- Page 1 Pokini Tab G10/M10 Quick Start Guide English...
-
Page 2: Table Of Contents
Deutsch Contents 1. Introduction..........................2. Device Layout .......................... 04-06 (Front, Side, Top, Bottom view) 3. Managing Device Power ......................07-09 (Netzteil, Akku) 4. Using optional features ......................10-13 (RFID, NFC, CAC, Fingerprint, Barcode Reader, GPS, Digitizer) 5. eController-App and its Applications .................. 14-16 (RFID, NFC, CAC, Fingerprint, Barcode Reader, GPS) 6. -
Page 3: Introduction
1. Introduction Welcome to your G10/M10 Tablet PC. To ensure the optimal performance of this product, please take the time to read this manual carefully. G10/M10 is a rugged tablet intended for medical/commercial uses. Explanation of Advisements In this manual we use three (3) levels of Advisements as follows: The Note symbol is used for notifying the user of something important or of something that needs special attention. -
Page 4: Device Layout
Deutsch 2. Device Layout Front View Finger Print Reader Provides Fingerprint Authentication and Security for your device (if equipped). Audio Recording Device Ambient Light Provides Automatic Adjustment of Screen Brightness for Various Lighting Conditions Sensor Front Camera Record Still and Video Images – 8 MP NFC/RFID Reader Near Field Communication/Radio-Frequency ID Device Power LED Indicator... - Page 5 Left-Side View Barcode Reader Optically Scans 1D or 2D Barcodes, if Equipped (Optional) Audio Connect headphones, speakers, or another external audio device. USB 3.0 Connect any external USB device or storage volume. HDMI Connect a secondary display via HDMI. Top View Press to activate Barcode Reader Scanning Device (button will be deactivated if Barcode Reader Button tablet not equipped with barcode reader).
- Page 6 Deutsch Right-Side View CAC Card Reader For reading Common Access Card for ID authentication. IO Cover Lock Cover the IO port for waterproof. DC in Direct current (DC) power for charging/using the tablet. RJ45 Port 10/100/1000 MB network port Speaker Sends out sound and voice.
-
Page 7: Managing Device Power
3. Managing Device Power AC Adapter The AC adapter accepts 100-240VAC Input. A standard US polarized, grounded three-pin plug adapter is included. International plug AC adapters are available for certain regions. Use only the AC adapter included with your Tablet PC. Using other AC adapters may damage the device. - Page 8 Deutsch Battery Pack The G10/M10 device has one small, permanent, internal battery and one hot-swappable battery. When hot swappable battery has low voltage and needs to be replaced, the built-in battery will power the tablet for up to 30 minutes. To charge the Battery Pack: 1.
- Page 9 Hot Swapping the Battery Pack The G10/M10 Tablet PC battery can be replaced without shutting down the tablet or interrupting your work, by use of the built-in battery. The built-in battery can sustain power for up to 30 minutes, during which period the swappable battery must be changed to prevent loss of function.
-
Page 10: Using Optional Features
Deutsch 4. Using optional features Due to the overlap features of NFC, RFID and CAC card readers, they are designed in the same location of the tablet, so the three modules cannot be installed in the same tablet, only one module can be selected. Using the RFID Reader This device may include an internal RFID reader module. - Page 11 Users must keep the NFC tag or cards close to the NFC area within 2.5 mm, otherwise the internal NFC module may not receive the signal from the tag or card. If you hear a small beep, it means the scan is successful. If you cannot get the NFC function work properly, check tag or card type.
- Page 12 Deutsch Using the Barcode Reader This device has optional internal Barcode Reader module. It is an optical input device used to capture and read information contained in a bar code. Most common 1D and 2D barcode formats can be read. The position of the reader is shown in the product layout in Chapter 2 (Position 14).
- Page 13 Users must insert the SIM card in the slot fully and in the correct orientation, and make sure the SIM card is enabled by the carrier, otherwise the card will not be read. The G10/M10 Tablet is able to support cellular connections that do not require a SIM card (such as eSIM or Built-In SIM).
-
Page 14: Econtroller-App And Its Applications
Deutsch 5. eController App and its Applications The eController App is designed to quickly check if device modules are working properly. It tests the following mod- ules: 1. Fingerprint Reader 2. CAC (Common Access Card) Card 3. RFID 4. NFC 5. - Page 15 CAC Card Reader When activated, the user may place an enabled card into the chip card reader. Users should then select “Read” on the screen, and the screen will display whether the card was read properly or not. If the reader indicates that the card cannot be read, please remove and reinsert the card, checking that it is inserted fully and in appropriate orientation.
- Page 16 Deutsch Barcode Scanner To test the barcode scanner, select the barcode test, point the scanner at a barcode (or QR code), and press the SCAN button on the screen or press the physical scan button on the handle of the tablet. System will quickly scan and display the barcode information on screen.
-
Page 17: Product Care
6. Product Care Temperature & Humidity General Use - Operating temperature The G10 is best kept in dry conditions at room temperature. The recommended range for temperature and the hu- midity value for the device is as follows: • Ambient temperature: 0°C to 35°C (32°F to 95°F) •... - Page 18 Deutsch Avoid exposing the G10/M10 device to fire or to temperatures above 60°C/140°F. These conditions may cause the battery to malfunction, generate heat, ignite or explode. Be aware that it is possible, in a worst-case scenario,for temperatures to reach greater than those stated above in, for example, the trunk of a car on a hot day.
-
Page 19: Troubleshooting
8. Trouble shooting In most cases, restarting your device will cure any problem. To restart your device, Select Start and then select Power - Shut down. If your device has crashed, hold down the power button or remote power button for 5+ seconds to hard shutdown. - Page 20 Deutsch B3 Industry Canada Statement Caution 1. The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential for harmful interference to co-channel mobile satellite systems; 2. The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz shall be such that the equipment still complies with the e.i.r.p.
-
Page 21: Technical Specifications
9. Technical Specifications •IP-65 Waterproof | •Drop: 4FT drop resistant on 4 corners to plywood (MIL-STD-810G) | •Shock resistant: MIL-STD- Ruggedness 810G, method 516.6, procedure I | •ESD Protection: 4KV touch, 8KV air Ultra-LCD protection (Option) Processor Intel® Apollo Lake N4200, Quad-core, base 1.1GHz, Burst 2.5GHz Intel®... - Page 22 Support You have any technical questions? If you have problems or questions, please contact us by e-mail: support@ @ pokini.de V1.1 / 05-2022 EXTRA Computer GmbH Brühlstr. 12 89537 Giengen-Sachsenhausen Deutschland/ Germany www.pokini.de all rights reserved...
