Tab K10
Quick Start Guide
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tab K10 and is the answer not in the manual?

Questions and answers

Related Manuals for Pokini Tab K10

Summary of Contents for Pokini Tab K10

  • Page 1 Tab K10 Quick Start Guide English...

  • Page 2: Table Of Contents

    Cleaning and Servicing Regulatory and Certification Lithium Battery Safety Statement Introduction ............................About This Guide Unpacking the Device Technical Specifications Tab K10 Configuration Options Parts List Identifying the Device Identifying the Digitizer Dimensions Touch Screen Features Getting Started ............................. First Time Use...
  • Page 3 Accessing the BIOS Setup Utility Installation an Operating System BIOS Passwords EC and BIOS Using the DashON Utility ......................Overview Troubleshooting ........................... Troubleshoot the Wi-Fi Connection Troubleshoot Operating the Computer Call Product Support Maintenance ............................Cleaning the Device Returning the Device Contacting Pokini...

  • Page 4: Related Information

    English About This Manual The Tab K10 User’s Manual provides instruction for qualified personnel to follow when setting up a new Tab K10 device. This document is intended for use by qualified personnel to compliment the training and expertise, not to replace it.

  • Page 5: Intended Use

    The Tab K10 is designed and manufactured according to strict controls and following the stated safety regulations. The following list identifies incorrect operating uses of the Tab K10. Incorrect use of the Tab K10 can lead to hardware damage, safety issues and possible risk to personnel health: ■...

  • Page 6: Electrical Hazards

    ■ All Pokini warranties are void. Environmental Hazards Do not use the Tab K10 in locations near/with flammable gases or vapor. The use of elec- trical equipment in explosive environments can be dangerous. ■ Turn off the device when near a gas station, fuel depot, chemical plant or a place where blasting operations take place.

  • Page 7: Radio Transmissions

    ■ Disconnect the Tab K10 from power before cleaning or servicing. ■ Never clean the Tab K10 with compressed air, a pressure washer or a vacuum cleaner. ■ If necessary, clean the housing of the Tab K10 with a damp cloth.
  • Page 8 English ■ Consult the dealer or an experienced radio / TV technician for help. ▪ Any changes or modifications not expressly approved by the grantee of this device could void the user’s authority to operate the equipment. ▪ This device is operation in 5.15 – 5.25GHz frequency range, then restricted in indoor use only, Outdoor operations in the 5.15 –...

  • Page 9: Lithium Battery Safety Statement

    The Tab K10 is a rugged device equipped with 802.11, Bluetooth and GNSS for wireless data communications. The Tab K10 is a rugged 10.1” tablet computer capable of 1920 x 1200 resolution. The Tab K10 supports the following operating systems: ■...

  • Page 10: Technical Specifications

    English Technical Specifications Item Description Display 10.1-inch LED Backlight, 1920 (W) x 1200 (H) WUXGA Touch screen 10-point capacitive touch screen with optional digitizer Brightness 1000 nits (before touch) Intel Core i5-7300U 2.6 GHz Operating System (Optional) Windows® 10 IoT Enterprise CBB DDR4@2400 MT/s 8 GB RAM Storage M.2 SSD 128 GB (optional: 256 GB)
  • Page 11 Item Description RS-232 Micro HDMI Ethernet Security TPM 1.2 BIOS On/Off for I/Os Data Collection - Front: 2.0 Mega-Pixels camera Camera - Rear: 8.0 Mega-Pixels camera with LED auxiliary light and Auto-focus GNSS Optional Barcode Reader Optional Smart Card Reader Optional Rugged Specifications Drop...

  • Page 12: Tab K10 Configuration Options

    ■ 4G LTE ■ Smart card reader ■ Digitizer Parts List The Tab K10 is shipped with the following items. All other accessories are sold and or- dered separately. For help, contact your local Pokini sales representative. Power Adapter Stylus or Digitizer...

