601-1-2 and IEC60601-1-11... -
Page 22: Waste Disposal
(non-sealed base) Do NOT use unapproved accessories or TPU-laminated nylon AIR CELL attempt to modify, disassemble or otherwise 224 mm misuse the ProCair system or any of its components. 350 mm 135 mm 3.1 kg OPERATION 30% to 75% non-condensing... - Page 23 RF communications equipment and the ProCair control unit The ProCair control unit is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the ProCair control unit can help prevent...
-
Page 24: Guidance And Manufacturer's Declaration - Electromagnetic Emissions
The ProCair control unit is intended for use in the electromagnetic environment specified below. The customer or the user of the ProCair control unit should ensure that it is used in such an environment. Immunity test IEC 60601 test level... - Page 25 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the ProCair control unit is used exceeds the applicable RF compliance level above, the ProCair control unit should be observed to verify normal operation.
- Page 26 Technical Specifications Manufacturer’s declaration-electromagnetic immunity Test specifications for Enclosure Port Immunity to RF wireless communications equipment The control unit is intended for use in the electromagnetic environment (for home healthcare and professional healthcare) specified below. The customer or the user of the control unit should assure that it is used in such an environment.
- Page 27 Contact your Novis Healthcare representative for more information 12/12 Mars Rd, 1300 738 885 novis@novis.com.au Lane Cove West, NSW 2066 novis.com.au 1300 738 885 Scan QR code for more information novis.com.au/procair Enabling Independence...
