Summary of Contents for Pokini Tab A10C

  • Page 1 Pokini Tab A10C Quick Start Guide English...
  • Page 2 Deutsch Tab A10C features, buttons & interfaces Front Ambient Light Sensor Recognizes the ambient light and adjusts the display brightness if enabled in the operating system Front camera 13MP camera for video conferencing Camera Indicator LED Lights up if camera is activated and during device boot and shutdown...
  • Page 3 Top Side On / Off Button Push it once to start the tablet; push it again to enable the sleep mode. Push and hold it to shut down the device. Push it for more than 10secs to reset the device. Volume key Push the left side to reduce the volume, use the right side to increase the volume Right and Bottom Side...
  • Page 4 Deutsch Rear View Camera flash LED Rear camera 13MP camera for high resolution images & video Battery lid (with custom logo sticker)
  • Page 5 Tab A10C features, buttons & interfaces To replace the battery, release both battery lockers (1) and lift the battery (2) The memory card can be inserted on the upper side, please ensure you insert it in the right direction as shown on the picture.

  • Page 6: Using The Tablet For The First Time

    Deutsch Using the Tablet for the first Time Connect power supply for the first time and make sure battery is fully charged before disconnecting. We recommend a charging dock or docking station to charge the tablet. If you use a USB-C wall charger, please ensure it has at least 18W and follows USB-C standard. To turn on the tablet, press the power button once. Follow the instructions in the operating system to complete the setup.
  • Page 7 Protect your device from water and moisture intake. Keep connector doors closed when not in use to prevent water and moisture intake. Listen to a headset at a moderate level, and do not place the device loudspeaker outlets near your ear when the loud- speakers are in use.
  • Page 8 Deutsch Replaceable battery safety: - Batteries have life cycles. If the time that the battery powers equipment becomes much shorter than usual, the bat- tery life might be at the end. Replace the battery when a significant loss of run time is detected. - When batteries are stored over six (6) months, some irreversible deterioration in overall battery quality may occur. - Store batteries at half of full charge in a dry, cool place, removed from the equipment to prevent loss of capacity, rusting of metallic parts and electrolyte leakage.

  • Page 9: Warning Statements

    Warning Statements To prevent possible hearing damage, do not listen at high volume levels for long periods. Antenna Positions Your device meets guidelines for exposure to radio waves (SAR, Specific Absorption Rate) when kept in a close dis- tance to your body. It is recommended to learn the antenna positions as mentioned below and not to touch or bring your body close to these antenna areas.

  • Page 10: Eu Declaration Of Conformity

    Deutsch Conformity Declarations Depending on the actual model, the following conformity / compliance statements are valid. Please check the type label of your device for further information. EU Declaration of Conformity Hereby, Aava Mobile declares that the radio equipment INARI-D-10-WIG-1 is in compliance with Directive 2011/65/ EU and 1999/5/EC or 2014/53/EU (2014/53/EU supersedes 1999/5/EC from 13th June 2017).

  • Page 11: Fcc Compliance Statement

    Wireless Devices Country Approvals Regulatory markings, subject to certification, are applied to the device signifying the radio(s) are approved for use in the following countries: United States, Canada, and Europe1. Please refer to the Aava Mobile Declaration of Conformi- ty (DoC) for details of other country markings. This is available at http://www.oona-solution.com/doc. 1 Europe includes: Austria, Belgium, Bulgaria, Croatia, Czech Republic, Cyprus, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Liechtenstein, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovak Republic, Slovenia, Spain, Sweden, Switzerland, and the United Kingdom.

  • Page 12: Radio Transmitters (Part 15)

    This product has been tested and found to comply with the following standards: - For the worst-case positions, the Tab A10C complies with the IC RSS 102 Issue 5 (RSS 102) and Federal Communications Commission (FCC) Guidelines (KDB) 447498 D03 for uncontrolled exposure.

  • Page 13: Radio Frequency Interference Requirements - Canada

    Radio Frequency Interference Requirements - Canada CAN ICES-3 (B)/NMB-3(B) Radio Transmitters This device complies with Industry Canada‘s license-exempt RSSs. Operation is subject to the following two conditi- ons: (1) This device may not cause interference; and (2) This device must accept any interference, including interfe- rence that may cause undesired operation of the device.

  • Page 14: 802.11 Radio Precaution Statement

    Deutsch Radiation Exposure Statement (SAR) Warning: This equipment complies with SAR for general population / uncontrolled exposure limits in SNAI / IEEE C.951, Federal Communication Commission Office of Engineering and Technology (KDB) 447498 D03, Canada RSS- 102, and CENELEC limits for exposure to radio frequency (RF) radiation. Specific Absorption Rate (SAR) 1.191W/kg (WLAN version) Énoncé sur l’exposition aux radiations (SAR) Avertissement : Cet équipement est conforme aux limites d’exposition au rayonnement à...

  • Page 15: Waste Electrical And Electronic Equipment (Weee)

    Radio Frequency Interference Requirements - Brazil The device meets the SAR limit of 2.0W/kg established by Anatel (National Telecommunications Agency in Brazil). The product should be kept at least 1.5cm from the body to ensure compliance with the radio frequency exposure limits.
  • Page 16 Deutsch EXTRA Computer GmbH Brühlstraße 12 89537 Giengen an der Brenz, Germany Tel.: +49 40 6979 5939 www.extracomputer.de © 2023 Aava Mobile Oy, All rights resevered...
  • Page 17 Support You have any technical questions? If you have problems or questions, please contact us by e-mail: support@ @ pokini.de V1.0 / 03-2024 EXTRA Computer GmbH Brühlstr. 12 89537 Giengen-Sachsenhausen Deutschland/ Germany www.pokini.de all rights reserved...