  • Page 13: Identifying The Device

    Identifying the Device Overview Left view See “Side View” for further information. Front view See “Front View” for further information. Rear view See “Rear View” for further information. Right view See “Side View” for further information. Easy to grip rubber bumpers enable the rugged tablet Rubber bumpers to withstand shocks and drop for use in demanding environments.
  • Page 14 English Product Overview Front View Front camera 2.0 Mega-Pixels camera. Touch screen 5-point capacitive touch. Barcode trigger If barcode scanner is installed, press to scan. Battery LED Display battery status Wi-Fi LED The Wi-Fi LED lights to indicate Wi-Fi is enabled. FN LED The FN LED lights when the function switch on.
  • Page 15 Volume - Volume decrease. Turns the Tab K10 on or off. Power key Power LED The power LED lights when the device is on. F2 key Programmable function key. F1 key Programmable function key. FN key Programmable function key. LED Status...
  • Page 16 English Bottom View Docking connector 12 pin connector for docking onto a station. Kensington lock Lock the Tab K10 to a stationary object for security. Pass-through Dual pass-through for WLAN, GNSS and WWAN. Left View Micro HDMI Connect HDMI devices to the Tab K10.
  • Page 17 Left View DC-IN jack Insert power connector to charge battery. RS-232 Connect the Tab K10 to a serial device. DC-IN cover Open to access the DC-IN jack. Right I/O compartment cover Open to access the right I/O port.
  • Page 18 English Rear View Battery To install a battery, an external battery is optional. Rear camera 5.0 Mega-Pixels camera with LED auxiliary light. Barcode reader For installing a barcode reader. (Optional) Embedded fan for cooling. Secure the bumpers and the D-rings for the handstrap Securing holes and shoulder strap.

  • Page 19: Identifying The Digitizer

    Identifying the Digitizer (Optional) You can use the optional digitizer to control your Tab K10 as with a mouse or keyboard. Click Button Dimensions The following image lists the device dimensions without add-ons (mm/inches). 23 / 0.9 280 / 11...

  • Page 20: Getting Started

    First Time Use Tab K10 is under “Battery Ship Mode” and will not power on to preserve the battery and prevent power loss. To enable “Regular Mode” and activate the battery, please connect...

  • Page 21: Charging The Battery

    Charging the Battery When you use the AC adapter to connect your Tab K10 to a power outlet, the standard and external (optional) battery will automatically begin to recharge. While the battery is charging, the power LED will be active. When the battery is fully charged, the power LED is lit a solid green.

  • Page 22: Powering The Device On And Off

    Powering the Device On and Off Powering On the Device Only power on the Tab K10 after connecting all of the peripherals and cabling. 1. Press and hold the power button until the screen lights. The device runs through the start up sequence and powers up.

  • Page 23: Using The Digitizer

    4. Take the micro SIM card from its packaging. 5. Push the SIM card cover to open and place the micro SIM card to the slot. 6. Close the SIM card cover. 7. Install the 4G LTE card and its antennas to the slot and close the service door. Using the Digitizer Following the information below when using a digitizer: ■...

