  • Page 1 Pokini Tab K10 & K10B Manual English...

  • Page 2: Table Of Contents

    Deutsch Table of Contents Related Information ..................................Conventions ...................................... Safety Guidelines ..................................... Intended Use Maintenance and Operation Overview Safety Electrical Hazards Environmental Radio Transmissions Cleaning and Servicing Regulatory and Certification Lithium Battery Safety Statement Introduction ....................................... About This Guide Unpacking the Device Technical Specifications Tab K10 &...
  • Page 3 Installation an Operating System BIOS Passwords EC and BIOS Using the DashON Utility ................................40 Overview Troubleshooting ....................................41 Troubleshoot the Wi-Fi Connection Troubleshoot Operating the Computer Call Product Support Maintenance ..................................... 44 Cleaning the Device Returning the Device Contacting Pokini...

  • Page 4: Related Information

    This document is intended for use by qualified personnel to compliment the training and expertise, not to replace it. Related Information Current information and manuals are available for download at the following website: www.pokini.de Conventions Bolded or underlined text is used to emphasize the designated information.

  • Page 5: Intended Use

    Intended Use The Tab K10(B) rugged tablet is equipped with multi-functional terminals for stationary and mobile applications in in- dustrial environments such as logistics, warehousing, fleet management, manufacturing and the automotive industry. Read the safety guidelines thoroughly before starting any servicing on the device. Read the guidelines before power- ing up the device, and keep this document for later use.

  • Page 6: Electrical Hazards

    To prevent the considerable damage, the Tab K10(B) and the external device should be disconnected from power when connecting/disconnecting excluding USB devices. Only Use Authorized Accessories Only use the supplied cables, power packs and other accessories that have been tested and approved by Pokini. Con- tact your local distributor for further information.

  • Page 7: Radio Transmissions

    Radio Transmissions Permitted Transmission Power Follow the national regulations for the maximum permitted transmission power. The operator is solely responsible for this type of operation. Radio Frequency Limited Locations Considering the radio frequency limitation in hospitals and aircraft, the Tab K10(B) can only be installed with permis- sion.
  • Page 8 Deutsch Consult the dealer or an experienced radio / TV technician for help. - Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. -This device is operation in 5.15 – 5.25GHz frequency range, then restricted in indoor use only, Outdoor operations in the 5.15 –...

  • Page 9: Lithium Battery Safety Statement

    R&TTE This device complies with the essential requirements of the R&TTE Directive 1999/5/EC. This device is classified as class 2 in Article 1(2) of Decision 2000/299/EC due to its capability of operating WLAN in the band 5.15 to 5.35 GHz. This device complies with the IEC 60950-1:2005+A1.

  • Page 10: Technical Specifications

    Deutsch Technical Specifications Item Description Item Description Display 10.1-inch LED Backlight, 1920 (W) x 1200 (H) WUXGA Touch screen 10-point capacitive touch screen with optional digitizer Brightness 1000 nits (before touch) Intel Core i5-7300U (2x 2.60 GHz) / Intel Core i5-8250U (4x 1.6 GHz) Operating System (Optional) Windows®...
  • Page 11 Item Description Item Description RS-232 Micro HDMI Ethernet Security TPM 2.0 BIOS On/Off for I/Os Data Collection - Front: 2.0 Mega-Pixels camera Camera - Rear: 8.0 Mega-Pixels camera with LED auxiliary light and Auto-focus GNSS Optional Barcode Reader Optional Smart Card Reader Optional Rugged Specifications Drop...

  • Page 12: Parts List

    High capacity battery • 4G LTE • Digitizer Parts List The Tab K10(B) is shipped with the following items. All other accessories are sold and ordered separately. For help, contact your local Pokini sales representative. Power Adapter Stylus or Digitizer Tab K10(B)
  • Page 13 Overview Left view See “Side View” for further information. Front view See “Front View” for further information. Rear view See “Rear View” for further information. Right view See “Side View” for further information. Easy to grip rubber bumpers enable the rugged Rubber bumpers tablet to withstand shocks and drop for use in demanding environments.
  • Page 14 Deutsch Product Overview Front View Front camera 2.0 Mega-Pixels camera. Touch screen 5-point capacitive touch. Barcode trigger If barcode scanner is installed, press to scan. Battery LED Display battery status Wi-Fi LED The Wi-Fi LED lights to indicate Wi-Fi is enabled. FN LED The FN LED lights when the function switch on.
  • Page 15 Volume - Volume decrease. Power key Turns the Tab K10(B) on or off. Power LED The power LED lights when the device is on. F2 key Programmable function key. F1 key Programmable function key. FN key Programmable function key. LED Status Item Status Description...
  • Page 16 Deutsch Bottom View Docking connector 12 pin connector for docking onto a station. Kensington lock Lock the Tab K10(B) to a stationary object for security. Pass-through Dual pass-through for WLAN, GNSS and WWAN. Left View Micro HDMI Connect HDMI devices to the Tab K10(B). USB 3.1 Type C Connect USB devices to the Tab K10(B).
  • Page 17 Left View DC-IN jack Insert power connector to charge battery. RS-232 Connect the Tab K10(B) to a serial device. DC-IN cover Open to access the DC-IN jack. Right I/O compartment cover Open to access the right I/O port.
  • Page 18 Deutsch Rear View Battery To install a battery, an external battery is optional. Rear camera 5.0 Mega-Pixels camera with LED auxiliary light. Barcode reader For installing a barcode reader. (Optional) Embedded fan for cooling. Secure the bumpers and the D-rings for the handstrap and shoul- Securing holes der strap.

