Novis BetterLiving BL1097 Setup And Operation

S E T - U P
Designed to assist with toilet
transfers, this adjustable toilet
seat raiser attaches to existing
toilet seat mounting points.
Can be used with or without
armrests (one or both).
Seat height can be adjusted to
50 mm, 100 mm or 150 mm.
Installation
Remove your existing
toilet seat from the bowl.
Seats are generally
attached by a pair of bolts/
nuts located under the rear
rim of the toilet.
Unscrew and remove the
long plastic nuts from the
rear of the toilet seat raiser.
Nut
Adjustable Toilet Seat Raiser
A N D
Rear bar
Bolt
O P E R A T I O N
Position the unit onto your
toilet bowl, inserting the rear
mounting bolts through the
existing holes on your toilet.
Ensure the unit is centred over
the toilet bowl.
The position of the mounting bolts can be adjusted to match
different toilets. To adjust, slide the mounting bolts along the rear
bar to achieve the correct distance.
Mounting nuts must be
loose for mounting bolts to
slide freely along the bar.
Reattach both long plastic
nuts to the mounting bolts
and tighten firmly.
Check the toilet seat raiser
is firmly clamped against
the toilet bowl before use.
Prior to use please
read all instructions
Unit must be
correctly mounted
to an existing toilet
bowl before use
01