  • Page 24: Removing The Protective Film From The Display

    English Removing the Protective Film from the Display The front display of the Tab K10 is protected during transport by a transparent film. This film should remain on the front display during assembly to avoid damage to the front display surface.
  • Page 25 Connect USB Cabling The Tab K10 have one USB 3.1 Type C and one USB 3.1 Type A port for connecting USB devices, such as a digital camera, scanner, printer, modem, and mouse. The USB Type A port support USB 2.0 or USB 3.0 devices.
  • Page 26 Use a shielded cable is required to maintain emissions and susceptibility compliance. 1. Open the left I/O compartment cover. 2. Connect LAN cable to Ethernet port on the Tab K10. Connect Audio Cabling For higher audio quality, you can send sound through external audio devices such as speakers, headphones, or earphone using audio connector.
  • Page 27 Connect Micro HDMI Cabling Connect to HDMI devices via micro HDMI cable. 1. Open the left I/O compartment cover. 2. Connect micro HDMI cable to micro HDMI port on the Tab K10. Connect RS-232 Cabling Connect to RS-232 devices with an RS-232 cable.
  • Page 28 English Handstrap, Carrying Handle and Shoulder Strap (Optional) The Tab K10 can be optionally equipped with a handstrap, a carrying handle or a shoul- der strap for convenience and choice. Select the accessory that is right for your needs. The handstrap can be installed with either the shoulder strap or the carrying handle.
  • Page 29 Connecting / Remove the Carrying Handle 1. Attach the clips to the metal loop on the bumper. Connecting / Remove the Shoulder Strap 1. Attach the clips to the metal loop on the bumper. Installing / Removing the Standard Battery The following instructions are for both standard and external batteries.
  • Page 30 English Locking Switch Release Button Battery 3. Align the tabs on the battery with the slots on the chassis. 4. Angle the battery in place and set the tabs in the chassis slots. 5. Lower the raised end of the battery and press in place until an audible click is heard.
  • Page 31 Connecting to a Wireless Network Before you can make use of the Tab K10 wireless functions, you need to connect to a network. The following is a set of procedures for connecting to a wireless network. 1. Before beginning, make sure your Wi-Fi setting is enabled and you are within range of a wireless network.
  • Page 32 To run the BIOS Setup Utility, use the following procedures: 1. Perform one of the following: ■ If the Tab K10 is powered off Press the Power button to start up the device. The power LED lights. Quickly press and hold the Windows Home key until the BIOS Post screen displays.
  • Page 33 Due to the device’s fast boot up and boot down time, there is only a small time frame of a few seconds between the release of the Power button and the opportunity to press the Windows Home key. The App Menu displays. Installation an Operating System Setting Up a Windows 7 Installation Environment There are several settings in BIOS that must be modified before you can install a Win-...
  • Page 34 English ■ Step2: Enable Legacy Boot 1. Access the BIOS Setup Utility. 2. Navigate to APP Menu > Main > Boot Features. 3. Locate the Legacy Boot setting and tap on the menu to select On enable legacy boot. ■ Step3: Advanced > Miscellaneous Configuration ■...
  • Page 35 BIOS Passwords Setting Up a Supervisor Password To setup a supervisor password, follow the procedure as described: 1. Go to APP Menu > Security > Account’s Password Status. 2. Tap the Enter icon next to Setup the Supervisor Password to access the virtual keyboard. 3.
  • Page 36 English 6. Tap Exit Saving Changes to display the confirmation screen. 7. Tap Yes to save the new configuration settings. After setting the Supervisor password, the password is required to access the BIOS Setup Utility. Changing a Supervisor Password 1. Navigate to APP Menu > Security > Account’s Password Status. 2.
  • Page 37 1. Contact your technical sales or technical representative to obtain the correct BIOS file. 2. Copy the BIOS file on to the USB device. 3. Connect the USB device to one of the device’s USB ports and power on the Tab K10. A USB keyboard is required for entering command.
  • Page 38 English 7. From the PC settings menu, tap Update 8. From the Update and recovery screen, and recovery to continue. tap Recovery. The Advanced startup option displays. 9. Under Advanced startup, tap Restart now. 10. Tap Use a device to select a boot up preference.
  • Page 39 14. Type wf (.nsh) and tap Enter. wf is the designated BIOS file. Do not turn off your device or interfere with the reflash process until the process is complete. 15. Once the process is complete, the Tab K10 automatically reboots. The BIOS is now updated. Updating EC Connect the Tab K10 to the AC adapter to prevent a sudden loss of power.
  • Page 40 English Using the DashON Utility Overview The DashON resident program is designed to provide near-instant access to your de- vice’s settings and configuration within a single, easy to use interface. The following information illustrates and describes the various settings available for configuration through the DashON menus.
  • Page 41 802.1x security, or general problems with operating the computer. If you send the computer in for service, it is your responsibility to save the computer data and configuration. Pokini is responsible only for ensuring that the hardware matches the original configuration when repairing or replacing...
  • Page 42 English Troubleshoot the Wi-Fi Connection Use this troubleshooting table to help solve problems with your 802.11 radio connection. Q. When you turn on the computer after it was suspended for a while (10 to 15 minutes or longer), it can no longer send or receive messages over the network. A.
  • Page 43 Q. The computer appears to be locked up and you cannot enter data. A. Restart the computer. Call Product Support Simple instructions please contact the dealer, contact Pokini representative, or leave a message visit the Pokini website at www.pokini.de. To better assist you have the following information ready: ■...
  • Page 44 Maintenance Cleaning the Device Danger to electric shock when cleaning or maintaining the Tab K10. To avoid electric shock, turn the Tab K10 off and disconnect it from the power supply before cleaning or maintaining it. Housing ■ The housing of the Tab K10 is best cleaned with a damp cloth.
  • Page 45 Support Sie haben Fragen technischer Art? Bei Problemen oder Fragen wenden Sie sich bitte per E-Mail an: support@pokini.de V 1.0 / 11-2018 Alle Rechte vorbehalten. © 2018 EXTRA Computer GmbH...