  • Page 19: Identifying The Digitizer

    Identifying the Digitizer (Optional) You can use the optional digitizer to control your Tab K10(B) as with a mouse or keyboard. Click Button Dimensions The following image lists the device dimensions without add-ons (mm/inches). 23 / 0.9 280 / 11 Touch Screen Features Always use the point of the digitizer for clicking or making strokes on the touch screen.

  • Page 20: Getting Started

    This section provides an outline of the steps necessary to setup a new Tab K10(B). A detailed guide follows the listed items, see as follows. For additional technical assistance, contact your Pokini representative. It is recommended to installing or remove accessories on a clean, well-lit work surface.

  • Page 21: Charging The Battery

    Charging the Battery When you use the AC adapter to connect your Tab K10(B) to a power outlet, the standard and external (optional) bat- tery will automatically begin to recharge.While the battery is charging, the power LED will be active. When the battery is fully charged, the power LED is lit a solid green.

  • Page 22: Powering The Device On And Off

    Deutsch Powering the Device On and Off Powering On the Device Only power on the Tab K10(B) after connecting all of the peripherals and cabling. 1. Press and hold the power button until the screen lights. The device runs through the start up sequence and powers up.
  • Page 23 4. Take the micro SIM card from its packaging. 5. Push the SIM card cover to open and place the micro SIM card to the slot. 6. Close the SIM card cover. 7. Install the 4G LTE card and its antennas to the slot and close the service door. Using the Digitizer Following the information below when using a digitizer: •...

  • Page 24: Operation

    Deutsch Removing the Protective Film from the Display The front display of the Tab K10(B) is protected during transport by a transparent film. This film should remain on the front display during assembly to avoid damage to the front display surface. Only remove the film once all of the assembly work has been completed.

  • Page 25: Connecting To External Cabling

    3. Unlock the latch. (Only available for the left I/O compartment cover) 4. Pull out the I/O compartment cover. Connecting to External Cabling To prevent damage to the device, connect all cabling and accessories before powering up the device. Connect USB Cabling The Tab K10(B) has one USB 3.1 Type C and one USB 3.1 Type A port for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse.
  • Page 26 Deutsch Connect Ethernet Cabling The Tab K10(B) provides a Ethernet port for connecting Ethernet. Use a shielded cable is required to maintain emissions and susceptibility compliance. 1. Open the left I/O compartment cover. 2. Connect LAN cable to Ethernet port on the Tab K10(B). Connect Audio Cabling For higher audio quality, you can send sound through external audio devices such as speakers, headphones, or earphone using audio connector.
  • Page 27 Connect Micro HDMI Cabling Connect to HDMI devices via micro HDMI cable. 1. Open the left I/O compartment cover. 2. Connect micro HDMI cable to micro HDMI port on the Tab K10(B). Connect RS-232 Cabling Connect to RS-232 devices with an RS-232 cable. 1.

  • Page 28: Handstrap, Carrying Handle And Shoulder Strap

    Deutsch Handstrap, Carrying Handle and Shoulder Strap (Optional) The Tab K10(B) can be optionally equipped with a handstrap, a carrying handle or a shoulder strap for convenience and choice. Select the accessory that is right for your needs. The handstrap can be installed with either the shoulder strap or the carrying handle.

  • Page 29: Installing The Standard Battery

    Connecting / Remove the Carrying Handle 1. Attach the clips to the metal loop on the bumper. Connecting / Remove the Shoulder Strap 1. Attach the clips to the metal loop on the bumper. Installing / Removing the Standard Battery The following instructions are for both standard and external batteries.
  • Page 30 Deutsch Locking Switch Release Button Battery 3. Align the tabs on the battery with the slots on the chassis. 4. Angle the battery in place and set the tabs in the chassis slots. 5. Lower the raised end of the battery and press in place until an audible click is heard.

