- Page 1 Tab K11 Vehicle Dock Quick Start Guide English...
- Page 2 English Product Overview Front Item Top spring latch Alignment port (x2) Triple RF pass-thru connectors Docking connector Latch bar (with key slot) Rear Item DC-in jack * LAN (RJ-45) port USB3.0 port (x2) USB2.0 port (x2) HDMI port VGA port Serial port (RS-232) Audio out jack Microphone in jack...
- Page 3 4. Push the side spring latch all the way to the left to disengage the top spring latch. NOTE: Top spring latch disengages automatically after the side spring latch is fully extended. Docking the Tablet-PC 1. With screen side facing out and docking 2.
- Page 4 English Undocking the Tablet-PC 1. Insert the latch bar key into the latch bar and 2. Push the side spring latch all the way to the left turn clockwise until a “click” is heard. Turn the to disengage the top spring latch. key back counterclockwise to remove it from the NOTE: Top spring latch disengages automatically key slot.
- Page 5 Support You have any technical questions? If you have problems or questions, please contact us by e-mail: support@pokini.de V1.0 / 01-2021 EXTRA Computer GmbH Brühlstr. 12 89537 Giengen-Sachsenhausen Deutschland / Germany all rights reserved...
