  • Page 1 F13GN F13GX Oven User Manual...

  • Page 2: Table Of Contents

    14. ENERGY EFFICIENCY.................. 23 WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.

  • Page 3: Safety Information

    ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damages that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.

  • Page 4: Safety Instructions

    Always use oven gloves to remove or put in • accessories or ovenware. Before maintenance cut the power supply. • Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock.
  • Page 5 ENGLISH such a way that it cannot be removed • Do not change the specification of this without tools. appliance. • Connect the mains plug to the mains • Make sure that the ventilation socket only at the end of the openings are not blocked.
  • Page 6 • Always cook with the oven door • If you use an oven spray, obey the closed. safety instructions on the packaging. • If the appliance is installed behind a • Do not clean the catalytic enamel (if furniture panel (e.g. a door) make applicable) with any kind of detergent.

  • Page 7: Product Description

    ENGLISH 3. PRODUCT DESCRIPTION 3.1 General overview Control panel Grill indicator Knob for the oven functions Knob for the Minute Minder Knob for the gas control Power indicator Air vents for the cooling fan Heating element Lamp Turnspit hole Oven cavity bottom plate Shelf positions 3.2 Accessories To bake and roast or as pan to collect...

  • Page 8: Daily Use

    5. DAILY USE WARNING! Refer to Safety chapters. 5.1 Oven functions Oven function Application Off position The appliance is off. Light To activate the lamp without a cooking function. Grill + Turn‐ To grill meat, including kebabs and smaller pieces of spit meat.

  • Page 9: Clock Functions

    ENGLISH 5.6 Grilling • To minimise splashing, you should thoroughly dry food before grilling. 1. Turn the knob for the oven functions Brush lean meats and fish lightly with a little oil or melted butter to keep clockwise to and set the them moist during cooking.

  • Page 10: Additional Functions

    9. Select a function with the turnspit position. The turnspit rotates. 10. Set the necessary temperature. Refer to the cooking tables. 7.2 Inserting the accessories Wire shelf: Push the shelf between the guide bars of the shelf support and make sure that the feet point down.
  • Page 11 ENGLISH 9.1 General information • Leave the meat for approximately 15 minutes before carving so that the • The appliance has five shelf positions. juice does not seep out. Count the shelf positions from the • To prevent too much smoke in the bottom of the appliance floor.
  • Page 12 Food Quantity Tempera‐ Time (min) Shelf posi‐ Comments (kg) ture (°C) tion Lamb min. 40 - 50 On the wire shelf. Put a deep pan on the second shelf posi‐ tion. Pork 180 - 190 75 - 85 On the wire shelf.
  • Page 13 ENGLISH Food Quantity Tempera‐ Time (min) Shelf posi‐ Comments (kg) ture (°C) tion English 56 - 60 On the wire roast beef - shelf. Put a well done deep pan on the second shelf posi‐ tion. Pastry Food Quantity Tempera‐ Time (min) Shelf posi‐...
  • Page 14 Cakes Food Quantity Tempera‐ Time (min) Shelf posi‐ Comments (kg) ture (°C) tion Rich fruit min. 150 - 170 In a 20 cm cake mould on the wire shelf Plain fruit min. In a 20 cm cake mould on...

  • Page 15: Care And Cleaning

    ENGLISH Food Quantity Tempera‐ Time (min) Shelf po‐ ture (°C) sition Pieces 1st side 2nd side Beef max. 10 - 12 6 - 8 steaks Sausages 8 max. 12 - 15 10 - 12 Pork max. 12 - 16 12 - 14 chops Chicken 1000...
  • Page 16 It can cause damage to the nonstick coating. 10.2 Stainless steel or aluminium appliances Clean the oven door with a damp cloth or sponge only. Dry it with a soft cloth. Do not use steel wool, acids...

  • Page 17: Troubleshooting

    ENGLISH 4. Put the door on a soft cloth on a Make sure that you install the internal stable surface. glass panel in the seats correctly. 5. Hold the door trim (B) on the top edge of the door at the two sides and push inwards to release the clip seal.
  • Page 18 Problem Possible cause Remedy The oven does not heat The fuse is blown. Make sure that the fuse is the cause of the malfunc‐ tion. If the fuse is blown again and again, contact a qualified electrician. The oven does not oper‐...

  • Page 19: Installation

    ENGLISH 12. INSTALLATION WARNING! WARNING! Do not squeeze the gas Refer to Safety chapters. supply ramp and the pipe when you move the 12.1 Gas connection oven into the built-in cabinet. WARNING! 3. Seal the connection correctly. Use a Before the gas connection, leak detection to control it.
  • Page 20 2. Release the screw (C), which keeps Make sure that the gas the burner in position. supply pressure of the appliance obeys the recommended values. If the supply gas pressure is changeable or different from the necessary pressure, you...
  • Page 21 ENGLISH WARNING! min. 4 mm Only put the mains plug into the mains socket when all parts are back into their initial position. There is a risk of injury. min. 550 6. Light the gas oven burner. Refer to "Daily use" chapter. min.

  • Page 22: Technical Data

    12.6 Securing the appliance to 12.8 Cable the cabinet Cable types applicable for installation or replacement: H05 V2V2-F (T90), H05 BB-F For the section of the cable refer to the total power on the rating plate. You can also refer to the table: Total power (W) Section of the ca‐...

  • Page 23: Energy Efficiency

    G30 (3+) 28-30 mbar G31 (3+) 37 mbar 14. ENERGY EFFICIENCY 14.1 Product Fiche and information according to EU 65-66/2014 Supplier's name Electrolux F13GN Model identification F13GX Energy Efficiency Index 70.8 Energy efficiency class Energy consumption with a standard load, con‐...
  • Page 24 15. ENVIRONMENTAL CONCERNS Recycle the materials with the symbol marked with the symbol with the household waste. Return the product to . Put the packaging in applicable your local recycling facility or contact containers to recycle it. Help protect the your municipal office.
  • Page 25 ENGLISH...
  • Page 26 www.electrolux.com...
  • Page 27 ENGLISH...
  • Page 28 www.electrolux.com/shop...