  • Page 31: Connecting To A Wireless Network

    Connecting to a Wireless Network Before you can make use of the Tab K10(B) wireless functions, you need to connect to a network. The following is a set of procedures for connecting to a wireless network. 1. Before beginning, make sure your Wi-Fi setting is enabled and you are within range of a wireless network. If your Wi-Fi setting is disabled, proceed to step 2.

  • Page 32: Using The Bios Setup Utility

    Deutsch Using BIOS Setup Utility Your ruggedized tablet has a BIOS setup utility which allows you to configure important system settings, including settings for the Boot and AP menus as well as the device’s basic settings--the system reads the basic settings during initialization in order to boot correctly.

  • Page 33: Installation An Operating System

    Due to the device’s fast boot up and boot down time, there is only a small time frame of a few seconds between the release of the Power button and the opportunity to press the Windows Home key. The App Menu displays. Installation an Operating System Setting Up a Windows Installation Environment: There are several settings in BIOS that must be modified before you can install a Windows operating system.
  • Page 34 Deutsch • Step2: Enable Legacy Boot 1. Access the BIOS Setup Utility. 2. Navigate to APP Menu > Main > Boot Features. 3. Locate the Legacy Boot setting and tap on the menu to select On enable legacy boot. • Step3: Advanced >...

  • Page 35: Bios Passwords

    BIOS Passwords Setting Up a Supervisor Password To setup a supervisor password, follow the procedure as described: 1. Go to APP Menu > Security > Account’s Password Status. 2. Tap the Enter icon next to Setup the Supervisor Password to access the virtual keyboard. 3.
  • Page 36 Deutsch 6. Tap Exit Saving Changes to display the confirmation screen. 7. Tap Yes to save the new configuration settings. After setting the Supervisor password, the password is required to access the BIOS Setup Utility. Changing a Supervisor Password 1. Navigate to APP Menu > Security > Account’s Password Status. 2.

  • Page 37: Ec And Bios

    EC and BIOS Updating BIOS This procedure allows you to update and reflash the system BIOS. Both procedures follow the same steps as described in the following. Make sure to protect your device from power loss during the BIOS update procedure to prevent irreparable damage to your system’s mainboard.
  • Page 38 Deutsch 7. From the PC settings menu, tap Update 8. From the Update and recovery screen, tap Recovery. The Advanced startup option displays. and recovery to continue. 9. Under Advanced startup, tap Restart now. 10. Tap Use a device to select a boot up preference.
  • Page 39 11. From the Use a device menu, tap Internal Shell to open 12. In the command screen, enter fs1: to select the USB device already connected to the device. The command the command screen. directs you to the USB device’ s root menu. 13.

  • Page 40: Using The Dashon Utility

    Deutsch Using the DashON Utility Overview The DashON resident program is designed to provide near-instant access to your device’s settings and configuration within a single, easy to use interface. The following information illustrates and describes the various settings availa- ble for configuration through the DashON menus. Important: Do not terminate or remove the DashON program manually or the ambient light sensor and the function buttons will be malfunction.

  • Page 41: Troubleshooting

    If you send the computer in for service, it is your responsibility to save the computer data and configuration. Pokini is responsible only for ensuring that the hardware matches the original configuration when repairing or replacing the computer.

  • Page 42: Troubleshoot The Wi-Fi Connection

    Deutsch Troubleshoot the Wi-Fi Connection Use this troubleshooting table to help solve problems with your 802.11 radio connection. Q. When you turn on the computer after it was suspended for a while (10 to 15 minutes or longer), it can no longer send or receive messages over the network.

  • Page 43: Call Product Support

    Call Product Support Simple instructions please contact the dealer, contact Pokini representative, or leave a message visit the Pokini website at www.pokini.de. To better assist you have the following information ready: • Configuration number • Serial number • Operating system, BIOS, and MCU versions •...
  • Page 44 Prevent using any kind of chemical solvent, acidic or alkali solution. Returning the Device Please put the contents in the original package gently when you need to return the Tab K10(B). Contacting Pokini If you experience technical difficulties, please consult your distributor or contact the technical services department: www.pokini.de...
  • Page 45 Support You have any technical questions? If you have problems or questions, please contact us by e-mail: support@ @ pokini.de V1.4 / 10-2022 EXTRA Computer GmbH Brühlstr. 12 89537 Giengen-Sachsenhausen Deutschland/ Germany www.pokini.de all rights reserved...
